Top Mount R frig rator

®

PRODUCT MODEL NUMBERS PRODUCT DIMENSIONS

G2IXEFMW

G9IXEFMW

El ctrical: A 115-Volt, 60-Hz, AC-only, 15- or

20-amp fused, grounded electrical supply is

required. It is recommended that a separate circuit

serving only your refrigerator e provided. Use an

outlet that cannot e turned off y a switch. Do not

use an extension cord.

Wat r: A cold water supply with water pressure of

etween 30 and 120 psi (207 and 827 kPa) is

required to operate the water dispenser and ice

maker. If you have questions a out your water

pressure, call a licensed, qualified plum er.

If a reverse osmosis water filtration system is

connected to your cold water supply, the water

pressure to the system needs to e a minimum of

40 to 60 psi (276 to 414 kPa).

IMPORTANT: The pressure of the water supply

coming out of a reverse osmosis system going to

the water inlet valve of the refrigerator needs to e

etween 30 and 120 psi (207 and 827 kPa).

Because Whirlpool Corporation policy includes a continuous commitment to improve

our products, we reserve the right to change materials and specifications without notice.

Dimensions are for planning purposes only. For complete details, see Installation

Instructions packed with product. Specifications su ject to change without notice.

Ref. W10208844

02-20-09

1/2" (1.25 cm)

2" (5.08 cm)

C

D

top of

cabin t

B

A

E

ov rall

Depth Cab. Width Door Width Cab. Height Overall Height

Model “A” “B” “C” “D” “E”

19 u.ft. 31-1/2" 29-1/2" 30-1/8" 65-1/2" 66-1/2"

(80 m) (74.9 m) (76.5 m) (166.4 m) (168.9 m)

22 u.ft. 31-1/2" 32-1/2" 33-1/8" 65-1/2" 66-1/2"

(80 m) (82.6 m) (84.1 m) (166.4 m) (168.9 m)

To ensure proper ventilation for your refrigerator, allow for a 1⁄2" (1.25 cm) space

on each side and at the top. When installing your refrigerator next to a fixed wall,

leave 2" (5.08 cm) minimum on the hinge side (some models require more) to allow

for the door to swing open. If your refrigerator has an ice maker, allow extra space

at the ack for the water line connections.

NOTE: Do not install the refrigerator near an oven, radiator, or other heat source, nor

in a location where the temperature will fall elow 55°F (13°C).

Dim nsions “D” and “E” includ roll rs

xt nd d 3/4" (1.9 cm)

LOCATION REQUIREMENTS
