Vogel QZ80 Manual de usuario
User manual for the QZ device
from VOGEL, the latest device
to detect and distinguish
between different metals.
QZ
www.vogeldetectors.com
User Manual
Metal and Water Finder
page 1
page 2
page 3
page 8
page 9
page 10
page 13
page 15
page 22
page 23
page 5
page 16
page 19
page 21
Index
Technical Specications
Important notes
Main unit
Getting started
setting
page 11
Main Unit setup and start working
search setting
Manual search settings
Pinpoint detection
page 25
Depth Mode
page 26
Charging
page 27
Notes
Introduction
page 6
page 7
Characteristics
Device components
Calibration
page 17
Search Modes
page 18
General Mode
Treasures Mode
Search mode for nuggets and coins
Assembly
Page 1
The user strips himself of metal, such as rings watch, or a metal belt
Do not store the device in a place with high temperatures and
humidity.
Page 2
The user should practice on how to use the device before setting off
for detection and search operations.
The user should practice how to use the device before setting off for
detection and search operations.
The device must be connected to the searching coil during
operation
In the case of tampering with the device, the device will lose its
security.
IMPORTANT NOTES
TECHNICAL SPECIFICATIONS
search for: Searching for metals, gold and blanks.
searching system:
Very low frequency VLF system
Operator
mikrocontroller
Operating system
A system for measuring and processing levels of the electromagnetic field formed
around the target and the receiver through the reception coil in the search coil,
analyzing these results and showing them through sound alerts and color graphic
indicators on the screen.
NO
Whireless
Sound alert YES
vibration alert NO
Three cells Li-ion 3.7 V, 3000 mA Power output 8.4 V
NO
Automated and intelligent
guidance system:
working hours 10 hours
Power
Charger 12 volts 2 amps / charging time 2 hours
Display 3.5 inch color TFT screen.
Page 3
:نزﻮﻟا
Operating temperature:
From -15 °C to 60 °C
storage temperature:
From -15 °C to 40 °C
Humidity :
Bag dimensions:
It can be stored and operated at an average air
humidity of 5% to 80%.
weight:
Dimensions:
Page 4
5 Kg
66X41X17 cm
4.6X5.7X9 cm
The QZ80, produced by the German company VÖGEL, is one of the company's
best in metal detector technology. This device is characterized by different
systems and multiple search options in order to reach the most accurate results
in the search for targets. The QZ80, through its unique search systems,
facilitates the work of prospectors and shortens the effort and time spent during
difficult excavations through various analysis algorithms of the earth to reveal
the contents of the soil and its different targets. It is also characterized by
advanced search settings that allow to ignore unwanted targets during the
search, which facilitates the work of prospectors.
The QZ80 is equipped with four different search modes for each system.
Individual features to display search results on the screen through interactive
graphical interfaces and alerts.
General search mode.
- Treasures Mode
- coins and nuggets mode.
- Depth mode
The device allows the user to adjust the search settings to suit the search
requirements:
Desensitization to iron.
- Increase or decrease the sensitivity in proportion to the electromagnetic
nature of the soil.
Increasing or decreasing the gain of the reception file in the search disk in
proportion to the nature of the soil.
Introduction
ًُ
Page 5
Dear customer, we appreciate your trust in us and your acceptance of a new
and unique experience in the world of metal detectors by owning one of our
products.
The QZ80 has a number of features including:
- The special design of the Double D-shaped search coil to avoid magnetic
anomalies caused by metallic minerals.
- The ability to isolate mineral and rocky soils (cancellation of magnetic noise)
without affecting sensitivity, thus giving greater effectiveness and a more
accurate allergic field during the research.
- Complete the search task without interruption due to the unique feature in the
number of continuous working hours, which
Up to ten hours straight.
Fast Charging: The QZ80 only needs 2 hours to fully charge.
- High-resolution color interactive interfaces to give the search process a lively
character.
-When you acquire the QZ80 device, you do not need to calibrate the soil for the
same search area every time you search, as the device stores the magnetic
harmonic value even after turning off the device, so you can return to the area
and start the search directly.
- Searching coils are identified for each device upon sale. When consuming
search coils and requesting new coils, you need to identify these coils by
pressing the scroll button down during turning the device on, so that the
frequency of the coil appears at the bottom of the screen.
QZ80 Characteristics
16 |
Page 6
By VÖGEL Metal detektor with MWF Detector association
S.F.:
By VÖGEL Metal detektor with MWF Detector association
S.F.: 14.420khz
Scroll button down
Frequency of the coil
Device components
Searching coil - 33 cm
Designed to Standards
to detect the small and medium size
pieces.
Designed to standard sensing
small sized parts and nuggets.
Searching coil - 21cm
Headphons
ChargerUser ManualWarranty
card
Main Unit
carry handle Device Bag
Page 7
411
37
2
5
8
9
1
6
1
2
3
6
57
4
5
8
9
10
11
Power button ON/OFF
Move buttons
OK button
Back button
TFT display
Charger socket
Calibration button
Pinpoint button
searching coil socket
Hedphone socket
speaker
Main Unit
Page 8
1
2
3
45
7
6
ASSEMBLY
ﺚﺤﺒﻟا صﺮﻘﺑ ﺾﺒﻘﻤﻟا ﻂﺑر
8- Connect the device to the carrying handle by sliding the device in the place designated for it on the handle
to the other.
9- Align the coil plug and insert it into the socket on the side of the unit
Main.
10- Tighten the retaining ring slightly clockwise to fix the cable.
9
10 8
ًا
ً
1
ًً
2
ً
1 25 ً
3
ضر EQUINOX Series
1- We open the handle locks to
calibrate the length of the
handle.
2- Lengthening or shortening
both arms of the carrying
handle in proportion to the
user.
3- When determining the
appropriate length for each of
the forearms, we close the
locks to give them movement.
4- Putting rubber protection to
prevent friction between the
handle and the search disk.
5- Place the contact head of the
handle in the place designated for
it in the search coil.
6- Inserting the fixing shaft into
the channel designated for fixing
the handle to the search coil.
7- Turn the locking nut clockwise.
Page 9
