Volvo 2010 XC60 Manual de usuario

CITY SAFETY™

City Safety™ is intended to help a distracted

driver in a critical situation immediately prece-

ding a collision.

The function is active at speeds ranging from

approximately 2-18 mph (4-30 km/h) and

assists the driver by monitoring the traffic

ahead using the laser sensor mounted in the

upper edge of the windshield.

City Safety™ can help prevent a collision if

the difference in speed between your vehicle

and the vehicle ahead is less than 9 mph (15

km/h). If the difference in speed is greater, a

collision cannot be avoided but the speed at

which the collision occurs can be reduced.

City Safety™ is designed to intervene as

late as possible to help avoid unnecessary

activation.

WARNING

City Safety™ is a supplemental aid to the

driver. It can never replace the driver’s

attention to trafﬁc conditions or his/her

responsibility for operating the vehicle in

a safe manner. City Safety™ may never

be used instead of the driver applying the

brakes.

City Safety™ does not function in all driving

situations or in all trafﬁc, weather or road

conditions.

REMOTE KEY, PCC PERSONAL CAR

COMMUNICATOR*

Locks the doors and tailgate and

arms the alarm.

Unlocks the doors and tailgate, and

disarms the alarmA

Unlocks the tailgate.

Approach lighting illuminates lights in

door mirrors, cabin, footwells, license

plates. Turn signals and parking lights

illuminate.

“Panic” alarm.

– Press and hold to sound the alarm.

Turn off alarm with unlock button.

AAutomatic relock occurs if no door/tailgate is opened

within 2 minutes after unlock.

PCC*

Information about the car can be

gathered within a range of 65 ft. (20 m).

– Press the button and wait for 7 seconds.

If the car is out of range when the button is

pressed, the most recently stored status

information will be shown.

Green light: Vehicle is locked.

Yellow light: Vehicle is unlocked.

Flashing red light: Someone may be in

the vehicle.

Red light: Alarm has been triggered.

– Press the START/STOP/

ENGINE button to start the

engine

STARTING THE ENGINE

– Insert the remote key as shown in the

illustration, with the buttons upward and push

lightly on it – the key will be drawn into the

lock.

– Press the brake pedal.

COLDSTART

NOTE

After cold starts, your engine will idle at a

higher speed for a short time.

IGNITION MODES 0 AND I

To access the following ignition modes: The

brake pedal must not be depressed.

SWITCHING OFF THE ENGINE AND REMOVING THE REMOTE KEY

2. Press lightly on the remote key. It will be par-

tially ejected from the ignition slot. The gear

selector must be in the Pposition.

Mode Active functions

Remote key inserted but not drawn

into ignition slot – audio system and

courtesy lighting.

Remote key drawn into ignition

slot – audio system and courtesy

lighting. Instrument/clock lighting,

steering wheel lock/unlocked.

Remote key drawn into ignition slot

and START pressed briefly – power

moonroof/windows, blower, ECC,

wipers, 12-volt sockets in center

console, Volvo Navigation System*.

To exit ignition modes 0/Iand turn off the

vehicle’s electrical system: Press in the

remote key. It will be partially ejected from the

igntion slot.

1. Park the vehicle and press

the START/STOP ENGINE

button to switch off the

engine.

Press for on/off.

Turn to adjust volume.

Select AM, FM1, FM2, CD, or MODE.

Use MODE to activate Sirius satellite

radio*, the accessory iPod interface or

AUX for e.g.A

Sound settings

Press to select e.g., BASS, TREBLE, etc.

– turn to adjust.

BLUETOOTH®

Make the cell phone searchable/visible.

Press the PHONE button on the audio sys-

tem control panel briefly.

Select “Add phone” in the audio system

display.

Select the cell phone to be connected.

Enter the numbers shown in the audio sys-

tem display using the cell phone’s keypad.

A. AUX connector for e.g., mp3 player. Set mp3 player’s volume

to medium for best sound quality.

RADIO

Turn to select a radio station.

Search for stations with the left/right ar-

rows. Store up to 20 stations by holding

in buttons 0–9 in FM1 och 0–9 in FM2,

until the stored station is confirmed in the

display.

Autostore stations by pressing for 2 se-

conds. Autostoring... is displayed during

the search. The 10 strongest stations are

stored. Press 0–9to select a station.

CD PLAYER

Turn to change tracks.

Change tracks with left/right arrows.

Select CDBwith up/down arrows.

