VR46 Kiddy Manual de usuario
User manual
English | Italiano | Español | Français | Deutsch | Polskie | Čeština | Slovenský | Português | Ελληνικά
electric scooter
English
Italiano
Español
Français
Deutsch
Polskie
Čeština
Slovenský
Português
Ελληνικά
01
28
55
82
109
136
163
190
217
244
Index
01
Electric scooter
User manual
Thank you for choosing this product.
For information, technical support and assistance, contact your reseller
or visit www.vr46e-mobility.com
For spare parts visit www.urbanemobility.com
English
02
Index
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
Safety instructions
Quick guide
Contents of the package
Product overview
Assembly and setup
Battery charging and activation
Brake adjustment
Autonomy
Storage and cleaning
General warnings
Learning to ride the scooter
Battery (Warnings)
Responsibility
Daily maintenance and care
Technical data sheet
Troubleshooting
03
1. Safety instructions
Please read the following instructions carefully before using the scooter. Keep this manual for future
reference or new users.
• The company shall not accept liabilities resulting from product misuse or from non-compliance with
trafcregulationsortheinstructionsprovidedinthismanual.
• This electric scooter is not a toy. Use it responsibly, with care and respect for others.
• Check local current regulations on the use of these products before riding it, and comply with local
trafcregulations.Rideresponsiblyandpayattentiontopeopleandobstaclestoavoidaccidents.
• Always use the recommended clothing: non-slip gloves, knee and elbow pads and wear a helmet.
• When holding the handlebars at the correct height, the person riding this scooter must be able to place
both feet on the ground easily.
•Whenstoppingorparkingyourvehicle,besuretodosoonaatandsafesurface
• The maximum load capacity for the scooter is 80 kg.
• This scooter may not be used by more than one person at a time.
• Misuse of the scooter or non-compliance with the instructions provided in this manual may cause
serious injury.
• Should technical problems occur, contact the Technical Support Service at your dealer.
• Do not attempt to disassemble or repair the scooter yourself.
•Donotleavethebatterynearreorheatsources.
• Avoid using used, defective and/or non-original batteries.
• Do not sit on the scooter both while riding it or when it is parked.
• If the user who is going to use the scooter is not familiar with this type of vehicle, they should be
instructedonthebasicsofdrivingbyanadultbeforeusingitforthersttime.Trainingshould
cover the following topics:
1. Acceleration
2. Deceleration
3. Braking
4. Basic riding principles
04
2. Quick guide
• Fully charge the scooter before using it for the first time.
• Press the power switch located on the right side of the footrest.
• If the battery is low, recharge it before use. The electric scooter is a device that requires
periodic charging.
• Place the electric scooter on a flat surface.
• Place your hands on the handlebars. Step onto the footrest with one foot and use the other
to give yourself a gentle push and accelerate.
• When the electric scooter begins to move, place both feet on the footrest and press
the accelerator.
• To steer the electric scooter, tilt your body in the direction of travel when turning and slowly
turn the handlebar.
• To stop the electric scooter, release the accelerator and press the electronic brake or lever
on the left side of the handlebar.
• Stop the electric scooter completely before getting off. Trying to get off the electric scooter
while it is moving may result in injury.
• Once the power switch is set to “ON”, the electric scooter will move when the throttle is rotated.
Before the throttle is rotated, make sure you are in an open area where it is safe to ride;
make sure you are balanced on the electric scooter, and have both hands on the
handlebar controls.
• Always make sure the power switch is set to “OFF” when the electric scooter is not in use.
Never store the product at a temperature that is near or below zero. Low temperatures will cause
permanent damage to the battery.
For your own safety, wear a helmet and knee pads to protect yourself against falls and injuries
while learning to ride the electric scooter.
The rider assumes all responsibility for any injury suffered when not wearing a helmet or other
protective gear.
05
3. Contents of the package
1x Charger
1x 2.5 mm hex wrench
1x 5 mm hex wrench
1x 10 / 8 mm wrench
1x 15 / 13 mm wrench
1x Screwdriver
Assembledelectricscooter;thehandlebarmustbettedusingthescrewsprovided.
06
4. Product overview
handlebar stem
drive wheel
rear wheel
charging port reset switchfront wheel
footrest
ON/OFF switch
accelerator
brake lever
07
5. Assembly and setup
Tools required: 5 mm hex wrench, 10 mm wrench
1. Press the switch located on the back of the fork and
insert the stem of the handlebar steering into the fork.
The switch should align with the positioning hole in the
handlebar stem and securely lock the stem in place.
2. Tighten the bolts using the 5 mm hex wrench and the 10
mm wrench. Tighten the bolts evenly and securely.
3. Align the handlebars both vertically and horizontally
(a) on the handlebar steering stem clamp (b), install the
handlebar clamp and components (c and d) and tighten
evenly and securely using the 5 mm hex wrench and the
10 mm wrench
08
The charging port is located on the left side of the footrest (see photo)
The device is usually delivered partially charged. However, we recommend
chargingitfor6to8hoursbeforeusingitforthersttime.
We also recommend charging it after each use and before storing it.
Do not allow the electrical scooter to fully discharge to avoid damaging the
battery.
6. Battery charging and activation
IMPORTANT
1. Make sure that the power switch, on the right side of the platform, is set to “0” before connecting the
charger. Connect the charger to the charging port, which is located on the left side of the footrest. Set the
switch on the right side of the footrest to “I”
2. Plug the charger into a wall power outlet. The light on the
charger housing should come on. A red LED light indicates
that the battery is charging whereas a green LED light
indicates that the battery is fully charged.
