Operating Manual
Dear Customer,
Thank you for choosing a WALTRON daytime® LED light.
Your daytime® LED light is a high-quality product that was specially designed for aquatic and
terrarium applications. It satisfies the most demanding safety requirements.
The selection and design of the light's materials enables it to illuminate in the most adverse
conditions, even in saltwater aquariums.
The usage of modern, high-quality LEDs from a reputable supplier together with a heat removal
system guarantees that the light source will have a virtually unlimited service life. They also ensure
that the lighting will maintain the required energy efficiency for years to come.
The entire team at WALTRON wishes you a "bright" future with our daytime® lighting!
Notice, warning and safety symbols
The European Standard prescribes the use of the following symbols for specific situations; they
are not intended to unsettle the user.
They are a part of modern operating manuals for any electrically operated appliance.
General description:
Warning!
Serious injuries can result from an electric
shock if you do not follow the information
marked by this symbol.
NOTICE!
The daytime® products may malfunction or be
damaged if the information marked by this
symbol is not observed.
Info
Sections marked by this symbol contain
helpful recommendations and tips for using
the daytime® products.
Information for disposing of the product in an
environmentally responsible manner
Compliance with EC directives
Proper and intended usage
This product is designed for private home use. It is only intended as aquarium lighting and should
not be used for general lighting purposes.
Thus, this is not subject to the mandatory labelling requirements regarding energy efficiency
classification (refer to Regulation 874/2012 + 1194/2012).
Read and observe the entire operating manual before using the lighting for the first time. The
warranty does not cover damage or defects which have resulted from not observing the
information in the operating manual. Keep this operating manual accessible near the device. Make
sure that it is given to any subsequent users.
WALTRON assumes no liability for the consequences of improper usage.
For your safety
Warning! Carefully read and observe the
following important safety information. In
order to avoid an electric shock:
Position the device in a suitable place to
ensure that it is not exposed to water (from
condensation or falling into water).
Info! WALTRON recommends making
"drip loops" in the converter cables to prevent
water (condensation) from running along the
cable to the converter or outlet.
NOTICE! Make sure that all cables:
have no kinks in them,
are not routed over sharp edges, and
cannot be jammed or snagged,
cannot come into contact with hot
surfaces (> 60 °C).
Warning! If you notice that the power
cable is damaged, disconnect the device from
mains power supply immediately. Contact an
authorized daytime® service partner or the
manufacturer (WALTRON GmbH) directly.
Warning! If the operating device's power
cable or secondary cable(s) are damaged,
they must be repaired, either by an
authorized daytime® service partner or
directly by the manufacturer.
Never use a device which has a damaged or
defective power cable (operating device).
Warning! Never open or repair the
operating devices and lights by yourself. Do
not make any changes which are not
described in these operating instructions. The
operating device contains live (current-
carrying) parts (with 230 V AC). A fatal injury
can result from an opened device.
Repairs may only be carried out by
authorized daytime® service partners or by
WALTRON GmbH, using only original spare
parts and accessories.
We hereby confirm that the design and construction of the daytime® lighting series
matrix
complies with all relevant regulations, directives and safety requirements, as listed below:
Low Voltage Directive
2006/95/EG
Waste Electrical Equipment Directive
(WEEE) 2002/96/EC
EMC Directive
2004/108/EG
Product Safety Directive
2001/95/EG
ErP Directive (energy related design)
2009/125/EG
and the applicable standards
DIN EN 60598-1
Lighting – general requirements and tests
DIN EN 60598-2-11
Special requirements – aquarium lighting
DIN EN 62471
Photo-biological safety of LEDs
.......
Any changes in the lighting that are made without the approval of Waltron GmbH will invalidate
this declaration.
