WASHING MACHINE

XWT-758

SERVICE MANUAL

Name of parts

Wash timer selector Spin timer selector

Water inlet port Selector

Control Panel

Washer tub

Pulsator

Base Drain hose

Power cord

Inner spin dryer lid

Lint filter

Inner spin dryer lid

Outer spin dryer lid

Spinner cap

1EA 1EA

Inlet joint Inlet hose

CCESSORIES

Note:

The washing machine is to be

connectedtothewater mains

usingnewhose-setssupplied

with the appliance are to be

used and old hose-sets

shouldnotbere-used.

GUIDE FOR SAFETYAND DURABILITY

SPECIFICATIONS

Note:Ambient temperature must notbe above 50 .

℃

Do not expose the wash-

ing machine to direct

sunlight or rain.

Do not install the washing

machine in a damp

environment.

Do not splash water over

switches.

Let water drain away from

the drain hose thoroughly. When pulling out the power

plug, do not hold the cord. Do not let children play

with the washing machine.

Keep the washing machine

away from fire or a heat

source.

Do not wipe the washing

machine with volatile

material, gasoline, etc.

Do not pour water over

50 into the tub.

℃

Rated voltage

Rated frequency

Rated washing capacity

Rated spinning capacity

Rated power input in washing

Rated power input in spinning

Enter-water pressure

Net weight

Machine dimension (L W H)

Water dosage (H)

××

: 220V

: 60Hz

: 7.5kg

: 7.0kg

: 350W

: 150W

: 0.02-0.3MPa

: 23kg

: 805mm 445mm 900mm

: 72L

××

Clothes

Spin dryer

Spinner cap

Spin drying

Notes for spinning

Type of the clothes

Shirts (synthetic)

Undershirts

Work clothes

Spin-drying time

1~2 min

3~5 min

5 min

Distribute clothing evenly

in the tub before spinning. Put the spinner cap in the

right place of the spinning tub. Do not put hands into

the spinning tub before

it stops.

OPERATING INSTRUCTIONS

MAINTENANCE

1.Lift the outer spin dryer lid and open the inner spin dryer

lid.

2.Place the rinsed clothing into the spinner tub.

3.IMPORTANT: To ensure correct balancing of the spinner

unit, distribute clothing evenly in the tub before spinning

(see n spinning ).

4.Place the

5.Close both the inner and outer spin dryer lids.

6.Turn the

7.Make sure the load is balanced to spin .

otes for

"SPINNER CAP" firmly on top of the clothing

(see notes for spinning).

"SPIN TIMER SELECTOR" clockwise to the

desired spin time (see spin-drying time chart). The spin

cycle will automatically commence. evenly

WARNING: DO NOT OPEN THE SPIN LID UNTIL THE

SPINNING HAS STOPPED.

SPIN TIMER SELECTOR

MAINTENANCE

Pull out the power plug

after washing. Wipe the wash tub with a

clean and dry cloth.

Clean tubs after bleaching or

starching, otherwise, some

deposits will accumulate.

Avoid water splashing on the

control panel to avoid

damage to internal electrical

wirings of the unit.

Remove the

lint filter.

Clean and

rinse it

thoroughly.

Reinstall.

Please clear the remains out

from of the lint filter in time.

5cm

Installation

Connect the drain hose

Install your new washing machine on a flat level floor

as near to a 2pin 220 volt AC socket outlet and water

tap as possible.

Keep the unit at least 5cm from walls or other fixtures

to avoid accidental contact during operation.

INSTALLATION

Please pull out the rubber stopple

at the end of the drain hose before

use.

WARNING:

To avoid the danger of choke,

keep the stopple away from

babies and children.

The groundwire which is indicated by green colour must

be firmly connected to a special groundwire. Please call

the technician to assemble.

The socket should have assembled the 3A fuse.

Do not cut or extend the power cord.

Do not operate the unit if the power cord is damaged or

cracked.

Do not place the power cord on wet or damp floors.

Do not attempt to repair or replace the power cord, if the

power cord is damaged. and refer repair to

qualified service personnel only.

Do not operate

Be sure to remove things such

as keys, pins, coins and

jewellery from the laundry.

Wash fuzzy laundry by turning

it inside out.

Wash oily or dyed laundry

separately.

Wash delicate clothes in a

nylon net.