Press to eject current CD.

Press and hold to eject all CDsB

CD selectB. Press 1–6.

BOptional CD changer only.

HD RADIO

HD radio reception is subject to coverage limi-

tations. See your Owner’s Manual for details.

AUDIO SYSTEM

EMERGENCY BRAKE ASSIST (EBA)

EBA is designed to provide full brake effect

immediately in the event of sudden, hard

braking. When EBA is activated, the brake

pedal will go down more than usual.

– Press and hold the brake pedal for as long

as necessary – there will be no braking ef-

fect if the pedal is released.

CAR CARE

Hand washing is gentler on the paint than an

automatic car wash. Since the paint on a new

vehicle may take several months to harden

completely, we recommend washing the

vehicle by hand during this period. Use clean

water, a suitable car washing detergent and

a sponge. Keep in mind that dirt or grit on the

sponge can scratch the paint.

ELECTRONIC CLIMATE CONTROL (ECC)

MANUAL CONTROL

Blower speed.

Air distribution.

Heated driver/front passenger seat*.

Recirculation

Defroster to quickly defog the windshield

and side windows.

Heated rear window and door mirrors.

Air conditioning Off/On to cool the cabin

and defog the windows.

The 12-volt sockets in the cabin function in

ignition positions Ior II.

The 12-volt socket* in the cargo area always

functions.

AUX/USB* can be used to connect e.g., an

mp3 player to the vehicle’s audio system.

STORAGE SPACES, 12-VOLT SOCKETS & AUX/USB* CONNECTOR

CAUTION

Using the optional 12-volt socket in the

cargo area with the engine switched off will

drain the battery.

AUTOMATIC CONTROL

In AUTO mode, ECC controls all functions

automatically and makes driving more pleasant

with optimal air quality.

Turn the control to the desired temperature

on the left/right sides of the cabin. The set

temperature is shown in the display.

Press to automatically control the tempera-

ture and other functions.

8 9

ODOMETER AND TRIP COMPUTER

STEERING WHEEL ADJUSTMENT REFUELING

WARNING

Never adjust the steering wheel while

driving.

– Press the button to unlock the fuel filler door.

Low fuel level indicator

When the symbol illuminates, refuel as

soon as possible.

The display shows two separate trip odo-

meters, T1 & T2.

Fuel gauge

The fuel filler door is on the right, as indi-

cated by the arrow.

Trip computer display. Select function with

(8).

Clock

Adjust with (6).

Multi-function control

Turn the control clockwise or counter-

clockwise to set the clock.

A short press toggles between T1 & T2.

A long press resets the displayed odome-

ter.

Press to display or erase a message.

Turn to show trip computer information

alternatives.

A short press resets current function.

A long press resets all functions.

NOTE

The display text Miles to empty tank is an

approximation, based on recent average fuel

consumption.

LAMINATED PANORAMIC ROOF*

The 1st press on the control operates the sun

shade; the 2nd press operates the laminated

panoramic roof. The sun shade must be fully

open before the laminated panoramic roof

POWER TAILGATE*

Opening

– Press the button on the lighting panel/remote

key until the tailgate begins to open.

– The tailgate can also be opened by pulling

the handle on the tailgate.

Closing

– Press the closing button on the tailgate or

close the tailgate manually.

can be opened manually. When the laminated

panoramic roof is opened to the tilt (ventilation)

position, the sun shade opens/closes automa-

tically.

Auto open

Manual open

Manual close

Auto close

Open to the tilt position

Close from the tilt position

High beam flash.

Toggle between high/low beams.

LIGHTING PANEL

Display & instrument panel lighting.

Front fog lights.

Rear fog light (driver’s side only).

Automatic headlights. High beam flash

only.

Parking lights.

Headlights: turn off when ignition is

switched off, high/low beams.

ADJUSTING THE FRONT SEAT

ELECTRIC PARKING BRAKE

Lumbar support.

Backrest tilt.

Raise/lower the seat.

Raise/lower the front edge of the seat

cushion.

Forward/rearward.

Folding down the passenger’s seat back-

rest.

Setting

– Press the button. The light flashes until the

brake is fully applied, then glows continu-

ously.

Releasing

Ignition mode 0or higher.

Press the brake pedal and pull out the but-

ton.

Release automatically

– Select a gear and begin driving. The parking

brake will release automatically (the driver’s

seat belt must be fastened).

