VPI Industries Nomad Manual

VPI Industries, Inc., 77 Cliffwood Ave. #3B, Cliffwood, NJ 07721

http://www.vpiindustries.com http://facebook.com/vpiindustries

Setup and Instruction Manual

VPI Industries, Inc., 77 Cliffwood Ave. #3B, Cliffwood, NJ 07721

http://www.vpiindustries.com http://facebook.com/vpiindustries

NOMAD SPECIFICATIONS:

Type Belt drive (manual turntable)

Motor 24 VAC Synchronous AC Motor

Turntable Platter Machined MDF

Diameter 11.81" (30.0 cm)

Turntable Speeds 33-1/3 RPM and 45 RPM

Wow and Flutter 0.06% WOW (In accordance with DIN specification)

0.04% Flutter (In accordance with DIN specification)

Rumble <-80dB (IEC 98A Unweighted)

Effective Arm Length 9.9" (251.4 mm)

Overhang 0.65" (16.4 mm) Lofgren A

Offset Angle 21.8°

Arm Mass 10g (without cartridge)

Stylus Pressure Adjustment Range 0 - 3g (with 4 g cartridge)

Cartridge Ortofon 2M Red

Output 5.5 mV @ 1 KHz

Phono Preamplifier Gain 35 db

Cartridge Loading 150 pF Across 47K Ohms

Frequency Response 20 Hz –20 Khz (-0.5 db at 20 Hz)

Low Frequency Rolloff -1.4 db @ 10 Hz

Output Voltage (on RCA Jacks) 287 mV @ 1 KHz

Headphone Amplifier Gain 10 db

Frequency Response 20 Hz –20Khz (-0.4 db at 20 KHz)

Output Level 395 mW per Channel @ 150 Ohm

165 mW per Channel @ 32 Ohm

Power Supply 24 VAC @ 50 - 60Hz

Power Consumption 7.7W at full output with 32 Ohm headphones

Safety Approvals Built to meet UL6500, EN 60065

Dimensions 18.5" (470 mm) W x 13.5" (343 mm) D x 4.3" (109 mm) H

Weight 12.9 lbs. (5.9 kg)

VPI Industries, Inc., 77 Cliffwood Ave. #3B, Cliffwood, NJ 07721

http://www.vpiindustries.com http://facebook.com/vpiindustries

IMPORTANT: READ BEFORE PROCEEDING!

Read and follow the SAFETY INSTRUCTIONS below.

Save all packing materials. The Nomad should only be moved or shipped in its original packaging to

reduce the risk of damage in transit.

The Nomad must be placed on a flat, level surface. This will make setup easy, provide better sound

quality, and put less strain on the main bearing.

SAFETY INSTRUCTIONS:

Follow the instructions below to reduce risk of electrical hazard or

injury.

1. To avoid electrical shock, do not open the motor cover.

2. If the power cord provided with the Nomad does not reach an outlet, use a heavy-duty, grounded

extension cord.

3. To avoid electrical shock, always plug the Nomad into a grounded outlet.

4. Do not expose the Nomad to rain or excessive moisture.

INTRODUCTION:

The VPI Nomad is the first all in one high-end entry level turntable. Complete with a headphone amplifier,

phonostage, and pre-mounted Ortofon 2M Red cartridge on a 10 inch Gimballed/Yoke bearing, it is the

perfect solution to being enjoying your records! It also has standard RCA connections giving the ability to

hook up to a standard amplifier and desktop/floor standing speakers. The Nomad turntable is a precision

instrument. It has been thoroughly tested.

WARNING: The Nomad’s phonostage is not defeat-able and MUST NOT be plugged into another

phonostage. Doing so could result in serious damage to your speakers.

OPENING THE BOX:

The VPI Nomad is protected by custom designed foam packaging to make it easy to remove and begin

your listening experience. All foam parts easily lift off from the box. Make sure to save all packaging in

the event you ever need to safely ship your Nomad table.

VPI Industries, Inc., 77 Cliffwood Ave. #3B, Cliffwood, NJ 07721

http://www.vpiindustries.com http://facebook.com/vpiindustries

MOUNTING THE COUNTERWEIGHT:

To prevent shipping damage, the VPI Nomad is packed with the counterweight separate from the

tonearm. The Nomad comes with both a wrench and pre-placed red tape to set the tracking force.

Notice the red tape on the back of the arm

wand.

Slip the counterweight from the back onto

the tonearm until it lightly touches the red

tape.

Make sure the hole for the set screw is

facing up and tighten the screw with the

black wrench.

You may want to save the red tape after

setting the counterweight for the future. The

distance also measures roughly 1.44 CM

REMOVING THE CARTRIDGE GUARD

The Ortofon 2M Red cartridges pre-mounted on the Nomad comes with a

cartridge guard to protect the stylus. To remove the guard (while facing

the Nomad) gently press the tab of the guard towards you to release and

remove.

Once you have mounted the Nomad tonearm counter weight and have removed the Ortofon 2M Red

cartridge guard you may remove the blue protective film on top of the headshell. You may also carefully

remove the blue wire tie.

CHANGING SPEEDS:

The VPI Nomad comes with a two speed pulley, 33 and 45. To adjust the speeds simply move the belt

from one pulley groove to another.

VPI Industries, Inc., 77 Cliffwood Ave. #3B, Cliffwood, NJ 07721

http://www.vpiindustries.com http://facebook.com/vpiindustries

CONNECTING TO THE PREAMPLIFIER/AMPLIFIER

Only use interconnects that are shielded and properly grounded. Non-shielded can hum.

The ground connection is available to eliminate hum if necessary. If hum is present, first connect a

ground lead from the connector block to the preamplifier or amplifier to which the output cable is

connected. If this does not eliminate the hum, run a ground wire from the turntable chassis to the

connector block as well. The block's connector will accept bare wires, spade lugs, or ring tongue

connectors.

Do NOT plug the Nomad into an external phonostage!

Doing so could possibly damage your speakers!

PLAYING RECORDS

Make sure the black felt mat that comes

standard with the Nomad is secure.

If using headphones, plug your

headphones into the headphone amplifier

located in the front left of the Nomad. Be

sure to set your volume at a preferred level

before listening.

Press the power button and sit down and

enjoy listening to your records with.

GENERAL USE

Allow at least 20 hours of break-in time.

The motor will make some low-level noise. This will not get into the system. The motor and bearings

will become quieter as you use your Nomad.

RECOMMENDED UPGRADES (SEE YOUR LOCAL DEALER)

VPI Anti-Static Mat (or other third party mats of your preference)

HR-X Center Weight

Ortofon 2M Blue, Bronze, or Black (other cartridges can be used but the 2M series is compatible

and easy to use with the Nomad)
