VOLYA VENT Manual de usuario

Technical certificate

Assembly manual

р.2-3

р.3-12

VENT

for the greenhouse “Ministar”

Quality management system (QMS)

of LLC «Volya» is certied

for compliance with

standard of

ISO 9001:2008

Certied by

Russian Registry

Warranty liability

1. The manufacturer bears responsibility for the vent

complete setup.

2. The manufacturer bears responsibility for the vent

assemblability in accordance with the manual

3.Claim submission period is 12 months from the

date of the purchase.

Warranty conditions

Warranty liabilities do not apply to the cases of:

1 .the vent installation with violation of requirements

of the manual

2. the violation of the operating rules

3. hurricanes and other natural disasters.

The manufacturer: OOO Volya, 8 Severny lane, Dubna, Moscow region, 141983, Russia

Telephones: 8(495)598-5-999

www.teplicy.ru e-mail: info@perchina.ru

The manufacturer bears responsibility for the quality of products in accordance with RF CC.

The manufacturer reserves the right for vent engineering design changes.

Manufactured date:

Description

The vent is designed to ventilate the greenhouses. The frame of the vent sash is

made of galvanized steel and it is assembled with screws and nuts. The kit part of the

vent includes all necessary elements of clamps.

Follow the greenhouse assembly instructions and use it in strict accordance

with the manual and operating rules stated in the technical certificate.

Please keep the technical certificate for further reference.

marking name

quan

tity,

pcs

Isohyps vent member

(20х20)

0,44 m

1-1

Isohyps vent member

(20х20)

0,44 m

Vertical vent member

(20х20)

0,49 m

3Bearer

(20х20) 1

3-1 Bearer

(20х20) 1

Small part of

heave-off hinge 2

Larger part of

heave-off hinge 2

Weather strip

0,44 m 2

Weather strip

0,52 m 2

Weather strip 0,45 m 2

Weather strip 0,62 m 2

Window security chain 1

Scotch tape 25 mm 1

Aluminum tape 1

Wire extender 1

Wire stop 1

name

quan

tity,

pcs

Screw

М4х30 4

Screw

М4х50 1

Screw

М5х45

Screw

М5х30 8

Screw

М6х30 4

Self-tapping

screw

4,2х16

Self-tapping

screw

4,8х19

Nut М4 8

Nut М5 8

Nylstop nut М5 2

Washer 4 2

Bracket 1

Clamp 2

Locking pipe 1

х1

M4x30

М4

1-1

х1

M6x30

х1

M6x30

х1

M6x30

х1

M6x30

х1 х1

M5x45

М5

х2

M5x30

М5

х2 х1

х1

х5

M4x30

М4

х1

M4x50 х1

Tape scotch on the cut sides

of the polycarbonate sheets.

3-1

х1

М4

х1

425 ≈85

605mm

≈33

425

≈40

3-1

х4

580 mm

400 mm

х2

х14

450 mm

7..9 mm

604 mm

620 mm

450 mm

7..9

7..9 mm

6х8

Aluminum tape

х1

х2

M5x30

М5

х2

х1

х2

THIS MANUAL CANNOT BE REPRODUCED IN ANY FORM, IN WHOLE OR IN

PART, WIHOUT AN EXPRESS WRITTEN PERMISSION OF «VOLYA» COMPANY

Manufacturer:

Volya LLC, Dubna, Moscow region

phone/fax: 8 (495) 598-5-999

www.teplicy.ru

e-mail: [email protected]
