Whistler 1580 Manual de usuario
If you have questions concerning the op-
erationofthisWhistlerproductpleasecall
customer technical service:
1-800-531-0004
Hours:
Monday - Friday
9:00 am - 5:00 pm EST
Dear Whistler Owner,
Formanyofus,avehicleismorethanjusttransportation.Itcanbe
amobileoffice,communicationsorentertainmentcenter,orsim-
plyanexpressionof our personality. Whistler Corporation recog-
nizes this and has created a selection of products we call “En-
hancedDrivingTools”.Theseproductsaredesignedtomakethe
time you spend in your vehicle more productive, more fullfilling,
safer, or just simply more fun. Our mission is to provide products
that improve your driving experience though keeping you...
IN TOUCH • IN COMFORT • IN CONTROL
Your new Whistler 1580/1585 laser/radar detector detects all ra-
dar,laserandsafetyradarsystems,plusoffersWhistler’sexclusive
SafeDriving System™ andReal Voice™technology. This compre-
hensivesafetysystemdetectstheSafetyWarningSystem™keep-
ing you informed of road hazards and adverse weather. Plus,
Whistler’suniqueStayAlert™featuretestsdriver’salertnessonlong
solo trips. Whistler’s 1580/1585 also offers a digital display with
safety message icons to keep you informed while you drive.
Tofullyacquaintyourselfwiththeoperation ofthe Whistler1580/
1585 and to better understand the differences between detect-
ing radar, laser and safety radar signals, we recommend reading
this entire manual.
Enjoy the Whistler 1580/1585 and please drive safely.
Sincerely,
WHISTLER CORPORATION
INTRODUCTION
1
Topic Page
Model Features Summary 3 - 5
Installation 6 - 8
• Mounting Guidelines
• Dash/Visor/Windshield Mounting
• Power Connection And Fuse Replacement
Operation 9 - 15
• Power On And Self-Test
• Memory/Beep Confirmation
• Audio Level Adjustment
• Auto Quiet/Mute Modes
• City Modes
• Dim/Dark Mode
• Stay Alert
• Option Select Mode
• Teach/Tutorial Mode
Radar, Laser And VG-2 Alerts 16 - 19
• Speed Radar Audio/Visual Alerts
• Pulse Protection®
• Safety Radar Audio/Visual Alerts
• Laser Audio/Visual Alerts
• VG-2 Audio/Visual Alerts
• Alert Priority
• Reset Features/Care Maintenance
Troubleshooting Guide 20
Are Detectors Legal? 21
Speed Monitoring Technologies 22 - 23
• Radar Facts
• Laser Facts
• Other Speed Detection Systems
• Radar Detector Detectors
Warranty Information 24 - 26
Specifications 27
Accessories 28
TABLE OF CONTENTS
2
Whistler 1580/1585
Whistler’sergonomicanduser-friendlydesignprovidesanew
level of operating convenience. Special features include:
1. Bracket Release Button - Provides quick and easy re-
lease of the mounting bracket.
2. Power Jack - Provides connection for the power cord.
3. Speaker - Provides distinct audio and Real Voice™warnings
for X, K, Ka band radar, safety radar, laser, VG-2 and Stay Alert.
4. Power/Dim/Dark Button - Turns unit on/off (press and
hold for 2 seconds) and engages Dim/Dark modes.
5. Volume Up/Down Buttons - Adjust volume up or
down.
6. High Visibility LED Display -Providesdistinctvisualcon-
firmation of signals detected, signal strength, and indicates en-
gaged modes of operation.
WHISTLER FEATURES
3
EE
MRGNCY
PWR VOL
CITY
MUTE
1580
1
2
4
5
6
8
7
3
9
WHISTLER FEATURES
7. Mute/Menu Button - Pressing MUTE before a signal is
detectedengagesAutoQuietModewhichautomaticallyreduces
theaudiolevelaftertheinitialwarningtoalowaudiolevelsetting.
PressingMUTEduringaradar/laserencountersilencesaudioalerts,
while allowing visual alerts to keep you informed. Pressing and
holding for 2 seconds allows you to enter Option Select Mode
and change menus.
8. CITY/CITY 1 Button - Reduces the annoyance of
false alerts typically encountered in urban driving areas.
9. Laser Antenna (Rear) - An integrated optical waveguide
providessuperiordetectionoflasersignalstransmittedfrom
behind.
10. Laser Antenna (Front) - High gain optical lens array
provides increased sensitivity and field of view for leading-
edge laser detection.
