Volt 3602 Series Manual de usuario

VOLT®Line Voltage Landscape Lighting

VOLT®Estate Size Path & Area Lights

3602 Series

INSTALLATION INSTRUCTIONS

Specications and product details subject to change without notice.

[email protected] • 813.978.3700

Help Hotline:

1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)

- 1 -

VOLT®Estate Size Path & Area Lights

3602 Series

Important: Please Read Before Installation

Important Safety Instructions

INSTALLATION INSTRUCTIONS

To avoid the risk of re, explosion, or electric shock, this product should

be installed, inspected, and maintained by a qualied electrician only, in

accordance with all applicable electrical codes.

To avoid electric shock:

1. Be certain electrical power is OFF before and during installation and

maintenance.

2. Luminaire must be connected to a wiring system with an equipment-

grounding conductor.

To avoid explosion:

1. Make sure the supply voltage is the same as the rated luminaire

voltage.

2. Do not install where the marked operating temperatures exceed the

ignition temperature of the hazardous atmosphere.

3. Do not operate in ambient temperatures above those indicated on the

luminaire.

For supply connections use wire rated for at least 90°C (194°F)

Warning: these luminaire should ONLY be installed by a qualied electrician.

LIGHTED LAMP IS HOT!

WARNING – TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS.

1. Turn o/unplug and allow to cool before reducing lamp.

2. Lamp gets HOT quickly!

3. Do not touch the hot lens, guard or cowl.

4. Keep lamp away from materials that may burn.

5. Do not touch lamp at any time.

6. Use a soft cloth.

7. Oil from skin may damage lamp.

8. Do not operate the xture with a damaged or missing lens or shield.

www.voltlighting.com

- 2 -

Package Contents

Product Dimensions

A. (1) Fixture Body

[email protected] • 813.978.3700

- 3 -

10.25”

38.5”

6”

3”

6”

3”

10.25”

6”

3”

9”

38.5” 36”

www.voltlighting.com

INSTALLATION INSTRUCTIONS

- 4 -

VOLT®Estate Size Path & Area Lights

3602 Series

Remove Stem Top

Loosen the stem top and remove

it from the top end of the stem.

Stem

Stem Top

Install Bulb

Insert the bulb with the correct

wattage and type marked on the

xture label and push rmly into

place.

CAUTION: Do not exceed maximum

wattage marked on luminaire label.

Socket

Bulb

[email protected] • 813.978.3700

- 5 -

Thread the stem top onto the

stem and hand tighten until

snug.

Install Stem Top

Stem Top

Stem

Install Stake and Conduit

Dig a hole in the ground for the conduit runs and the stake. Install the

conduit. Slide the stabilizer grid onto the stake and secure with the

screws. Place the stake over the conduit runs then backll against the

mounting stake.

Stake

Stabilizer

Grid

Conduit

Ground Level

INSTALLATION INSTRUCTIONS

www.voltlighting.com

- 6 -

Remove the cap from the stake

by loosening the set screws.

Remove Cap from Stake

Set Screw

Cap

Stake

VOLT®Estate Size Path & Area Lights

3602 Series

Thread the cap onto the Junction

Box.

Install Cap to Junction Box

Cap

Junction Box

* Junction Box is not

provided by VOLT®

[email protected] • 813.978.3700

- 7 -

Install Fixture to Junction Box

Remove the cover from the junction

box by loosening the screws. Place

the xture supply wires into the

junction box.

Thread the junction box onto the

bottom of the xture and hand

tighten until snug.

Fixture

Junction Box

Supply Wires

Screw

Cover

Install Junction Box to Stake

Pass the main supply cable into

the junction box. Place the cap

back onto the stake and secure

with the previously removed

screws. Tighten until snug with a

screwdriver.

Main Supply Cable

Junction Box

Cap

Screw

Stake Conduit

* Junction Box is not

provided by VOLT®

* Junction Box is not

provided by VOLT®

INSTALLATION INSTRUCTIONS

www.voltlighting.com

- 8 -

VOLT®Estate Size Path & Area Lights

3602 Series

Wire Connection

Strip the leads from the xture supply wire and main supply cable. Using

wire connectors (sold separately), connect the leads from the xture

supply wire to the main supply cable leads. Then, connect the ground

wires to the ground screw in the junction box.

After wiring, carefully tuck the slack wires into the junction box. Attach

the cover back onto the junction box and secure with the previously

removed screws.

Main Supply Cable

Wire Connectors

Junction Box

Screw

Cover

Fixture Supply Wires

Ground Screw

* Junction Box is not

provided by VOLT®

[email protected] • 813.978.3700

- 9 -

Install Hat

Place the hat onto the stem top and secure it with the nial, or thread

the hat onto the stem top directly. Hand tighten until snug.

Stem Top

Finial

Hat

Stem Top

Finial

Hat

OPTIONAL A OPTIONAL B

StemTop

Hat

OPTIONAL C

Install/Replace Bulb

Disconnect the power, before replacing the bulb. Then remove the nial,

hat and stem top to expose the bulb and replace it with the correct

wattage and type marked on the xture label. Then, reinstall the stem

top, hat and nial.

IMPORTANT: Bulbs must be protected from moisture and dust at all

times. Always reinstall the stem top and hat when removed.

www.voltlighting.com

INSTALLATION INSTRUCTIONS

- 10 -

VOLT®Estate Size Path & Area Lights

3602 Series
