WESTERSTRAND KNX Manual de usuario

KNX SLAVE CLOCK

Document:

DOK11027en01.doc

Author:

User Manual

Date:

2018

Page:

(

)

WESTERSTRAND URFABRIK AB

P.O. Box 133 Tel. +46 506 48000 Internet:: http://www.westerstrand.se

SE 545 23 TÖREBODA Fax. +46 506 48051 E mail: info@westerstrand.se

User Manual

Westerstrand KNX Slave Clock

KNX SLAVE CLOCK

Document:

DOK11027en01.doc

Author:

User Manual

Date:

2018

Page:

(

)

WESTERSTRAND URFABRIK AB

P.O. Box 133 Tel. +46 506 48000 Internet:: http://www.westerstrand.se

SE 545 23 TÖREBODA Fax. +46 506 48051 E mail: info@westerstrand.se

L st of contents

GENERAL DESCRIPTION .................................................................................................................................. 3

INSTALLATION .................................................................................................................................................. 3

KNX CONFIGURATION ...................................................................................................................................... 4

ESCRIPTION OF

ROUP

BJECTS

.................................................................................................................................. 5

ESCRIPTION OF

ARA ETERS

....................................................................................................................................... 6

CLEANING THE CLOCK EXTERIOR .................................................................................................................. 7

TECHNICAL DATA ............................................................................................................................................. 7

KNX SLAVE CLOCK

Document:

DOK11027en01.doc

Author:

User Manual

Date:

2018

Page:

(

)

WESTERSTRAND URFABRIK AB

P.O. Box 133 Tel. +46 506 48000 Internet:: http://www.westerstrand.se

SE 545 23 TÖREBODA Fax. +46 506 48051 E mail: info@westerstrand.se

General descr pt on

Westerstrand’s KNX analogue slave clock provides the possibility to create a time distribution system with high

accuracy and high reliability through a KNX network.

The clock is intended for connection to a 2-wire bus that combines power supply and KNX communication.

A built-in microprocessor receives time telegram from a KNX master clock, reads the position of the hands, and

sets the clock to the correct time.

Installat on

1. When the clock is wall mounted use the cable inlets, see fig. 1.

2. easure and assemble an appropriate mounting screw (not included).

3. Connect the KNX bus to the black/red connector on the back of the clock.

4. The clock will start to reset itself to 12:00.

5. Configure the clock with the ETS software. The KNX connector, LED and programming buttons are

located on the back of the clock.

6. After the configuration is downloaded, the clock will again reset itself to 12:00, and then wait for a time

telegram. If the parameter “Send Time Request at Startup” has been enabled, the clock will send a time

request to the master clock. This requires that the master clock is configured to receive time requests.

7. As soon as a valid time telegram has been received, the hands will step forward to the correct time.

KNX SLAVE CLOCK

Document:

DOK11027en01.doc

Author:

User Manual

Date:

2018

Page:

(

)

WESTERSTRAND URFABRIK AB

P.O. Box 133 Tel. +46 506 48000 Internet:: http://www.westerstrand.se

SE 545 23 TÖREBODA Fax. +46 506 48051 E mail: info@westerstrand.se

KNX conf gurat on

The clock must be configured with ETS4/5 before use. The available group objects and parameters are listed

below:

Group Objects

ID Object Datapoint

Type

Direction Size Configuration Flags

U T RI

R C Priority

DateTime 9.00 Input 8 bytes 0 0 0 N/A

Low

2 Time 0.00 Input 3 bytes 0 0 0 N/A

Low

4 Time Request .00 Output bit 0 0 0 0 N/A

Low

5 Timeout Alarm .005 Output bit 0 0 0 0 N/A

Low

Parameters

Parameter Description Range Default

SCLOMode Clock Mode ReadOnly =Slave

System Clock

Timeout

Timeout period 3- 445 2 (minutes)

Clock Type Type of clock, Date and

time or only time

-Analogue

-Digital – Time only

-Digital – Time and date

Analogue

Time Format Datapoint type used -DPT 0.00

-DPT 9.00

DPT 9.00

Send Time Request

at Startup

Ask master clock for time

at startup.

