Whirlpool AWM05801 Manual de usuario

WASHING MACHINE

AWM05801

User

Manual

User Manual

CHAPTER-1: BEFORE USING THE APPLIANCE

• Correct Usage 6-7

• General warnings 8-9-10-11

• Safety warnings 12-13-14-15-16-17

• Packaging and Environment 18

• Savings Information 19

CHAPTER-2: OVERVIEW OF YOUR DEVICE

• General Appearance 20-21

• Techincal Specications 22

CHAPTER-3: INSTALLATION

• Removing transportation safety screws 23-24

• Adjusting Adjustable Stays 25-26-27

• Electrical connection 28

• Water inlet hose connection 29-30

• Water discharge connection 31

CHAPTER-4: INTRODUCTION OF CONTROL PANEL 32

• Detergent drawer 33-34

• Programme knob 35

• Temperature selection 36

CONTENTS

CHAPTER-5: PRELIMINARY PREPARATION FOR LAUNDERING

• Separating laundries 37-38

• Putting laundries in the machine 39

• Adding detergent into machine 40

• Operating your machine 41-42-43

• Auxiliary functions 44-45

• Child lock 46

• Cancelling programme 47

• Finishing programme 48

CHAPTER-6: PROGRAM TABLE 49-50-51-52-53-54-55

CHAPTER-7: MAINTENANCE AND CLEANING OF YOUR MACHINE

• Warning 56

• Water inlet lters 57

• Pump lter 58-59

• Detergent drawer 60

CHAPTER-8: FLUSH STOPPER / BODY / DRUM 6 1

CHAPTER-9: TROUBLESHOOTING 62-63-64-65-66

CHAPTER-10: AUTOMATIC FAULT WARNINGS AND WHAT TO BE DONE 67

CHAPTER-11: PRACTICAL INFORMATION 68-69-70-71

• Disposal of your old machine 72

CONTENTS

CHAPTER -1: BEFORE USING THE APPLIANCE

(CORRECT USAGE)

• Denitely read the user’s manual.

• Your machine is designed to be used

domestically. Commercial use will

cause your warranty to be cancelled.

• Keep your pets away from your machine

• Please check the packaging of your machine

before installation, and the outer surface af-

ter the package is opened. Do not operate

damaged machines or machines with opened

package.

• Have your machine installed only by author-

ized service. Any interference to your machine

by anyone other than authorized services

shall cause your warranty to be void.

• The appliance is not intended for use by

people (including children) with reduced phys-

ical, sensory or mental capabilities, or lack of

experience and knowledge unless they have

been given supervision or instruction concern-

ing use of the appliance by a person responsi-

ble for their safety. Children should be super-

vised to ensure that they do not play with the

appliance.

CHAPTER -1: BEFORE USING THE APPLIANCE

(CORRECT USAGE)

• Use your machine only for laundries that

have been specied as suitable for washing

by the manufacturer.

• Before operating the washing machine,

remove the 4 transportation screws and

rubber spacers from the back of the ma-

chine. If the screws are not removed, it

may cause heavy vibration, noise and

product malfunction, (voiding the guaran-

tee).

• Your machine is not covered under warranty

for faults caused by any kind of external fac-

tors (pesticides, re, etc.).

• Please do not throw away this user manual;

keep it for future reference. You or somebody

else might need it in the future.

Note: Machinery specications may vary de-

pending on the product purchased.

CHAPTER -1: BEFORE USING THE APPLIANCE

(GENERAL WARNINGS)

• The necessary ambient temperature for your

machine’s ideal operation is 15-25°.

• Frozen hoses can tear and explode. In regions

where temperature is below zero, ambient tem-

perature might endanger the safe operation of

electronic card.

• Please ensure that the clothes you will place

in your machine do not contain any foreign sub-

stances (nail, needle, coins, lighter, matches, clip

etc.) in their pockets. These foreign substances

can damage your machine.

• Before starting to use your machine, you may

call the nearest authorized service and request

free-of-charge help for installation, operation and

use of your machine.

• It is recommended to perform the rst

washing operation in 90˚ Cotton programme

and without laundry by inserting ½ scale

of detergent in 2nd compartment of the

detergent drawer.

CHAPTER -1: BEFORE USING THE APPLIANCE

(GENERAL WARNINGS)

• As detergent or softener exposed to air for a

long time may cause residues, put your deter-

gent or softener in the detergent drawer at the

beginning of every washing.

• It is advised that you unplug your machine

and close the water inlet tap if you will not use

your machine for a long time.

Also, leaving the door of your machine will

prevent the formation of bad odors due to hu-

midity.

• Some water might be left in your machine

after the trials and tests conducted due to

Quality Control procedures.

This will not damage your machine.

• Remember that packaging materials of your

machine may be dangerous for children. Keep

the packaging materials in a place where chil-

dren cannot reach or dispose of them appro-

priately.

• Keep the small parts found in the document

part away from the reach of children and ba-

bies.

• Use pre-wash programs only for very dirty

laundry.

1010

CHAPTER -1: BEFORE USING THE APPLIANCE

(GENERAL WARNINGS)

• Never open the detergent com-

partment when the appliance is

running.

• In case of any breakdown, unplug

the appliance rst and then turn

the tap off. Do not attempt to repair

by yourself, always contact for au-

thorized service advice.

• The amount of laundry you put in

your washing machine should not

exceed the maximum amount indi-

cated.

• Never force the door to open

when the machine is running.

• Washing oury clothes in your

machine damages the machine.

Do not wash oury clothes in your

machine.
