OPERATORS
HANDBOOK TD500 &
TD500HL TRACKED
DUMPER
WINGET LIMITED
PO BOX 41
EDGEFOLD INDUSTRIAL ESTATE
PLODDER LANE
BOLTON
LANCS
BL4 0LR
Tel: ++ 44 (0) 1204 854650
www.winget.co.uk
ISSUE 13
2020
CONTENTS
1Introduction
2Declaration of Conformity
4Warranty Terms & Conditions
6Safe Working
11 Operation
13 Maintenance and Service
20 Technical Information
23 Parts Information
INTRODUCTION 1
The WINGET TD500 & TD500HL Tracked Dumper are based on the
HONDA HP500H Power Carrier donor unit and this Handbook must be
read in conjunction with HONDA HP500H Owners Manual.
The contents of this Handbook although correct at the time of
publication, may be subject to alteration by the manufacturers
without notice.
Winget Limited operates a policy of continuous product development.
Therefore, some illustrations or text within this publication may differ
from your machine.
WARNING: The operator must read both this handbook and the
Honda publication and be familiar with all the controls before
attempting to operate this machine.
DECLARATION
OF
CONFORMITY
We: WINGET LIMITED
Of P.O. Box 41 Edgefold Industrial Estate, Plodder Lane, Bolton, Lancs,
England BL4 0LRdeclare that the product type:-
Machine Type:- . 500Kg Tracked Dumper .
Model:- .TD500 & TD500HL .
Serial Number:- . TD5001001-TD5002599 .
To which this declaration relates, with a net installed power of 3.6Kw and
having been tested in accordance with the Conformity Assessment Procedure
detailed in Annexe VI of Directive 2000/14/EC and verified by;-
AV Technology Limited
AVTECH House
Birdhall Lane
Cheadle Heath
Stockport
Cheshire
SK3 OXU
is in conformity with the provisions of the Noise Emission in the Environment
by Equipment for use Outdoors Directive 2000/14/EC. A representative sample
of this equipment was tested and Sound Power Levels (Lwa) recorded of:-
99db
We guarantee under the provisions of the above Directive (2000/14/EC) that
the Sound Power Levels for this equipment will not exceed:-
101db
We also declare that the above equipment is also in accordance with the
following EC Directives:-
2006/42/EC 2004/108/EC
S. Hodge .Bolton
04.02.20
Place and date of issue Name and signature or equivalent
marking of authorised person.
Joint Managing Director
Position
The above named person is also responsible for holding the Technical Documentation
applicable to the product to which this declaration relates and may be contacted at the
address which appears at the head of this declaration
Please take care of this document, as duplicate copies are not available.
This document is in accordance with EN45014:1989
WARRANTY TERMS & CONDITIONS 4
Winget Limited assures you that if any of the parts identified within
the Parts section of this manual become defective due to faulty
manufacture or materials within 12 months from the date of purchase,
the part will be repaired or replaced under warranty free of charge by
any authorised Winget Distributor.
Warranty repairs must be carried out by a Winget Distributor, unless
prior agreement has been agreed in writing with the Warranty
Department at Winget Limited.
This warranty is given to the first owner and may be transferred to
subsequent owners for the balance of the Warranty period.
Winget Limited’s liability only extends to the costs of repair or
replacement of the faulty parts and necessary labour charges
involved in the repairs. The company accepts no liability for any
consequential loss, damage or injury, resulting directly or indirectly
from any defect in the goods.
Items not covered by Warranty and considered to be the customers
responsibility include normal maintenance services; replacement of
service items and consumables; replacement required due to abuse,
accident, misuse or improper operation; replacement of wearable
items e.g. pins bushes etc.
All Warranty repairs on the Honda HP500H Power Carrier must be
carried out by an Authorised Honda Distributor.
The Warranty will not apply where the equipment is modified,
converted, or used for purposes other than those for which it was
designed, unless clearance for the modifications etc. have been
granted by Winget Limited in writing.
The Pre-delivery Inspection & Warranty Registration Document must
be completed correctly and returned to Winget Limited within 7 days
of the date of sale. Failure to do so could result in any subsequent
Warranty claim being rejected.
No claim will be considered if other than genuine Winget Limited
parts, which must be obtained via an authorised Winget distributor,
WARRANTY TERMS & CONDITIONS 5
are used to effect a repair, or if lubricants other than those
recommended by Winget Limited are used.
The equipment must be serviced and maintained in accordance with
the service schedules laid down in this handbook by Winget Limited.
Evidence that these have been complied with may be required before
Warranty claims are reimbursed.
Winget Limited have a policy of continuous product improvement
and reserve the right to change specifications without notice. No
responsibility will be accepted for discrepancies, which may occur
between the specification of machines and the descriptions
contained in publications.
SAFE WORKING 6
Safety is the responsibility of all persons working with and around
this machine. Think “SAFETY” at all times. Read and remember the
contents of this and the Honda Operators Handbook.
Any modifications to the machine will affect its working parameters
and reduce built in safety factors. Refer to Winget Limited before
fitting any non-standard equipment or parts. Winget Limited accepts
no responsibility for any modifications made after the machine has
left the factory, unless previously agreed in writing. Winget Limited
will accept no liability for damage to property, persons or the
machine if failure is brought about due to such modifications, or
fitment of spurious parts.
Never use this machine for purposes other than those for which it
was designed. This machine was designed to carry loads such as
soil, clay, sand, wet concrete, light stone, garden rubbish or other
similar materials. It was not designed to carry any loads or materials
that may over hang the skip in any way, nor was it designed to carry
loads that may move around in the skip uncontrollably. If in doubt as
to the suitability of this machine for a particular task refer to Winget
Limited or Honda Power Equipment.
Never commence work until the daily service checks have made
carried out.
Always report faults as soon as they are discovered.
Never fill fuel or hydraulic tanks whilst the engine is running. Stop
the engine and allow the tanks to cool.
Never leave the machine unattended with the engine running.
Never ride on the machine and do not carry others as passengers.
Never use this equipment in areas of poor lighting.
Always operate on surfaces that are known to be stable.
Never drive or operate the machine close to the edge of any
excavation, always use effective track stops to prevent the machine
running close to the edge. Ensure the stops are in proportion to the
size of the tracks and are set sufficiently far back from the edge of
any excavation to prevent the weight of the load causing a collapse.