1) At least one matrix module and converter per lamp is required for operation
1. Scope of delivery
The standard delivery of the daytime® matrix includes:
1 pc. lamp, with 2-metre connection cable and protective panel
1 pc. "Inline" universal adapter set with rubber pads
1 pc. special key (tool for mounting and disassembling
the module, and for attaching the Inline adapter
system)
2. Required accessories1
NOTICE! Follow the instructions and notices concerning the installation and operation that
are included with the accessories.
The following accessories are available or required1 for setting up and operating the lighting:
2.1 matrix LED modules1
matrix module WW
Warm White
4,000 K
PAR: 4.73 μmol/s/watt
Power: 10 watts
matrix module NW
Neutral White
6,000 K
PAR: 4.50 μmol/s/watt
Power: 10 watts
matrix module UW
Ultra White
8,000 K
PAR: 4.30 μmol/s/watt
Power: 10 watts
matrix module UBRW
Ultra Blue Red White
Ratio of blue and red to white LED is
1:1:2
440-455 nm + 620-630 nm + 8,000 K
PAR: 4.26 μmol/s/watt
Power: 10 watts
matrix module UBW 1:1
Ultra Blue White 1:1
Ratio of blue to white LED is 1:1
440-455 nm + 8,000 K
PAR: 4.06 μmol/s/watt
Power: 10 watts
matrix module UBW 3:1
Ultra Blue White 3:1
Ratio of blue to white LED is 3:1
440-455 nm + 8,000 K
PAR: 3.94 μmol/s/watt
Power: 10 watts
matrix module BR
Royal Blue
440-455 nm
PAR: 3.81 μmol/s/watt
Power: 10 watts
matrix-Modul SLF
SunLike fresh
25% SunLike-LED Seoul Semi.
6.000 K + 440-455 nm + 620-630 nm
PAR: 4,39 µmol/s/Watt
Power: 10 watts
matrix-Modul SLM
SunLike marine
25% SunLike-LED Seoul Semi.
8.000 K + 440-455 nm
PAR: 4,06 µmol/s/Watt
Power: 10 watts
1) At least one matrix module and converter per lamp is required for operations.
2.2 Converter (power supply) including power supply cable1
"Premium" 24 V LED converter
40 watts
60 watts
90 watts
120 watts
180 watts
240 watts
1) At least one matrix module and converter per lamp is required for operation
3. Optional accessories
NOTICE! Follow the instructions and notices concerning the installation and operation that
are included with the accessories.
3.1 matrix adapter sets
matrix acrylic adapter set
For open aquariums
For placing on aquarium edges
matrix swing adapter set
For open aquariums
For placing on aquarium edges
matrix insertion/screw-on adapter set
For closed aquariums with terraced
levels
For screwing onto suitable surfaces
matrix T8 adapter set
For mounting into existing T8 lamp
holders
matrix T5 adapter set
For mounting into existing T5 lamp
holders
matrix magnet holder set
For attaching to magnetic surfaces
matrix wire suspension set
For hanging over open aquariums
matrix cross-connector set
For hanging two or three lamps over an
open aquarium
matrix Tetra AquaArt 100/130 adapter set
matrix Giesemann Sphera adapter set
matrix Aquatlantis adapter set
3.2 Adapter profiles for matrix
Adapter profile for JUWEL® aquariums
For converting to matrix
3.3 Design profiles for matrix
Design-Profiles: Top White/Black
For elegantly integrating the matrix into
open aquariums
Design-Profiles: Pendant White/Black
For elegantly integrating the matrix into
open aquariums using wire suspension
3.4 Light controls for matrix
Smart Control SC20 3-channel
Operating and programming using a
smartphone, tablet or PC
Basic Control BC16 1-channel
Operating and programming using
3 buttons
3.5 Distributor, adapter cables for matrix
2-way distributor
For operating two matrix lamps with a
converter or a light control unit
Adapter cables
5-pin female connector, wire-end ferrule
5-pin male connector, wire-end ferrule
Set for GHL LEDControl4 V2 / ProfiLux
Set for EHEIM LEDcontrol+
Extension cables
Length: 1 metre
Length: 2 metre
