Vpon VP-580 Manual de usuario
VP - 580
Digital Video Recorder
Software User Manual
Overview .....................................1
Introduction ........................................... 1
System requirements .............................. 2
Features ................................................. 2
About theGUI........................................ 4
ThelocalGUI ................................ 4
The networkGUI ........................... 4
GettingStarted ...........................5
Running modes ...................................... 5
Viewing live images on theVP- 580........... 8
IR remote control operation .......11
Introduction ........................................... 11
Main menu ............................................. 11
System setup.......................................... 12
Password protect .......................... 13
Video ............................................. 15
Disks ............................................. 17
TV output...................................... 18
OSDtext ........................................ 18
PTZ setup ..................................... 20
TCP/IP........................................... 21
Account........................................ 22
Audio............................................ 24
Serial ports .................................... 25
System information ....................... 26
Date/Time ...................................... 26
Alarm ............................................ 27
ISP................................................. 33
Registry server.............................. 34
Running mode............................... 35
Algorithm ...................................... 35
NTP setup ..................................... 35
Default settings............................. 36
Revisefirmware ............................. 37
Record setup.......................................... 37
DVR ............................................... 37
Record schedule ........................... 37
Motion detection .......................... 39
Pre-Alarm ...................................... 40
Playback ................................................. 39
Playback list .................................. 40
Table of Contents
Searching for a file ........................ 42
Locking files.................................. 43
Backing the data........................... 44
System Shutdown .................................. 45
The LocalGUI ............................46
Introduction ........................................... 46
Surveillance screen panel ....................... 46
PLAYbutton .......................................... 46
LIVEbutton............................................ 47
I/O button .............................................. 47
GO TO button ........................................ 48
STATUS button ..................................... 48
VIDEO .................................................... 49
PTZ panel ............................................... 50
Play panel ............................................... 51
Setup...................................................... 52
System setup ................................ 52
Record Setup ................................ 65
Alarm ............................................ 67
Motion detection .......................... 73
DVRnetworkoperation ...........74
Introduction ........................................... 74
Connecting ............................................ 74
Surveillance screen panel ....................... 76
Play button ............................................ 77
PTZ panel ............................................... 78
System Setup ......................................... 78
System information ....................... 79
Camera setting .............................. 79
Audio setting................................ 80
Set time and date ........................... 81
SetNTP server .............................. 81
System configuration .................... 82
Set names and on-screen display .. 82
Set user’s authority....................... 83
DVR setup ..................................... 84
Record schedule ........................... 84
Motion detection .......................... 85
Setpre-alarm ................................. 85
Playback........................................ 86
Sendmail ....................................... 87
FTP upload .................................... 88
Back to home page ................................. 88
View video without plug-ins .................. 89
Appendix .....................................90
This manual will guide you through the features and functions of the VP-
580 Network Digital Video Recorder (DVR) system. Read this section to get
an overview of the product.
1.1 Introduction
The FORMOSA21 VP-580 Network DVR System is a high performance digital
video recorder and web server all in one. Features include a real time video
capture utility, and video compression that allows efficient transmission of
moving images over a network.Video can also be displayed on a local VGA
monitor.The VP- 580 can record and play back digital video simultaneously
while continuing to display livevideo. Video footage is saved to a removable
hard disk.
Up to 8 cameras can be connected to a single VP- 580 unit. Full motion
video with audio over Internet or intranet is supported. Video output can be
viewed using a standard PC and web browser with custom plug-in software.
Camera pan, tilt, zoom, and focus functions can be controlled over the
network, and the unit can be configured to react a particular way to when
certain events occur. An IR remote control unit is included to make setup
and operation as trouble free as possible.
1.2 System requirements
Cameras
Composite CCD, V8, or camcorder
NTSC or PAL standard
1. Overview
2
Network equipment
RJ-45 Ethernet port and connection to Internet or intranet
(network mode)
Public or private IP address (Network mode and Internet access)
VGA monitor for local display
PC for configuration for remote viewing
Pentium IV 1.7GHz CPU or better
256MB RAM or more
AGP VGA card
Microsoft Windows XP/2000/ME/98 operating system
Standard Internet browser such as Internet Explorer
1.3 Features
Video and audio recording:
Up to 8 black and white, or color cameras
Up to 30 fps for each camera (local monitoring)
Record, playback and, display simultaneously
Built-in QUAD/multiplexor functions (local monitoring)
Local playback of recorded footage on VGA or TV monitor
Remote playback in PC browser
Query recorded data referenced by date, time, and event
Support for popular PTZ cameras
High video quality and low data rate
Up to 200:1 video compression
Multiple video compression engines including, H.263, JPEG,
M-JPEG, and MPEG4
System repuirements
3
Network
Dynamic IP support for Internet access
Direct dial-up support
Data storage and backup
Removable hard disk
Optional CD writer
Easy to use
Plug and play, non Windows embedded real-time OS
Easy configuration using either keyboard, mouse, IR remote
control, home page, or RS-232 terminal
The only client application required is a standard web browser
Alarm functions
Motion detection, event trigger, schedule, pre alarm recording
E-mail ,Voice Call and FTP alarm notification
Optional GPI/O for alarm control
Customization
HTML file upload support for home page customization
FTP server upload support for customization
1.4 About the GUI
The VP- 580 can be configured and operated using either the local GUI, or
over a network.
Features
4
1.4.1 The local GUI
1.4.2 The network GUI
About the GUI
2. Getting Started
Read this section to get your VP- 580 up and running. This section assumes
that the VP- 580 is already connected and cameras are attached. For more
information, see the user manual supplied with the unit.
Live footage can be viewed either on the local screen connected to the VP-
580 or over a network if a connection exists.
2.1 Running modes
Images can be viewed on the screen attached to the VP- 580. You can
control the number of images displayed on the screen and configure the VP-
580 using either mouse control, or IR remote controller.
Turn the VP- 580 on using the power switch on the rear of the unit and the
switch on the front panel.
The VP- 580 will boot up in either IR control or mouse control running
mode.
Note: The default startup mode for the VP- 580
is IR control mode. This can be changed by
setting the Running Mode option as described
later in this section.
Depending on how the VP- 580 is configured, you will see images from the
attached cameras on the screen.
If the VP- 580 is in mouse running mode, a graphical user interface (GUI)
with clickable buttons will be displayed on screen as shown below. In this
running mode, the IR remote control will not function. When the VP- 580 is
in IR remote control running mode, no GUI is displayed, only feeds from
the connected cameras.
6
Follow these instructions to switch from mouse running mode to IR remote
control running mode.
1.Click the SET UP button on the GUI to display the setup menu.
2. From the list on the left of the screen, click the Running Mode
heading to display the running mode menu.
Running modes
