WE-EF FLB141 #6 LED Manual de usuario

Surge Protection

This product features built-in surge protection circuitry in compliance with

applicable standards.

For comprehensive protection of a luminaire installation against lightning and

electrical surges, it is essential to cover mains supply and data input lines at

the distribution board level, by using respective primary (Type 1) and secondary

(Type 2) surge arrestors in compliance with EN61643-11/IEC61643-1.

Warning

Ensure that all required surge protection measures are in place and activated

prior to luminaire installation. Also, disconnect luminaires before operating

high-power devices such as, for example, electrical arc welders.

Do not open during installation

This product is factory-sealed.

Refer to the instructions contained in this

document for details.

WE-EF LEUCHTEN

Installation and Maintenance

Instructions

Floodlight with clamp

FLB141 #6 LED

FLB141 #7 LED

Floodlight with clamp

FLB141 #6 RAIL66 version

FLB141 #7 Space frame version

IP66, IK08, Class I, ta = 40°C

Weight kg

for FLB141 #6LED 3.9

for FLB141 #7LED 4.6

Windage area m²

for FLB141 #6 LED 0.040

for FLB141 #7 LED 0.045

Orientation: any

RAIL66

Light Source

LED

Maintenance

Apart from cleaning the product’s exterior surfaces, no special maintenance work is required.

Do not use high-pressure cleaners.

In case of component failure due to abnormal circumstances or at end of life, replacement must be carried out

E\DVXLWDEO\TXDOLƂHGDQGWUDLQHGSURIHVVLRQDO

Warning: Do not open luminaire while mains supply is switched on.

Installation

The product must be installed and maintained by a

VXLWDEO\TXDOLƂHGSURIHVVLRQDOLQFRPSOLDQFHZLWKODWHVW

building/construction and/or electrical regulations and

relevant legislation.

Warning: Switch off mains electrical supply prior to

installing and connecting the luminaire.

Notice:,IWKHOXPLQDLUHLVPRGLƂHGE\DQ\ERG\RWKHU

than the original manufacturer, then the warranty will

no longer be valid and shall become the full respon-

sibility of the modifying person/organisation. Claims

based on defects attributable to improper installation

and/or application, and the consequences thereof, are

excluded.

The installation on site must comply with local and/or

national health and safety regulations.

1) Switch off mains electrical supply.

Installation Procedure

Installation – RAIL66 version

Prior to installing the luminaire, mount and connect the selected RAIL66 mounting system in accordance with

relevant installation instructions

3) Determine desired position of luminaire A

on rail X, dependent on aiming requirements

and proximity to a suitable mains outlet Y.

4) Attach clamp Bto rail X. Tighten wingnut C.

2) Check that rating shown on luminaire label

conforms with mains electrical supply.

(example)

FLB141-LED 220-240V50-60/Hz

161-XXXX SOE XXXXXXX

LED 3000K 18W item no. XXX

07/18 IP66

5) Remove protective cover Zfrom mains outlet

Y. Insert in-line connector Gand tighten.

Attention: On any mains outlet Y’ that is not

used, protective cover Z’PXVWUHPDLQƂUPO\

VHFXUHG&KHFNDQGHQVXUHSURSHUƂWDQG

tightness.

6) Loosen screws Hand I slightly. Aim luminaire

in desired direction, retighten screws Hand I.

1) Switch off mains electrical supply.

Installation – Space frame version

Suitable for space frame diameter 48-60 mm.

4) Detach gear box cover Dby loosening screws S.3) Determine desired position of luminaire A

on space frame X, dependent on aiming

requirements. Attach clamp Bto space

frame X. Tighten wingnut C.

2) Check that rating shown on luminaire label

conforms with mains electrical supply.

(example)

FLB141-LED 220-240V50-60/Hz

161-XXXX SOE XXXXXXX

LED 3000K 18W item no. XXX

07/18 IP66

7) Reposition gear box cover Dand secure in

position by retighten screws S.

5) Feed mains supply cable Ethrough cable

gland G(Fig. I). 6) Connect mains supply cable Eleads to

respective terminals in terminal connector K:

a) ON/OFF (L = Phase, N = Neutral,

= Earthing)

b) 1-10 V/DALI (L = Phase, N = Neutral,

= Earthing, DA/DA = DALI control line,

D–/D+ = 1-10 V control line).

Tighten cable gland G.

Fig. I

8) Loosen screws Hand Islightly. Aim luminaire

in desired direction, retighten screws Hand I.

www.we-ef.com

WE-EF LEUCHTEN

Germany

Tel +49 5194 909 0

Fax +49 5194 909 299

info.germany@we-ef.com

WE-EF LUMIERE

France

Tel +33 4 74 99 14 44

Fax +33 4 74 99 14 40

info.france@we-ef.com

WE-EF HELVETICA

Switzerland

Tel +41 22 752 49 94

Fax +41 22 752 49 74

info.switzerland@we-ef.com



WE-EF LIGHTING

Thailand

Tel +66 2 738 9610

Fax +66 2 175 2174

LQIRDVLDSDFLƂF#ZHHIFRP

WE-EF LIGHTING

Australia

Tel +61 3 8587 0444

Fax +61 3 8587 0499

info.australia@we-ef.com

WE-EF LIGHTING

United States of America

Tel +1 724 742 0030

Fax +1 724 742 0035

info.usa@we-ef.com

TO9248W0519 © WE-EF 2019

7HFKQLFDOVSHFLƂFDWLRQVDUH

subject to change.

WE-EF LEUCHTEN

Installation and Maintenance

Instructions

RAIL66

Projector and Floodlight

Mounting System
