Wenglor OPT2015 Manual de usuario

Available as PDF only

Status: 16.08.2018

www.wenglor.com

Operating Instructions

OPT2015

High-performance distance sensor

Index

1. Proper Use 4

2. Safety Precautions 4

2.1. Safety Precautions 4

2.2. Laser/LED warning 4

3. EC Declaration of Conformity 4

4. Technical Data 5

4.1. Connecting the Sensor 7

4.2. Housing Dimensions 8

4.3. The Control Panel 8

5. Mounting Instructions 8

6. Initial Start-Up 9

6.1. Initial Start-Up 9

6.2. Default Settings 10

7. Functional Overview 11

7.1. RUN 12

7.2. Pin Function 12

7.3. A1/A2/A3 Switch 12

7.4. A3 Error /A3 Input 15

7.4.1. A3 Error 15

7.4.2. A3 Input 15

7.5. A1 Analog/Analog 16

7.6. Offset 17

7.7. Measure Rate 19

7.8. Laser 19

7.9. Run Mode 20

7.10. Display 21

7.11. Language 21

7.12. Info 21

7.13. Reset 22

7.14. Password 22

8. Maintenance Instructions 23

9. Proper Disposal 23

1. Proper Use

This wenglor product has to be used according to the following functional principle:

High-performance distance sensor

High-performance distance sensors which use the principle of transit time measurement determine the dis-

tance between the sensor and the object according to the principle of transit time measurement. These sensors

have a large working range and are therefore able to detect objects over large distances.

Selected sensors are distinguished by WinTec (wenglor interference free technology). This technology allows

black or shiny surfaces to be reliably detected even in extremely inclined positions. It is possible to mount sev-

eral sensors next to or across from each other without them inﬂuencing each other.

2. Safety Precautions

2.1. Safety Precautions

• This operating instruction is part of the product and must be kept during its entire service life.

• Read this operating instruction carefully before using the product.

• Installation, start-up and maintenance of this product has only to be carried out by trained personal.

• Tampering with or modifying the product is not permissible.

• Protect the product against contamination during start-up.

• Not a safety component in accordance with the EU Machinery Directive.

2.2. Laser/LED warning

Laser Class 1 (EN 60825-1)

Observe all applicable standards

and safety precautions.

3. EC Declaration of Conformity

The EC declaration of conformity can be found on our website at www.wenglor.com in download area.

RoHS

LASER CLASS 1

EN60825-1

2007

4. Technical Data

Optical Data OPT2015

Working range 0,2…100,2 m

Working range analog 0,2…100,2 m

Measuring range 100 m

Reference reﬂector/reﬂector sheet 4 × OPT2030

Linearity 0,05 %

Switching hysteresis 13…50 mm

Light Source Laser (rot)

Wave Length 660 nm

Service life (amb. temp. = 25 °C) 100000 h

Laser Class (EN60825-1) 1

Beam Divergence < 2 mrad

Electrical Data

Supply Voltage* 18…30 V DC

Current Consumption (operating voltage = 24 V) < 100 mA

Switching Frequency 50 Hz

Response Time 10…200 ms

Measure Rate 1…100/s

Temperature Drift <0,5 mm/k

Temperature Range −25…60 °C

Number of switching outputs, conﬁgurable as

PNP, NPN or push-pull 3

Switching Output Voltage Drop < 2,5 V

Switching Output Switching Current 200 mA

Error Output yes

Error Output Switching Current 200 mA

Analog Output 0…10 V

Current Load Voltage Output <1 mA

Analog Output 4…20 mA

Current Output Load Resistance <500 W

Short Circuit Protection yes

Reverse Polarity Protection yes

Overload Protection yes

Resolution 4…20 mm

Mechanical Data

Adjustment Teach-In

Housing Plastic

Protection IP68

Connection M12 × 1, 8-polig

Protection Class III

* Supply voltage residual ripple may not exceed 10 % (within the speciﬁed voltage range).

Measuring Range:

The Sensors’ measuring range is determined by object remission and the size of the reﬂector.

Type of reﬂector Mounting distance

OPT2030 5...100 m*

0,2...10 m

* when using 4 reﬂectors

In order that the Sensor functions properly, the whole light spot of the Sensor has to hit the reﬂector. Please

chose the suitable reﬂector!