-No

-Yes

Send Alarm at

Timeout

Send Alarm on KNX bus

at Timeout

-No

-Yes

Timeout Action Behaviour at timeout -Continue using local clock

-Reset to 2:00

Continue using

local clock

KNX SLAVE CLOCK

Document:

DOK11027en01.doc

Author:

User Manual

Date:

2018

Page:

(

)

WESTERSTRAND URFABRIK AB

P.O. Box 133 Tel. +46 506 48000 Internet:: http://www.westerstrand.se

SE 545 23 TÖREBODA Fax. +46 506 48051 E mail: info@westerstrand.se

Descr pt on of Group Objects

ID 1: DateT me

The clock receives time with datapoint type 9.00 and synchronises the local clock accordingly.

ID 2: T me

The clock receives time with datapoint type 0.00 and synchronises the local clock accordingly.

ID 3: Date

Not used in analogue clocks

ID 4: T me Request

To speed up installation, the clock can be set to send a time request at startup. If the master clock

can receive and respond to the request, it will immediately transmit the time. This way the installer

can quickly see if the clock is working or not.

ID5: T meout Alarm

The slave clock will expect time messages with the interval set with the parameter “System Clock

Timeout”. If there are no messages within this time, an alarm can be sent on the KNX bus. If

parameter “Enable Timeout Alarm” is set to “Yes”, the clock will set this group object to ‘ ’. When the

clock again receives time messages, it will reset the alarm by setting the group object to ‘0’.

KNX SLAVE CLOCK

Document:

DOK11027en01.doc

Author:

User Manual

Date:

2018

Page:

(

)

WESTERSTRAND URFABRIK AB

P.O. Box 133 Tel. +46 506 48000 Internet:: http://www.westerstrand.se

SE 545 23 TÖREBODA Fax. +46 506 48051 E mail: info@westerstrand.se

Descr pt on of Parameters

SCLOMode

SCLOMode is a read only parameter that indicates that the clock is a slave clock.

System Clock T meout

The timeout period is set using the System Clock Heartbeat parameter. The default value is 2

minutes. The timeout value should be set using the following formula:

System Clock Timeout= (System Clock Heartbeat x 2) +

Where System Clock Heartbeat is the transmission interval set in the master clock.

Clock Type

There are two types of slave clocks, the digital that can show both date and time and the analogue

which can only display time. For the analogue clock, select “Analogue”.

T me Format

The clock can receive time in two different formats, datapoint type 0.00 or 9.00 . The default

datapoint type is 9.00 .

Send T me Request at Startup

As default, the slave clock will not send any time requests. To force the slave clock to send a request

at startup, select “Yes”.

Send Alarm at T meout

Select ”Yes” if the clock should send an alarm on the KNX bus at timeout. The default is “No”.

T meout Act on

As default, the timeout action is “Free run”. This means that clock will keep running using the local

clock in the case of a timeout. If “Reset to 2:00”, the clock will instead reset itself to 2:00.

KNX SLAVE CLOCK

Document:

DOK11027en01.doc

Author:

User Manual

Date:

2018

Page:

(

)

WESTERSTRAND URFABRIK AB

P.O. Box 133 Tel. +46 506 48000 Internet:: http://www.westerstrand.se

SE 545 23 TÖREBODA Fax. +46 506 48051 E mail: info@westerstrand.se

Clean ng the clock exter or

A clean clock is always a more representative product. The exterior should regularly be cleaned to maintain the

clock in good condition.

Cleaning solutions

Never apply cleaning solutions directly to components. Solutions are always sprayed on a cloth, and then the

cloth is used to wipe the component. Almost any type of household cleaner can be used to clean the outside of

the clock case. The cleaner should not dissolve or scratch the finish. When rubbing alcohol is used with cotton

swabs, the swabs should be moist, not dripping with solution. Avoid ammonia-based cleaners.

Techn cal data

Temperature range: 0C to +40C.

Humidity: 0-95% non-condensing

Supply voltage: KNX bus voltage SELV DC 29V

KNX bus current

consumption: 30mA

Housing

aterial: ABS / Aluminium

Protection class: IP20

Size: Ø 400 mm

KNX Bus electrical safety: SELV DC 29V

Pollution degree: 2

Intended use: Indoor, wall mount

Part numbers: KX4041448-00: Grey, A-type dial

KX4041448-90: White, A-type dial

KX4043448-00: Grey, H-type dial

KX4043448-90: White, H-type dial