PREPARATION BEFORE WASH

WIRING DIAGRAM

YELLOW

CAPACITOR

BROWN

PLUG

BROWN

WHITE

BLUE

GREY

SPIN TIMER

GREY

YELLOW

GENTLE WASH

YELLOWBLACK

BLACK

WHITE

CHANGE OVER SWITCH

NORMAL WASH

BROWN

SPIN

MOTOR

RED

BLUE

RED

WASH

MOTOR

BLUE

YELLOW/GREEN

CAPACITOR

WASH TIMER RED RED

SAFETY SWITCH

WHITE

DRAIN

Plug the power cord

into the socket.

Let down the drain

hose.

Connect the inlet

hose.

OPERATING INSTRUCTIONS

Washing

Rinsing

2. Insert the inlet hose into the water inlet port,

dd the proper amount of water to the

wash tub.

the faucet, A open

3. References for detergent volume.

4. Put clothes in the wash tub, one article at a

time.

1. Turn the SELECTOR knob to select

the HEAVY/NORMAL water flow according

to the fabric type of the clothes.

“”

5. Turn the WASH TIMER SELECTOR to the

“

desired wash time clockwise. The washing

action will begin.

6. After washing is completed, drain the water

by turning the SELECTOR to the DRAIN

“”“”

position.

”

WASH ACTION NORMAL HEAVY

FABRIC TYPE Synthetics

fabrics

Wools

Cotton Linen

Heavily stained clothes

Work clothes

WASHING TIME 3~7min 8~15min

Water lever

Detergent volume(g) Low

25~33 Middle

30~40 High

40~48

Normal Rinse Mode:

Let water flow into the tub, rinse for 3-5

minutes like washing mode. Repeat 2-3 times.

Overflow Rinse Mode:

Adjust the faucet and let the water flow

continuously into the tub, the other operation

just like the Normal Rinse Mode.

SELECTOR

WASH TIMER SELECTOR

Troubleshooting

Failure Reason Checking Step & Repairing Method

the power is abnormal to check the fuse, wire and socket for the

washing machines, to sure whether it is

well connected

the wash motor or

capacitor breaks down to check the capacitor firstly, then the

wash motor, and make necessary

repairing, if necessary, change the

capacitor or wash motor

The washing

machine

doesn't wash

wash timer breaks down to change the wash timer accordingly

e lubricating oil in the

gear box was leaked, or

e seal of gear box for

oil doesn't work

to change the gear box

the noise comes from

the shift of the bear box to change the gear box

the belt or strap of the

gear box is too tight or

too loose

to adjust or change the belt accordingly

the washing

machine

makes noise

during wash

the noise comes from

the shift of the wash

motor

to change the wash motor

the belt is too loose to adjust or change the belt accordinglythe wash

operation is

not powerful overpass the wash

capacity reduce the clothes to fit its wash capacity

the touch point of safety

switch isn't well

connected

re-adjust your touch point of the safety

switch

the brake system wire is

too long, which lead to

the brake plate cannot

separate the brake

wheel from the spin

motor after the spin lid

is covered

to readjust the brake system wire, if

necessary, change the brake system wire

accordingly

the spin capacitor was

broken by the electricity to change the spin capacitor

the spin motor was

failed to check or change the spin motor

the wash

machine

doesn't spin

the spin timer was failed to change the spin timer

Failure Reason Checking Step & Repairing

Method

the sc

rew to connect the spin

ift assembly and brake

eel is loosen

to re-tight the screw

the clothes is loaded on one

side the spin tub to re-load the clothes

accordingly in average

the washing machine is

placed on inclining place to adjust and put the washing

machine on the flat place

the washing

machine shakes

violently while

spin

the oiled shift in the rubber

ring is worn, or the vibration

proof rubber ring was

deviated

to conglutinate or change the

vibration proof rubber ring

the spin vibration proof

rubber ring and the spin tub

are not conglutinated

strongly, which leads to water

leakage

to re-conglutinate and fasten the

vibration proof rubber ring

water leakage

the space between the oiled

shift in the rubber ring and

the spin shift assembly is too

big, or the oiled shift in the

rubber ring is worn, which

leads to water leakage

to change the oiled shift in the

vibration proof rubber ring

Exploded Views

XWT-758-1
