WebGate HD400H Manual de usuario

HD-CCTV DVR

Install & User Guide

HD-CCTV DVR Manual.

Thank you for purchasing a Webgate Digital Video Recorder.

Before installation or operation please become familiar with the user manual and other referenced manuals

mentioned in the booklet.

User manual, software and hardware described here are protected by copyright by law. With the exception of

copying for general use within fair use, copying and reprinting of the user manual, either partially or in

entirety, or translating it into any another language without the consent of our Corporate office is strictly

prohibited.

Product Warranty and Limited Responsibility

The manufacturer does not assume any responsibility concerning the sale of this product and does not

delegate any right to any third party to take any responsibility on its behalf. The product warranty does not

cover cases of accidents, negligence, alteration, misuse or abuse. No warranty is offered for any attachments or

parts not supplied by the manufacturer.

The manufacturer does not assume any responsibility for followings

Malfunctions due to negligence by user

Deliberate disassembly and replacement by user

Connection of power source other than a properly rated power source

Malfunctions caused by natural disasters (fire, flood, tidal wave, etc)

The warranty period for HDD is one year

Any data damage due to HDD damage

The product is not for exclusive use of crime prevention but for assistance in cases as fire or theft. We

take no responsibility for damage from any incident.

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial

environment.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction

manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause

harmful interference in which case the user will be required to correct the interference at his own expense.

Correct Disposal of This Product (Waste Electrical & Electronic Equipment)

(Applicable in the European Union and other European countries with separate collection systems)

This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB

cable) should not be disposed of with other household waste at the end of their working life. To prevent possible harm to the

environment or human health from uncontrolled waste disposal, please separate these items from other types of waste and recycle them

responsibly to promote the sustainable reuse of material resources.

Household users should contact either the retailer where they purchased this product or their local government office, for details of where

and how they can take these items for environmentally safe recycling.

Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic

accessories should not be mixed with other commercial wastes for disposal.

Correct disposal of batteries in this product

(Applicable in the European Union and other European countries with separate battery return systems.)

This marking on the battery, manual or packaging indicates that the batteries in this product should not be disposed of with other

household waste at the end of their working life. Where marked, the chemical symbols Hg, Cd or Pb indicate that the battery contains

mercury, cadmium or lead above the reference levels in EC Directive 2006/66. If batteries are not properly disposed of, these substances

can cause harm to human health or the environment.

To protect natural resources and to promote material reuse, please separate batteries from other types of waste and recycle them

through your local, free battery return system.

Warning

Please do not bend or press power cord by force which could lead to fire.

Be careful not to pull

Do not pull power cord by force or with wet hands to avoid fire or electric shock.

In case of changing built-in lithium battery, it should be replaced with same brand or similar one to prevent

a danger of explosion. Since old batteries could be a factor of environment contamination, please disposed

of them properly.

Do not throw the batteries in fire or heating units. Neither short circuit nor disassembly is prohibited. Do

not recharge battery used for remote controller.

Do not open the top cover otherwise it could lead to electric shock and product damage.

The previous recorded data is deleted if record continues when HDD is full so please check disk setup

status.

Manufacturer takes no responsibility for any damaged data due to customer’s carelessness or negligence.

Caution

Do not place heavy objects on the top of the produc, it will damage the unit

Product is for indoor use only and it is not for outdoor use. Use product to its environmental specifications

(Temperature & Humidity). To clean the product, gently wipe the outside with a clean dry cloth.

Product uses AC power of 110V ~ 240V. Be cautious not to cause electric damages to the product.

Be careful not to drop the product. Physical shocks may harm the product including internal HDD. In

addition, please make sure the product is secured after installation.

Product is made of metal you can hurt another human if you throw or used as a weapon. Keep away from

the reach of children.

If Product does not operate properly, please contact the closest WEBGATE distributor for service. Tampering

or disassembling the product will void the warranty.

The product can transmit real time video over network or internet and can be used for monitoring purpose

based on installation. So please check and review related regulations before installation.

Experience and technical skills are needed for the installation of this product. Improper installation may cause

fire, electric shocks, or defects. Any installation job should be performed by the vendor you purchased this

product from.

The content of this manual can differ according to firmware or Software upgrading, and the standard and

appearance of products may be changed for the improvement of quality without an advance notice.

◈System Power Off

In case user turn off device by force while device is working, it could give damage on HDD and device so

please turn off device safely using power button located in the front panel.

◈Working Temperature

The working temperature of the product is 5°C~45°C or 41°F~113°F. Product may not work properly out of

recommended working temperature range for a long periods of time.

Please keep this product within recommended temperature range.