TIRE PRESSURE MONITORING

SYSTEM (TPMS)*

When a low tire pressure warning message

(Low tire press. check tires or Very low tire

pressure) has been displayed and the tire

pressure warning light ( )has illuminated,

one or more tires has low inflation pressure.

Check the inflation pressure of all four tires

with a tire pressure gauge as soon as pos-

sible and pump the tire(s) with low pressure

to the recommended inflation pressure.

Refer to the inflation pressure tables in the

section “Wheels and tires” in the Owner’s

Manual.

BLIND SPOT INFORMATION

SYSTEM (BLIS)*

If the BLIS indicator lights illuminate even

when there are no vehicles in the blind area,

this may be due to light reflected from a

wet road surface, the vehicle’s own shadow

against a large, light, smooth surface, or

sunlight directly in the camera when the sun is

low on the horizon.

In the event of a fault, Blind spot syst.

service required will be displayed. See the

Owner’s Manual for other BLIS-related mes-

sages.

WELCOME TO THE GLOBAL FAMILY OF VOLVO

OWNERS!

Getting to know your new vehicle is an exciting experience.

This Quick Guide provides a brief overview of the most common features and

functions in your Volvo.

However, for the most up-to-date and detailed descriptions and instructions,

as well as important warnings and other information not included in this

folder, please refer to your Owner’s Manual.

An asterisk (*) indicates optional equipment.

For additional information, contact Customer Service:

U.S.A.: 1-800-458-1552 www.volvocars.us

Canada: 1-800-663-8255 www.volvocanada.com

VOLVO XC60

Quick guide

Otros manuales para 2010 XC60

Tabla de contenidos

Otros manuales de Automóvil de Volvo

Volvo

Volvo S90 - ACCESSORY PANEL Manual de usuario

Volvo

Volvo XC60 - ANNEXE 541 Manual de usuario

Volvo

Volvo V70 SPORT Manual de usuario

Volvo

Volvo C70 Manual de usuario

Volvo

Volvo XC90 Twin Engine 2019 Manual de usuario

Volvo

Volvo C70 Manual de usuario

Volvo

Volvo XC60 2011 Guía de inicio rápido

Volvo

Volvo V90 CROSS COUNTRY Manual de usuario

Volvo

Volvo XC60 - ANNEXE 541 Manual de usuario

Volvo

Volvo XC90 2020 Manual de usuario

Volvo

Volvo S 80 Manual de usuario

Volvo

Volvo V60 TWIN ENGINE 2019 Manual de usuario

Volvo

Volvo 262 Manual de usuario

Volvo

Volvo XC40 Twin Engine Manual de usuario

Volvo

Volvo V70 SPORT Manual de usuario

Volvo

Volvo S80 - Manual de usuario

Volvo

Volvo V70 SPORT Manual de usuario

Volvo

Volvo XC70 2013 D5 AWD Guía de inicio rápido

Volvo

Volvo V70 SPORT Guía de inicio rápido

Volvo

Volvo V50 Manual de usuario

Volvo

Volvo C30 2012 Guía de inicio rápido

Volvo

Volvo V70XC Cross country 1998 Manual de usuario

Volvo

Volvo XC60 - ANNEXE 541 Manual de usuario

Volvo

Volvo V90 CROSS COUNTRY Manual de usuario

Manuales populares de Automóvil de otras marcas

Toyota

Toyota 2000 Tundra Manual de usuario

CITROËN

CITROËN DS4 DSign Manual de usuario

Lexus

Lexus 2015 CT 200h Manual de usuario

Cadillac

Cadillac CTS 2008 Manual de usuario

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manual de usuario

Porsche

Porsche Boxster S Manual de usuario

GMC

GMC 2010 Savana 1500 Cargo Manual de usuario

KIAM

KIAM SPORTAGE 2014 Manual de lista de piezas

GMC

GMC 2013 Terrain Instrucciones de montaje

GMC

GMC T-Series 1999 Manual de usuario

Mercury

Mercury 1998 Mystique Manual de usuario

Mercury

Mercury 2007 Mariner Manual de usuario

Mazda

Mazda 2007 Mazdaspeed 3 Guía

Mazda

Mazda 2014 CX-5 Manual de usuario

GMC

GMC Chevrolet Express 2022 Manual de usuario

GMC

GMC 1997 Jimmy Manual de usuario

Chevrolet

Chevrolet 2012 Malibu Manual de usuario

Cadillac

Cadillac 2010 Escalade Manual de usuario
