Western Digital WDBMBA0000NBK Instrucciones de instalación

Loaded with the best movie, TV and music apps

Play your photos and home videos in 1080p

Easy to set up, easy to use

Wirelessly stream the latest movies, trending

videos, hit TV shows, chart-topping music,

plus your personal media collection in Full-HD

1080p. WD TV Play is the most entertaining

way to make any TV smart.

Media Player

Get instant entertainment

on your TV.

WD TV®

PLAY™

Instant entertainment with your

favorite apps

Stream hit movies, view the latest

viral videos, catch up on TV shows,

stay connected to your social network

and watch highlights from the biggest

games of the season.

Ready, set, stream

Connect to your high-speed Internet

connection wirelessly, no PC required. Or

use the Ethernet port to connect to your

wired home network.

One-touch access to your

favorite entertainment

Use the remote to access your favorite

apps using the pre-programmed

buttons, or move them to the home

page of your customized screen. It’s as

easy as using your smartphone.

Turn your smartphone into a

touch-screen remote

Control your WD TV experience with

the swipe of a nger using the free

WD TV Remote™app. Available for

iOS™and Android™mobile devices.

Your media collection belongs

on the big screen

Enjoy your media library, home videos,

vacation slideshows, and favorite songs

on your HDTV and sound system in your

living room in Full-HD 1080p.

Enjoy media from any source

Stream videos, music, and photos from

your USB drive and any DLNA/UPnP™

network drive, PC or Mac®computer in

your home. You can also connect your

camera or camcorder.

High-performance,

streaming-ready Wi-Fi®

Includes the latest extended-range,

wireless-N technology to give you the

speed you need to stream HD.

Stay updated with news feeds

Stay posted on your favorite bloggers

and websites and stream the latest

audio and video with timely RSS feeds.

You can also add specic feeds to your

dashboard to be shown as tickers so

you never miss a thing.

WD TV PLAY

Media Player

Product Features

Product Specications

Western Digital, WD, the WD logo, WD TV and Put Your Life On It are registered trademarks in the U.S. and other countries; WD TV Play and WD TV Remote are trademarks of Western Digital Technologies, Inc. Other marks may be mentioned herein that belong to other companies. Pictures

shown may vary from actual products. Not all products may be available in all regions of the world. All product and packaging specications subject to change without notice. The term of your limited warranty depends on the country in which your product was purchased. Please visit our web

site at http://support.wdc.com/warranty for the detailed terms and conditions of our limited warranty and for a list of the specic countries in these regions.

4178-705523-A01 Dec 2012

INTERFACE DIMENSIONS REQUIREMENTS MODEL NUMBER

Ethernet

Wi-Fi (Wireless-N)

Height:

Depth:

Width:

Weight:

1.07 in ( 27.2 mm)

4.13 in (104.9 mm)

4.17 in (105.9 mm)

0.32 lb (0.14 kg)

Standard or high-denition television

with HDMI or composite video

connections.

Wireless network needed to enable

wireless capability. HDMI cable not

included.

Canada

Europe

WDBMBA0000NBK-HESN

WDBMBA0000NBK-VESN

WDBHZM0000NBK-EESN

WDBHZM0000NBK-UESN

CONTENTS OPERATING SPECIFICATIONS LIMITED WARRANTY

Media player

Remote control with batteries

Composite AV cable

AC adapter

Quick Install Guide

Operating temperature: 5°C to 35°C

Non-op. temperature: –40°C to 65°C

1 year

2 years

US/Canada

UK/EU

Media formats

AVI (Xvid, AVC, MPEG4, VC-1), MKV

(h.264, x.264, AVC, MPEG4, VC-1),

TS/TP/M2T/M2TS (MPEG4, AVC, VC-1),

MP4/MOV (MPEG4, AVC), WMV9, FLV

(AVC)

JPEG, GIF, TIF/TIFF, BMP, PNG

MP3, WAV/PCM/LPCM, WMA, AAC,

FLAC, MKA, AIF/AIFF, OGG, Dolby TrueHD

Playlist PLS, M3U, WPL, M3U8, XML, CUE

Subtitle SRT, ASS, SSA, SUB, SMI, MKV

(embedded sub)

MPEG4/H.264 Up to Main Pro¬le (MP) @ L4.2. Reference frame up to 4 frames.

An audio receiver is required for multi-channel surround sound digital output.

Please refer to user manual for specic limitations.
