Installation Manual:
Undertile
Heating Mat
Components NOT included as part of your Warmup®
Undertile Heating Mat Kit:
The mat is available in 2 different wattages. Each mat is designed to pro-
duce a specific amount of heat based on its length. For this reason you
must never shorten the mat.
Specification for 150W Undertile Heating Mat
Mat Size(m2) Nominal Watts Amps@230v
1 150 0.65
1.5 240 1.05
2 301 1.31
3 420 1.83
4 601 2.61
5 827 3.59
6 918 3.99
7 1043 4.54
8 1319 5.74
9 1461 6.35
10 1618 7.03
11 1775 7.72
15 2250 9.78
Specification for 200W Undertile Heating Mat
Mat Size(m2) Nominal Watts Amps@230v
0.5 101 0.44
1 205 0.90
1.5 319 1.40
2 401 1.70
3 575 2.50
4 795 3.50
5 972 4.20
6 1245 5.40
7 1439 6.30
8 1546 6.70
9 1729 7.50
10 1909 8.30
NOTE:
The Warmup® XSTAT thermostat can switch up to 16
amps. If you are installing more than two heaters you
may require a junction box. (see Page 4 - Electrical
Considerations for details).
Specification for 150W Undertile Heating Mat
Mat Size(m2) Ohms@230VAC
0.5 352.70
1 220.00
1.5 176.00
2 126.00
3 88.00
4 64.00
5 57.60
6 50.70
7 40.10
8 36.20
9 32.70
10 29.80
15 23.51
Specification for 200W Undertile Heating Mat
Mat Size(m2) Ohms@230VAC
0.5 526.2
1 257.9
1.5 165.8
2 132.0
3 92.0
4 66.5
5 54.4
6 42.5
7 36.8
8 34.2
9 30.6
10 27.7
If at any time your readings are not
in line with the guidelines above,
or you suspect there is a problem,
please call the Warmup Technical
Helpline at 0845 345 2288
Please complete the control card in the back of the manual and
display at the consumer unit along with the installation instructions,
heater location/layout plan and any wiring diagrams as per 17th
Edition wiring regulations.
Name
Address
Post code Telephone number
E-mail
Installer name
Date of purchase Batch No. Serial No.
Please state which room the heater(s) is installed:
I
hereby
confirm that I have read and understand the contents of the
Installation Manual, and that the heater has been installed as specified therein.
I acknowledge that no claim can be brought against the manufacturer or its agents for any consequential loss or damage whatsoever.
I confirm that the heater was working prior to the commencement of tiling.
other
Kitchen Bathroom Conservatory Hall
Fill in your registration online at www.warmup.co.uk to choose your FREE GIFT.
