WCP GreyT Manual de usuario

GreyT Telescope - User Guide
(Rev 1)
Page 2
wcproducts.com
Table of Contents
Table of Contents
What is the GreyT Telescope? ���������������������������������������������������������������������������5
Calculating Tube Lengths ����������������������������������������������������������������������������������6
Tube Hole Patterns ��������������������������������������������������������������������������������������������7
GreyT Bottom Block Assembly Instructions ����������������������������������������������������9
GreyT Bottom Block - Step 1 ������������������������������������������������������������������ 10
GreyT Top Block Assembly Instructions �������������������������������������������������������� 11
GreyT Top Block - Step 1 ������������������������������������������������������������������������ 12
GreyT Top Block - Step 2 ������������������������������������������������������������������������ 13
GreyT Top Block - Step 3 ������������������������������������������������������������������������ 14
Gearbox Assembly Instructions ��������������������������������������������������������������������� 15
Gearbox - Step 1 ������������������������������������������������������������������������������������� 16
Gearbox - Step 2 ������������������������������������������������������������������������������������� 17
Gearbox - Step 3 ������������������������������������������������������������������������������������� 18
Gearbox - Step 4 ������������������������������������������������������������������������������������� 19
Gearbox - Step 5 ������������������������������������������������������������������������������������� 20
Gearbox - Step 6 ������������������������������������������������������������������������������������� 21
Gearbox - Step 7 ������������������������������������������������������������������������������������� 22
Gearbox - Step 8 ������������������������������������������������������������������������������������� 23
Gearbox - Step 9 ������������������������������������������������������������������������������������� 24
Gearbox - Step 10 ����������������������������������������������������������������������������������� 29
Gearbox - Step 11 ����������������������������������������������������������������������������������� 31
Telescope Assembly Instructions ������������������������������������������������������������������ 32
Telescope - Step 1 ���������������������������������������������������������������������������������� 33
Telescope - Step 2 ���������������������������������������������������������������������������������� 34

GreyT Telescope - User Guide
(Rev 1)
Page 3Table of Contents
wcproducts.com
Telescope - Step 3 ���������������������������������������������������������������������������������� 35
Telescope - Step 4 ���������������������������������������������������������������������������������� 36
Telescope - Step 5 ���������������������������������������������������������������������������������� 37
Telescope - Step 6 ���������������������������������������������������������������������������������� 38
Telescope - Step 7 (Non-Flipped) ���������������������������������������������������������� 40
Telescope - Step 7 (Flipped) ������������������������������������������������������������������ 41
Available Kits ��������������������������������������������������������������������������������������������������� 42
KIT-0018: GreyT 1 Stage Telescope (All �060” Wall) ����������������������������� 43
KIT-0019: GreyT 1 Stage Telescope (All �125” Wall) ����������������������������� 43
KIT-0020: GreyT 2 Stage Telescope (All �060” Wall) ����������������������������� 44
KIT-0021: GreyT 2 Stage Telescope (All �125” Wall) ����������������������������� 44
KIT-0022: GreyT 3 Stage Telescope (Mixed �060 &�125” Wall) ������������ 45
KIT-0023: GreyT 3 Stage Telescope (All �125” Wall) ����������������������������� 45
KIT-0024: GreyT 4 Stage Telescope (Mixed �060 &�125” Wall) ������������ 46
KIT-0025: GreyT 4 Stage Telescope (All �125” Wall) ����������������������������� 46
KIT-0026: GreyT Telescope Gearbox (Falcon, 10�61:1) ������������������������ 47
KIT-0027: GreyT Telescope Gearbox (Falcon, 15�34:1) ������������������������ 48
KIT-0028: GreyT Telescope Gearbox (Falcon, 20�25:1) ������������������������ 49
KIT-0029: GreyT Telescope Gearbox (Cim, 10�62:1) ����������������������������� 50
KIT-0030: GreyT Telescope Gearbox (Cim, 15�60:1) ����������������������������� 51
KIT-0031: GreyT Telescope Gearbox (Cim, 18�00:1) ����������������������������� 52
WCP-0416: GreyT Telescope Gearbox (Stages #1-4) ��������������������������� 53
WCP-0418: GreyT Telescope (Stage #1, 1�5” to 1”) ������������������������������ 54
WCP-0419: GreyT Telescope (Stage #2, 2” to 1�5”) ������������������������������ 55
WCP-0420: GreyT Telescope (Stage #3, 2�5” to 2”) ������������������������������ 56