Contents

Warning 2

KEY FEATURES 5

Accessories 7

Description & Function 8

Connecting other devices 13

Usage 20

Use of Input/output devices 23

Menu Structure 26

Function Menu 26

Factory Reset 26

Basic Screen 27

Single Screen 27

Multi Screen 27

Screen Description 27

Auto Switch Mode(Sequence) 28

Event Screen 28

Zoom Screen Mode 28

Pause Live Screen 28

PTZ Control 28

Playback 30

Search Mode 31

Copy 32

System Set up 33

Network 42

Device Set up 44

Event Set up 48

Recording Set up 53

System requirement 58

Installation 58

User Set up 58

Monitor 59

Playback 63

Trouble Shooting [FAQ] 66

Compatible HDD 68

Factory Default 69

Menu Structure 72

Specification 74

Product Dimension 76

KEY FEATURES

FULL HD image supports

The product supports live monitoring and playback for HD-SDI

high quality video of 1080p (1920x1080) / 720p (1280x720)

resolution. Max 240 frames per second can be saved and Max

15 second recordable before event triggeres.

HD-SDI video record

HD400H model

-HD 1080p : 60fps

-HD 720p : 120fps

HD800H model

-HD 1080p : 120fps

-HD 720p : 240fps

Supports manual & schedule recording

Support archiving event list (Sensor, Video loss, Motion detection, Text)

Available record Max 5 seconds before triggering an event per each channel

FULL HD high quality video will be able to show superior resolution compared with SD video product. Over

1200 TV lines at 1080p resolution can be visible.

Full HD

D1 Resolution

1080P Resolution

720P Resolution

HD-SDI transmission

The product can transfer HD (High-Definition) signal image using HD-SDI technology via coax cable. Please

be noted that this product doesn’t accept SD signal. The supportable resolution is as below.

Transmission method

-SMPTE 292M : HD-SDI

Resolution

-SMPTE 296M : 1280x720p 25/30/50/60Hz

-SMPTE 274M : 1920x1080p 25/30Hz

Monitoring screen

Supports real live video with high resolution per each channel and variable display mode. Also

COVERT(hiding image) feature will secure privacy.

Various monitoring mode

Single, Multi screen division

Auto switching (Sequence)

Event Popup

Full HD : 1080p

HD : 720p

SD : D1

Live/Playback 16 times (horizontal 16x, vertical 16x) digital zoom supports (D-Zoom)

Audio recording

Supports real-time audio input and recording

Simultaneous 4ch audio input & recording available

Input : 4ch RCA, Output : 1ch RCA(Rear)

Simultaneous audio recording and playback available

Search / Playback

It supports variable and convenient functions for search & playback and FULL frame playback in 4 screen

multi division.

QUAD Multi Full Frame playback

Playback by time, Date, Channel

Time/Calendar/Event/Thumbnail search

Pre/Pose search from a freeze frame

Save and Backup

Internal HDD is supplied and image can be copied to DVD-R, CD-R, USB memory at user’s choice.

Various backup device supports : DVD-R, USB memory

HDD external unit (Expended external storage device) : Storage capacify extended via e-SATA HDD

or NVS04R

Network

It supports variable network like LAN, XDSL and easily control from remote site using web browser and

customized CMS program.

HD Live monitoring/playback/backup from remote site

Multi-streaming feature for slow network environment (CIF/Half-D1/D1 monitoring)

Event information(Image) transmission using E-Mail/Twitter/FTP

Playback in PC, save, search and DVR configuration feature via CMS

Available to search, playback and backup from remote site

Customized Android, Iphone application

10/100Mbps Ethernet/xDSL supports

Max 1024 DVRs management

ETC

Supports User friendly GUI and mouse function

Easy and simple firmware upgrade by USB memory

Record data backup function thru USB

PTZ control, PRESET support

Available to control up to 16 DVRs with one remote controller

Accessories

Check if below items are included.

DVR

Remote Controller

Mouse

Battery

Rack Bracket & Screw

Screw for HDD installation

AC code

SW & Manual CD

Quick Guide

User’s Manual

Description & Function

Front

1 3 6

4 5

7 8 11

Category

Function

DVD-Multi for backup

Back up use for recorded data by DVD/CD media

Jog / shuttle

Playback direction change and speed control.

Touch channel button

Select channel by touch during live and playback.

Channel LED

Shows image input status and event working status.

REC

To start and stop Manual record

LOCK

To lock the buttons on the front panel/remote controller in monitoring status

ESC

To exit menu or close pop-up window

To enter Menu

Record LED

Display recording status

Event LED

Display event status when event is triggered.