Light Spot Diameter

Working Distance 0 10 m 40 m 100 m

Light Spot Diameter 5 mm < 20 mm < 80 mm < 200 mm

Dependence of Hysteresis and Resolution on the Sampling Rate on white (90 % Remission)

OPT2015

Selected

sampling

rate in Hz

Default setting for min.

hysteresis in mm

Resolution in

100 40 20

50 35 14

20 30 12

10 25 10

5 20 8

2 15 6

1 13 4

4.1. Connecting the Sensor

514

Switching laser light off via pin connection:

If the “La” pin is open or connected to negative, the laser is on.

If positive voltage is applied, the laser is off.

Legend

Wire Colors according to

DIN IEC 757

Platinum measuring resistor

not connected

Test Input

Test Input inverted

Trigger Input

Analog Output

Ground for the Analog Output

Block Discharge

Valve Output

Valve Control Output +

Valve Control Output 0 V

Synchronization

Receiver-Line

Emitter-Line

Grounding

Switching Distance Reduction

Ethernet Receive Path

Ethernet Send Path

Interfaces-Bus A(+)/B(–)

Emitted Light disengageable

Magnet activation

Input confirmation

Contactor Monitoring

Encoder A/A (TTL)

Encoder B/B (TTL)

Black

Brown

Red

Orange

Yellow

Green

Blue

Violet

Grey

White

Pink

Green/Yellow

Supply Voltage +

Supply Voltage 0 V

Supply Voltage (AC Voltage)

Switching Output (NO)

Switching Output (NC)

Contamination/Error Output (NO)

Contamination/Error Output (NC)

Input (analog or digital)

Teach Input

Time Delay (activation)

Shielding

Interface Receive Path

Interface Send Path

Ready

Ground

Clock

Output/Input programmable

Power over Ethernet

Safety Input

Safety Output

Signal Output

Ethernet Gigabit bidirect. data line (A-D)

Encoder 0-pulse 0-0 (TTL)

Encoder A

Encoder B

Digital output MIN

Digital output MAX

Digital output OK

Synchronization In

Synchronization OUT

Brightness output

Maintenance

reserved

4.2. Housing Dimensions

4.3. The Control Panel

Display

Control key

5. Mounting Instructions

All applicable electrical and mechanical regulations, standards and safety precautions must be adhered to

when installing and operating the Sensor. The Sensor must be protected against mechanical inﬂuences. Install

the device such that its installation position cannot be inadvertently changed. The wenglor mounting system is

recommended for installing the Sensor. Additionally a suiting reﬂector or reﬂex foil has to be mounted.

6. Initial Start-Up

6.1. Initial Start-Up

Connect the Sensor to supply power (18 to 30 V DC). The display view appears.

The Sensor is ready for operation after 2 seconds. The following table provides an overview of typical, addi-

tional deviations during the warm-up phase.

Time (min.) 0 1 2 5 10 15

Deviation (mm) ±10 ±7 ±6 ±2 ±1 0

Switch to the conﬁguration menu by pressing any key.

Note:

If no settings are adjusted in the conﬁguration menu for a period of 30 s, the Sensor is automatically returned to

the read-out view. The Sensor accesses the last used menu view when a key is once again activated.

If a setting is adjusted, it becomes active when the conﬁguration menu is exited.

The keys are used for navigation, and for conﬁguring settings.

Important: Do not use any sharp objects to press the keys when configuring settings, because they might

otherwise be damaged.

Navigation up.

Navigation down.

Accept the selected setting, exit the menu (arrow points away from the display).

Acknowledge the selected menu item (arrow points towards the display).

6.2. Default Settings

OPT2015

Pin Function

A1: Switching output

A2: Switching output

A3: Error output

Outputs

Teach Mode Object

Switching threshold 1000 mm

Hysteresis 20 mm

Window Size 50 mm

PNP/NPN PNP

NO/NC NO

ON Delay 0 ms

OFF Delay 0 ms

Impulse 0 ms

Error Output PNP/NPN PNP

NO/NC NO

A3 Input invers

Analog

U/I U

0 V 200 mm

10 V 100200 mm

Offset Speciﬁcation Offset 0 mm

Measure Rate 20 Hz

Laser On

Run Mode Display Mode Distance

Display Intensity Screensaver

Language German

Password Enable Off

Enter 0