GreyT Telescope - User Guide
(Rev 1)
Page 4Table of Contents
wcproducts.com
WCP-0421: GreyT Telescope (Stage #4, 3” to 2�5”) ������������������������������ 57
FAQ ������������������������������������������������������������������������������������������������������������������� 58
Revision Table ������������������������������������������������������������������������������������������������� 59

GreyT Telescope - User Guide
(Rev 1)
Page 5
wcproducts.com
Table of Contents
What is the GreyT Telescope?
The Greyt Telescope kit lets you make a linear telescoping system with little to no
effort. Up to 40 inches per stage, up to 4 stages, and more than enough power from the
Falcon 500 motor. Lock your telescope in place with either the Ratchet & Pawl or the
WCP Friction Brake. Use it for fast and secure climbs, or any other ne-controlled linear
mechanisms.
Notable features:
• Congurable, up to 4 stages.
• Easy to assemble and maintain.
• All bearings, no sliders.
• Integrated gearbox and mounting.
• Built in option for Ratchet & Pawl or WCP Friction Brake.
• Works with .060” and .125” tubing.
• No CNC machining required.
• Proper hardstops.
• Improved design, removes common failure point of internal bolts.

GreyT Telescope - User Guide
(Rev 1)
Page 6Table of Contents
wcproducts.com
Calculating Tube Lengths
The image below shows the equations for calculating the length of each tube. Each of
the moving stages are 1/4” longer than the preceding stage, and the rst stage is 1”
longer than the base tube.
Note: The max tube length for each stage (excluding the output stage) is roughly 40”�
The is due to the max safe extension of the CF Springs sold by WCP, which is 40”�

GreyT Telescope - User Guide
(Rev 1)
Page 7Table of Contents
wcproducts.com
Tube Hole Patterns
The holes in the bottom of the Base Tube and top of the Intermediate/Base Tubes
are used to pin the Top Blocks and Gearbox to their respective tubes. The holes in the
bottom of the Intermediate Tube are used to install the Bottom Blocks, Hardstops, and
CF Springs to their respective tubes. The top of the output tube will be determined by
the user. This is the recommended spot for the Telescope String to anchor to, as it is the
easiest place to do so.
Note: An easy way to anchor the string to the output tube is to drill a 3/8” hole in the
end of the tube and run a 3/8” OD shaft through for the string to be tied to.

GreyT Telescope - User Guide
(Rev 1)
Page 9Table of Contents
wcproducts.com
GreyT Bottom Block Assembly Instructions
Assembly instructions are interchangeable between the 1”, 1-1/2”, 2”, and 2-1/2” GreyT
Telescope Bottom Blocks.
Note: Blue Loctite (McMaster P/N 1004A12) is recommended on all bolts that thread
into a tapped hole�
1” Tube Bottom Block 1-1/2” Tube Bottom Block
2” Tube Bottom Block 2-1/2” Tube Bottom Block

GreyT Telescope - User Guide
(Rev 1)
Page 10Table of Contents
wcproducts.com
GreyT Bottom Block - Step 1
The size of the 1/4” ID bearings used in this step are determined by the wall thickness of
tube you are using. For 1/8” wall tube these bearings will be 1/4” ID x 1/2” OD bearings,
and for 1/16” wall tube these bearings will be 1/4” ID x 5/8” OD bearings.
There should be one Bearing Stack-Up for each slot in the GreyT Bottom Block you are
assembling; 4 for the 1” Tube Bottom Block, and 8 for the 1-1/2” to 2-1/2” Tube Bottom
Blocks.
1” Tube Bottom Block 1-1/2” to 2-1/2” Tube Bottom Block
