volkano Sync Series Manual de usuario
Sync Series
TRUE WIRELESS
STEREO EARBUDS
Please read these instructions carefully and
retain for future reference.
INSTRUCTION MANUAL
EN
VK-1111-BK
TA-2017/2354
APPROVED
• Volkano Sync Series Earbuds
• 500 mAh Charging Case
• USB to Micro-USB Charging Cable
• Instruction Manual
• Charging Case – Recharges Earbuds 5x Cycles
• Stereo Sound Completely Wireless
• Lightweight
• Earbuds Pair Separately
• 24 Hours Playtime
THE HIGHLIGHTS
PACKAGE CONTENTS
SPECIFICATIONS
2
• Bluetooth:
Version: 5.0
Chipset: Airoha 1532
Profiles: HFP, HSP, A2DP, AVRCP
Range: 30 feet / 10 meters
• Earbud Capacity: 50 mAh / Earbud
• Charging Station Capacity: 500 mAh
• Playback Time (with Case): 24 Hours
• Charging Case Charging Time: 2 Hours
IDENTIFYING PARTS
Charging the Charging Case:
Please fully charge the Sync charging case before using it
for the first time. Connect the supplied USB charging cable
to any powered USB port and to each of the micro USB ports
on the charging case. Make sure it is fully plugged in.
CHARGING
1. Earbud
2. Charging Case
3. Multi-Function Button
3
1
2
3
4
The blue light will flash to indicate charging has begun:
Note:
Once fully charged, the blue light will no longer flash.
Please fully charge the Sync earbuds before use.
Place the earbuds into the charging station. A white light
around the earbuds will turn on when the charging
has begun. The white light will turn off when the charging
is complete. When the earbuds are removed from the
charging case they will automatically power on.
Note:
The charge time is approximately 2 hours. The earbuds
cannot be used while charging.
CHARGING THE EARBUDS
Charge percentage
0 – 25%
25 – 50%
50 – 75%
75 – 100%
1 Time
2 Times
3 Times
4 Times
Times LED will flash
Turning On and Off:
To turn on the earbuds, long press the MFB button until the
blue LED light flashes, you will then hear a voice prompt
stating that the earbud has been powered on. To turn off
the earbuds, long press the MFB button until the red LED
light flashes for three seconds, you will then hear a voice
prompt stating that the earbuds have been powered off.
Note:
Please note that the earbuds would need to be turned
on individually.
INSTRUCTION FOR USE
Earbuds:
Turn on the main (left) earbud first then turn on the slave
earbud and allow a few seconds to pair. While powering on
the earbuds, hold down the MFB button to place the
earbuds on pairing mode.
Note:
This can be done separately to use earbuds individually.
BLUETOOTH PAIRING
1. Open the Bluetooth menu on the device you want to
pair. Some devices require you to select “Search for
Devices” or “Add New Device” in order to create a
Bluetooth pairing.
2. With the earbud turned off, flick the power switch to the
“On” position. The earbud will beep twice and the LED
will start flashing blue while the earbud is in
pairing mode.
BLUETOOTH DEVICE
5
Once both of the Sync earbuds are turned on, it will
automatically connect with the last paired Bluetooth
device that is on and within range. If the Sync does not
connect automatically, open the Bluetooth menu on your
device and select “Sync master” from the Bluetooth
device list.
Hands Free Calling:
To answer / end a call while connected to the Sync
earbuds, short press the “MFB” button on the master (left)
earbud, and to reject an incoming call, press and hold the
“MFB” button.
Note:
When using hands free calling, your calls will only come
through on the master (left) earbud.
CONNECTING WITH PAIRED DEVICES
3. Wait until you see “Sync Master” on your device screen.
4. Select “Sync Master” on your device and follow any
further prompts to pair. Once pairing is complete and a
connection is established, the earbud will beep.
Note:
If you are unsure on how to access your Bluetooth menu
on your device, please refer to your device’s instruction
manual.
6
SIRI / GOOGLE ASSISTANT
7
Compatible with Siri and Google Assistant
Function
Siri / Google
Assist
Activate Siri /
Google Assist
Turn Off Siri /
Google Assist
Triple touch either earphone’s
Multifunction Touch Button.
Triple touch either earphone’s
Multifunction Touch Button
Operation
• The product should only be used with the parts provided
by the manufacturer.
• Never use your earbuds near water or in areas where
they can come into contact with water. Never handle the
earbuds if they were dropped in water or any
other liquid. If the product comes into contact with
water while switched off, but still plugged in, this is a
safety hazard.
• Always make sure your hands are dry before touching
the plug or power connections.
• Do not operate the product with a damaged cord or
plug, or after it malfunctions, has been dropped, or
damaged in any manner.
• The earbuds are intended for personal use only.
Commercial use invalidates the warranty and the
supplier cannot be held responsible for injury or
damage caused when using the device for any other
purpose than that which it was intended for.
• These earbuds are not intended for use by children, or
persons with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the device by a person responsible
for their safety. Extreme caution must be exercised.
• Children should be supervised to ensure that they do
not play with the earbuds. Packaging must never
be left within reach of children, since it is
potentially dangerous.
SAFETY PRECAUTIONS
8
DISCLAIMER
Do not dispose of electrical appliances as
unsorted municipal waste, use separate collection
facilities. Contact your local government for
information regarding the collection systems
available. If electrical appliances are disposed of in landfills
or dumps, hazardous substances can leak into the
groundwater and get into the food chain, damaging your
health and well-being.
All product and company names are trademarks™ or
registered®trademarks of their respective holders. Use of
them does not imply any affiliation with or endorsement
by them.
ENVIRONMENTALLY FRIENDLY DISPOSAL
9
WARRANTY
This product comes with a standard 12-month limited
warranty against manufacturing defects and faults.
Should your product be unboxed with any faulty parts,
poor finishing or visible damage, or fail to perform due
to a manufacturing defect or poor workmanship, please
return it with your proof of purchase (till slip or invoice)
to the store of purchase for an exchange, or repair,
depending on the store’s returns policy.
This warranty commences from the date of purchase.
Kindly retain your proof of purchase as well as the
packaging for your warranty period.
Note: The Warranty does not apply to Product that:
1. Has failed due to excessive wear and tear beyond what
is considered to be reasonable.
2. Has been misused or neglected.
3. Has been damaged accidentally or by Force Majeure
including fire and flooding.
4. Has been used or operated contrary to operating or
maintenance instructions outlined in this manual.
The Store of Purchase / Seller cannot accept any
returned products that have not been returned following
this warranty or which does not follow their own Returns
Policy. Please refer to the Store of Purchase / Sellers
Returns Policy for details.
10