11. Radar Antenna - Compact, high-efficiency antenna re-
ceives radar signals.
12. Mounting Bracket Location - Slot holds mounting
bracket firmly.
4
11
12
10
WHISTLER FEATURES
5
Accessories
Accessories included are highly functional and easy to use.
Coiled and Straight Power Cords with Modular Plug -
Connects to the unit’s power jack and your vehicle’s lighter
socket.
Windshield Bracket - Allows installation of unit on your
vehicle’s windshield.
Visor Bracket - Allows installation of unit on your vehicle’s
visor.
Velcro®Fasteners - Designed to secure the unit on a level
dashboard.
Hardwire Kit (1585 only) -10 ft. hardwire connects directly
to vehicle’s fuse box.
Protective Travel Case (1585 only) - Designed for conve-
nience storage of your Whistler Radar Detector.
Mounting Guidelines
• Mount the unit as low as possible near the center of the
windshield.
• Donotmountyourunitbehindwipers,ornaments,mirrored
sunscreens,etc.Theseobstructionshavemetalsurfaceswhich
can affect radar and laser signals and reduce critical warning
time. (Regular tinted glass does not affect reception.)
• Some newer windshields have an Instaclear™or
Electriclear™type coating, which affect radar signals. Con-
sult your dealer or the owner’s manual supplied with your
vehicle to determine if your windshield has this coating.
• Avoid placing unit in direct contact with windshield.
• To reduce the possibility of theft, conceal your unit when
not in use.
Windshield Mounting
• Install the two suction cups and rubber bumper onto the
bracket by fitting them into their holes.
• Press the suction cups onto the windshield at the location
you have chosen.
• Slidethedetectorontothebracketuntilitlocksintoplace.
• If necessary, the unit may be leveled by bending the wind
shield bracket. Press the bracket release button and remove
INSTALLATION
6
the detector before bending.
IMPORTANT: Some newer cars have a plastic safety coat-
ingon theinside ofthe windshield.The windshieldbracket
may leave permanent marks on this type of surface. To
find out if your vehicle has this type of windshield, check
the owner’s manual or ask your dealer. We recommend
that you do not leave the suction cup bracket on the win-
dowin directsunlight. If thedetectoris removed,thismay
cause blistering of the dash in some vehicles.
Dash Mounting
• Makesurethemountinglocationyouhavechosenisrelatively
level and is clean and dry. Clean with isopropyl alcohol if neces-
sary to remove any waxes or polishes.
• SeparatetheVelcro®fastener strips. Peel the paperback-
ing off each strip and adhere one piece to the dash and the
other piece to the bottom of the unit, taking care not to
cover the serial number.
Be careful not to place the Velcro®over the unit’s serial number. If the Velcro®is
removed, the serial number may be pulled off the unit. Units without serial num-
bers are not covered under warranty.
INSTALLATION
7
Visor Mounting (optional accessory)
• Slide the visor bracket into the bracket mounting slot.
• Clip the visor bracket onto the visor making sure it is rela-
tively level and has a clear view of the road.
Power Connection
• Plug the small end of the power cord into the unit’s power
jack.
• Plug the large end into the vehicle’s cigarette lighter.
Fuse Replacement
The lighter socket plug is equipped with a replaceable 2 amp
3AG fuse located behind the silver tip. To replace the fuse,
carefully unscrew the tip of the plug. (IMPORTANT: Unscrew
slowly.Thetipcontainsaspringwhichmayflyoutwhendisas-
sembling.) Insert the new fuse with the spring and screw on
thetip.With use, screw cap on plug may loosen. Retighten
occasionally.
Unscrew the tip of the lighter socket plug carefully when replacing the 2
amp fuse.
INSTALLATION
8
Slide on visor
Insert into bracket
mounting slot
Power On And Self-Test
Each time your Whistler detector is turned on, an automatic
self-test sequence confirms that the speaker and visual dis-
plays are functional and displays the engaged features.
• Press (Power) or apply Power. Display reads:
• Press and hold for 2 seconds or remove power to turn
unit off.
Memory/Beep Confirmation
Allfeaturesselected(exceptStayAlert)areretainedinmemory.
Each time a button is pressed one beep confirms feature “on”,
two beeps confirm feature “off”.
OPERATION
9
K
Ka
X
LASER
9
9
9
SAFETY
VG2 OFF
HIGHWAY
WHISTLER
