Vulcan-Hart VC6EC Manual de usuario

Item # __________________________

C.S.I. Section 11420

VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028

502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602

A2780

ISO9001

Vulcan-Hart Co.

F-32541 (03-08)

MODEL: VC6E Single Deck, Deep Depth Electric Convection Ovens

VC6E SERIES

SINGLE DECK, DEEP DEPTH

ELECTRIC CONVECTION OVENS

SPECIFICATIONS:

Single section, deep depth electric convection oven,

Vulcan-Hart Model No. (VC6ED) (VC6EC). Stainless steel

front, sides and top. Painted legs. Independently operated

stainless steel doors with double pane windows. Non-sag

insulation applied to the top, rear, sides, bottom and doors.

Porcelain enamel on steel oven interior measures 29"w x

261/8"d x 20"h. Two interior oven lights. Five nickel plated

oven racks measure 281/4" x 241/2". Eleven position nickel

plated rack guides with positive rack stops. Heated by electric

solid sheath elements rated at 12 KW. Furnished with a two

speed 1/2H.P. oven blower-motor. Oven cool switch for rapid

cool down. 208 or 240 volt, 60 Hz, 1 or 3 phase.

Exterior dimensions: 40"w x 461/4"d x 563/4"h on 253/4" legs.

Depth measurement includes door handles.

NSF listed. U L listed. U L listed to Canadian safety standards.

VC6ED Solid state temperature controls adjust from 150°

to 500°F. 60 minute timer with audible alarm.

VC6EC Computer controls with digital time and temperature

readouts. 99-hour timer with audible alarm. Roast

and Hold cycle. Six preset menu selections.

Shelf I.D. programming.

STANDARD FEATURES

■Stainless steel front, sides and top.

■Painted legs.

■Independently operated stainless steel doors with double

pane windows.

■12.5 total KW.

■1/2H.P. two speed oven blower-motor.

■Moisture vent damper control.

■Oven cool switch for rapid cool down.

■Porcelain enamel on steel oven interior.

■Five nickel plated oven racks with eleven rack positions.

■One year limited parts and labor warranty.

OPTIONS

Stainless steel legs.

Five hour timer in place of 60 minute timer (Model VC6ED).

Stainless steel open stand with storage rack.

Casters.

480V/60 Hz/1 or 3 phase.

Second year extended limited parts and labor warranty.

ACCESSORIES

Stainless steel rear motor enclosure.

Extra oven rack(s).

Rack hanger.

Stainless steel drip pan.

Stacking kit.

Model VC6ED

Printed On Recycled Paper

VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028

502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602

NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and

specifications without notice.

F-32541 (03-08)

NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and

specifications without notice.

OPTIONAL VOLTAGES:

480 volt, 60 Hz, 3 phase.

220/380 volt, 50 Hz, 1 phase, 3 wire.

220/380 volt, 50 Hz, 3 phase, 4 wire.

240/415 volt, 50 Hz, 3 phase, 4 wire.

NOMINAL AMPS PER LINE WIRE

TOTAL 3 PHASE LOAD 3 PHASE

MODEL CONN. KW PER PHASE 208 VOLT 240 VOLT 480 VOLT 1 PHASE

NO. KW X-Y Y-Z X-Z X Y Z X Y Z X Y Z 208V 240V

VC6E 12.5 4 4 4.5 35 33 35 33 29 33 14 15 15 60 52

VC6E SERIES

SINGLE DECK, DEEP DEPTH

ELECTRIC CONVECTION OVENS
