Twin tub Washing Machine

PARTS &

SERVICEManual

WHITE MAGIC SUPER

Models

SAP M0DEL NUMBER OLD MODEL NUMBER DESCRIPTION

2440 WWHY620-B3A WHITE MAGIC SUPER - THAILAND- COOL GREY

Whirlpool of India

This document is only intended for qualified technicians who are aware of the respective safety regulations.

First release Date 2nd May, 2001 Subject to modification Revision No1

Document No. WOI/WM/2001/001 Reviced on 13/01/2003

PAGE 1of 21

CONTENTS

1Introduction 2

2Specifications 3

3Controls and functions 4

4Installation Procedure 6

5Wiring diagram 8

6Exploded views and parts list 9

7Trouble diagnosis chart 17

8Component check guide 20

Whirlpool of India

This document is only intended for qualified technicians who are aware of the respective safety regulations.

First release Date 2nd May, 2001 Subject to modification Revision No1

Document No. WOI/WM/2001/001 Reviced on 13/01/2003

PAGE 2of 21

INTRODUCTION

It is a twin tub washing machine, which is developed on basic twin tub platform and

it differs from the AWT 62S model in the following respects:

?Max. Capacity : 6.2 kg Dry Clothes.

?Dual action agitator (White Magic TT Agitator).

?White Magic Super styling

?New control panel graphics with AWT 62S model name.

?Mechanical wash timer (White Magic TT Timer).

?Grey color for tub, Drain Hose, Fill Hose, Lower water inlet, Over flow filter, Top

Plate, Stainer Assy, slider adjustible overflow, Guard drain hose.

?Power Cord : SCHUKO PLUG (Right angle type)

?With switch wash and spin.

?Drive Assy.- NT

?Fill hose assy – Double end cuff

?Plastic Spin basket.

Whirlpool of India

This document is only intended for qualified technicians who are aware of the respective safety regulations.

First release Date 2nd May, 2001 Subject to modification Revision No1

Document No. WOI/WM/2001/001 Reviced on 13/01/2003

PAGE 3of 21

SPECIFICATIONS

?Power Source :220V AC 50 Hz single phase, earthed 5 A 3 pin

?Capacity :Wash :6.2 Kg dry weight of clothes

?Motor Speed :Spin :1600 RPM +/- 25 RPM

?Motor Power :Wash :170 – 265V / Single speed / 330W

(Input) Spin :170 – 265V / Single speed / 150W

?Wash system :Agitator type reversible (12 strokes/Min.)

?Spin System :Centrifugal

?No. of wash actions : 3 (Soft, Normal and Heavy)

?Wash Timer : Electromechanical, 15 minutes maximum

Operation knob : Rotary

?Spin Timer : Mechanical Spring wound timer (5 mts. Max.)

?Wash / Rinse temperature : 50oC

?Basket material : Plastic

?Underbase material : Polypropylene

?Cabinet Material : Pre-painted steel

?Wash lid : Hinged / Can be removed

?Spin Lid : Hinged

?Lint Collector : Yes

?Spin lid safety : Yes

Whirlpool of India

This document is only intended for qualified technicians who are aware of the respective safety regulations.

First release Date 2nd May, 2001 Subject to modification Revision No1

Document No. WOI/WM/2001/001 Reviced on 13/01/2003

PAGE 4of 21

CONTROLS AND FUNCTIONS WHITE MAGIC SUPER

Escutcheon

?Wash mode selection

There are three basic wash actions viz. Heavy, Normal and Soft.

Rotary knob in the control panel

?Spin time selection

Spin time of 2,3 and 5 minutes can be selected by pressing the "Spin time" button

?Drain Selector

This is a mechanical slide type knob with two positions Wash/Rinse and Drain. When set

at Wash/Rinse position the drain valve attached to the wash tub is closed and thereby

allowing water to be retained in the tub to perform Wash/Rinse. If the knob is pushed to

drain position the drain valve opens and the water is drained out.

Whirlpool of India

This document is only intended for qualified technicians who are aware of the respective safety regulations.

First release Date 2nd May, 2001 Subject to modification Revision No1

Document No. WOI/WM/2001/001 Reviced on 13/01/2003

PAGE 5of 21

?Spin shower

This is also a two position knob with two positions Wash tub and Spin shower. When set

at Wash tub position it allows the water to be filled in the wash tub. When set at Spin

shower position water flows in to the spin tub.

Spin shower option is generally used to aid the soap removal from the clothes. During

this process the clothes are loaded in the spin tub and the knob is set to spin shower

mode. Water is then let into the machine. This water gets sprayed over the clothes in the

spin tub. After two minutes of spraying the water supply needs to be cutoff and the spin

operation is to be continued for another 2 minutes. This removes suds from the clothes

effectively.

Whirlpool of India

This document is only intended for qualified technicians who are aware of the respective safety regulations.

First release Date 2nd May, 2001 Subject to modification Revision No1

Document No. WOI/WM/2001/001 Reviced on 13/01/2003

PAGE 6of 21

INSTALLATION PROCEDURE

?Before installing the machine make sure of the following facilities

?Electrical requirements

A 220 Volts, 5 Amps and 50 Hz, three pin socket with proper earth and fuse is

required.

DO NOT USE EXTENSION CORD WITH THE WASHING MACHINE. SUCH

USE MAY RESULT IN FILE, ELECTRICAL SHOCK OR OTHER PERSONAL

INJURY DUE TO IMPROPER OR INADEQUATE GROUNDING.

?Water source

A water tap suitable to the faucet coupler supplier with the machine is required

(Max. tap diameter 3/4").

?Drain facility

A drain at floor level to drain the used water form the machine by gravity is

required.

?Sturdy floor

The floor must be level and sturdy enough to support the machine weight.

?Installation Procedure

?Check the plug point to which the machine is to be connected for proper

earthing using a multimeter in voltage mode. The meter should read 220 Volts

between line and earth and line and neutral. Also the meter should read zero

volts between earth and neutral. If earthing is not proper advise the customer

to get the same corrected by an electrician before installing the washing

machine

?Cut the straps wound over the machine carton using stripper or a knife.

?Take out the corrugated packing material placed over the machine.

?Pull out the corner posts placed at the corner of the carton one by one.

Whirlpool of India

This document is only intended for qualified technicians who are aware of the respective safety regulations.

First release Date 2nd May, 2001 Subject to modification Revision No1

Document No. WOI/WM/2001/001 Reviced on 13/01/2003

PAGE 7of 21

?Take out the carton from the machine.

?Remove the polythene cover wrapped over the machine.

?Open the machine and take out the fill hose and other accessories from the

machine.

?The machine is on thermocole packing at the bottom, which is to be removed

by lifting the machine and make the machine rest on the castors.

?Move the machine to the place where it is to be installed.

?Connect the power cord to the electrical power supply.

?Operate the machine for one complete cycle and check for proper functioning

of the machine.

?Use the opportunity for giving a washing demonstration to the customer.

Whirlpool of India

This document is only intended for qualified technicians who are aware of the respective safety regulations.

First release Date 2nd May, 2001 Subject to modification Revision No1

Document No. WOI/WM/2001/001 Reviced on 13/01/2003

PAGE 8of 21

WIRING DIAGRAM

Whirlpool of India

This document is only intended for qualified technicians who are aware of the respective safety regulations.

First release Date 2nd May, 2001 Subject to modification Revision No1

Document No. WOI/WM/2001/001 Reviced on 13/01/2003

PAGE 9of 21

EXPLODED VIEWS