Copy LED

Display copy status once copy is under process by flickering

Network LED

Display network connection status by flickering

Internal HDD LED

It flickers while internal HDD is recording

ExternalHDD LED

It flickers while eSATA HDD is recording

FUNC button

Runs FUNC menu where user can use main menu, screen division, auto sequence, copy,

search, playback, keylock, logout, poweroff

SEAR button

Runs menu for search by time, calendar, event, thumbnail

COPY button

Runs menu for copy AVI, EXE thru DDVD, USB

RELAY button

Runs Relay On/Off manually

ZOOM button

Max 16 times zoon in live/playback screen and get into digital zoom mode

SEQ button

Runs Max 16 scenario of auto sequence in live mode

MULTI button

Changes division mode in live and playback mode

■(STOP)

Stop playback

◀l(SREW)

To move to reverse direction by one frame

◀◀(REW)

To move or select in menu and change replay speed to reverse direction in playback

mode.

◀▶(PLAY)

To select playback mode and change playback direction.

▶▶(FWD)

To move or select in menu and change replay speed to forward direction in playback

mode.

l▶(SFWD)

To move to forward direction by one frame

ll(PAUSE)

Pause playback

USB port

USB Memory, USB connection port

◀(Left move)

To move to left in menu

▶(Right move)

To move to right in menu.

▲(Upper move)

To move to upper in menu

▼(Down move)

To move to lower in menu.

Enter(select)

To select menu or enter the selected menu

Power

To turn On/Off power

Rear

2 3 4 5

7 8 9 10 1312 15

1411

In/Out port name

Function

Power connector

Socket for AC100V~AC240V power cord..

Sensor IN

Input for external sensor.

Relay

Relay Connection terminal.

Com2,3

RS-485 device connection

RS-485 termination

Set RS-485 termination

Ground

Ground between DVR & external device.

Channel input

BNC input for camera connection

Audio input(RCA)

RCA connection for Audio input

Audio output

Speaker output terminal.

Com1

RS-232C D-SUB..

VGA Output

Video output port to connect PC monitor.

HDMI Output

HDMI output port to connect PC monitor.

eSATA port

For eSATA external HDD connection

Storage

Connected to customized network

storagee device(NVS04R) for use

Ethernet

For network connection (RJ-45)

Remote Controller

It is available to use all functions of DVR. If several DVR

are set, each one can be set with unique ID number,

they can be controlled with one remote controller. To

use remote controller, it is necessary to set ID first.

Keep pressing ID button repeatedly (Up to Max. 16

times) and use it matching DVR & ID.

(Refer to the picture for remote controller working angle)

Otros manuales para HD400H

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de DVR de WebGate

WebGate

WebGate EH1600L Manual de usuario

WebGate

WebGate DS412 Manual de usuario

WebGate

WebGate HDC400M Manual de usuario

WebGate

WebGate HS1620F-PD Manual de usuario

WebGate

WebGate 480L Manual de usuario

WebGate

WebGate HS1600F-D Manual de usuario

WebGate

WebGate HD400H Manual de usuario

WebGate

WebGate MH1600H Manual de instrucciones

WebGate

WebGate Hybrid DVR Series Manual de usuario

WebGate

WebGate UHN1600-H2 Manual de usuario

WebGate

WebGate MD1600E Manual de usuario

WebGate

WebGate MD1600L eDVR Manual de usuario

WebGate

WebGate MH1600H Manual de instrucciones

WebGate

WebGate HD1600F-PDR Series Manual de usuario

WebGate

WebGate eDVR MD800M Manual de usuario

WebGate

WebGate MD1600L eDVR Manual de usuario

WebGate

WebGate MD1600H Manual de usuario

Manuales populares de DVR de otras marcas

FLIR

FLIR M3100E Series Manual de usuario

VTRACKPRO

VTRACKPRO FPRO300 Manual de usuario

Swann

Swann NVR-7085 models Manual de usuario

XtendLan

XtendLan DVR-1670C Manual de usuario

urmet domus

urmet domus 1093/004AHD Manual de usuario

Holux

Holux M1 Manual de usuario

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Manual de usuario

Whistler

Whistler D16VRS Manual de usuario

Defender Security

Defender Security 82-20235 Manual de usuario

MISUMI

MISUMI MP-WF100M Manual de usuario

Speco

Speco D8HU Manual de usuario

UST

UST DDR-E04AA Instrucciones de uso

Consolidated

Consolidated Digital Video Recorder Manual de usuario

Mace

Mace DVR0404RW Guía de inicio rápido

RCA

RCA RTD315W Manual de usuario

FSM

FSM Colibri Grande PRO Manual de usuario

Hauppauge

Hauppauge HD PVR 2 Manual de usuario

Identivision

Identivision ICR-PH161i PIONEER Manual de usuario
