VULCAN-HART COmpANy, p.O. BOX 696, LOUISVILLE, Ky 40201, TEL. 1-800-814-2028
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
A2780
ISO9001
Vulcan-Hart Co.
Item # __________________________
C.S.I. Section 11420
F-32636 (6-07)
MODEL: 1GPC12 GAS PASTA COOKER
STANDARDFEATURES
Stainless steel front and sides.
316 stainless steel tank, 12 gallon capacity. Includes limited
12 year tank warranty.
Set of four 6" adjustable casters (2 locking).
Overflow dam with skim port for starch removal and overflow
protection.
1" full port drain valve.
90,000 BTU/hr. input.
Temperature control adjusts from 190 to 212F. Power "ON",
"HEATING" and "HI-LIMIT" indicators.
Hi-limit shut-off.
Combination gas shut-off valve, pressure regulator and
electronic pilot ignition system.
1/2" rear gas connection.
Tank cleaning brush.
One year limited parts and labor warranty.
ACCESSORIES
Fine mesh stainless steel bulk cook basket.
Twelve section retherm basket with a set of twelve plastic
retherm portion cups. NSF approved.
Set of six individual 51/4" round fine mesh stainless steel cook
and retherm baskets with base screen.
3/4" x 4 ft. flexible gas hose with quick disconnect and restrain-
ing device.
MODEL 1GPC12
GAS PASTA COOKER
SPECIFICATIONS:
Gas pasta cooker, Vulcan-Hart Model No. 1GPC12. 316 stain-
less steel tank, 12 gallon capacity. Stainless steel front and
sides. Set of four 6" adjustable casters (2 locking). Overflow
dam with diameter skim port. 1" full port ball type drain valve.
90,000 BTU/hr. input. Temperature control adjusts from 190
to 212F. Power "ON", "HEATING" and "HI-LIMIT" indicators. Hi-
limit shut-off. Combination gas shut-off valve, pressure regulator
and electronic pilot ignition system. 1/2" rear gas connection.
Tank cleaning brush.
Overall dimensions: 151/2"w x 343/4"d x 471/8"h. Working height
361/4".
CSA design certified. NSF listed.
SPECIFY TYPE OF GAS WHEN ORDERING.
SPECIFYALTITUDEWHENABOVE2,500FT.
VULCAN-HART COmpANy, p.O. BOX 696, LOUISVILLE, Ky 40201, TEL. 1-800-814-2028
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and
specifications without notice.
F-32636 (6-07)
MODEL 1GPC12
GAS PASTA COOKER
IMPORTANT
1. A combination valve with pressure regulator is provided with this unit.
Natural Gas 4.0" (102 mm) W.C.
Propane Gas 10.0" (254 mm) W.C.
2. An adequate ventilation system is required for Commercial Cooking
Equipment. Information may be obtained by writing to the National
Fire Protection Association, Batterymarch Park, Quincy, MA 02269.
When writing refer to NFPA No. 96.
3. All models require a 6" (152 mm) clearance at both sides and rear
adjacent to combustible construction.
4. All models require a 6" (152 mm) minimum clearance to adjacent
open top burner units.
5. This appliance is manufactured for commercial installation only and
is not intended for home use.
OVERALL WORKING TANK TANK APPROX.
MODEL WIDTH DEPTH HEIGHT HEIGHT SIZE BTU/HR. CAPACITY SHP.WT.
1GPC12 15
1
/
2
" 34
3
/
4
" 46
1
/
4
" 36
1
/
4
" 14" x 18
1
/
4
" 90,000 12 gallons 250 lbs.
SERVICE CONNECTIONS: (casters fully extended)
P1 1/2" NPT pipe gas connection, 161/2" above floor.
P2 3/4" garden hose connection, 111/4" above floor.
P3 11/4" NPT drain connection, 117/8" above floor.
E1 Electrical connection, 120/60/1, 181/2" above floor.
