VIRTUFIT Pro Elite HiiT Manual de usuario

Pro Elite HiiT Running Treadmill

ser manual

VirtuFit Pro Elite HiiT Running Treadmill 2

INDEX

SAFETY INSTRUCTIONS

CHECKLIST

ASSEMBLY INSTRUCTIONS

MAINTENANCE

TROUBLE SHOOTING

CONTROL PANEL

EXPLODED DRAWING

PARTS LIST

TRAINING INSTRUCTIONS

3 - 4

5 - 6

7 - 12

15 - 23

25 - 26

VirtuFit Pro Elite HiiT Running Treadmill

3EN

SAFETY INSTRUCTIONS

– It is important to read this entire manual before assembling and using the equipment. Safe and

eective use can only be achieved if the equipment is assembled, maintained and used properly.

It is your responsibility to ensure that all users of the equipment are informed of all warnings and

precautions.

– Before starting any exercise program, you should consult your doctor to determine if you have

any medical or physical conditions that could put your health and safety at risk, or prevent you

from using the equipment properly. Your doctor’s advice is essential if you are taking medication

that aects your heart rate, blood pressure or cholesterol level.

– Consult your GP before starting to exercise on this device. Should you want to exercise regularly and

intensively, the approval of your GP would be advisable. This is especially true for users with health

problems.

– We recommend that handicapped people should only use the device when a qualied care is present.

– When using the tness device, wear comfortable clothing and preferably spaots or aerobic shoes.

Avoid wearing loose clothing which could get caught in the moving parts of the device.

– Stop exercising immediately should you feel unwell or if you feel pain in your joints or muscles. In

particular, keep an eye on how your body is responding to the exercise program. Dizziness is a sign

that you are exercising too intensively with the device. At the rst signs of dizziness, lay down on the

ground until you feel better.

– Ensure there are no children nearby when you are exercising on the device. In addition, the device

should be showed in a place that children or house pets cannot reach.

– Ensure that only one person at a time uses the tness device.

ATTENTION

WARNING:

Before beginning any exercise program consult your physician. This is especially

important for people who are over 35 years old or who have pre-existing health

problems. Read all instructions before using any tness equipment. Do not operate this

exercise equipment without properly tted guards, as the moving parts can present a

risk of serious injury if exposed.

VirtuFit Pro Elite HiiT Running Treadmill 4

– After the sports device has been set up according to operating instructions, make sure all screws,

bolts and nuts are correctly tted and tightened. Use only attachments recommended and/or suplied

by the importer.

– Do not use a device that is damaged or unserviceable.

– Always place the device on a smooth, alean and sturdy surface. Never use near water and make sure

ther are no pointed objects in the direct vicinty of the tness device. If necessary, place a protective

mat (not included in scope of delivery) to protect your oor underneath the device and keep a free

space of at least 0.5m around the device for safety reasons.

– Take care not to put your arms and legs near moving parts. Do not place any material in openings in

the device.

– Use the device only for the purpose described in these operating instructions. Use only attachments

recommended by the manufacturer.

– The device is made for home use and semi-professional use. The maximum user weight is 160 kg.

– Please keep the space at least 1 to 2 meter at the end of base frame to escape any accidents!

– Place the device on a clean and at surface. Do not place the equipment on a thick carpet.

– The device is for indoor use and not for outdoor use to prevent damage. Keep the storage location

dry, clean and at. It is forbidden to use the device for purposes other than training.

Warranty claim is excluded if the cause of the defect is the result of:

• Maintenance assembly and repair work not carried out by an ocial dealer.

• In the event of improper use, neglect and / or poor maintenance.

• Failure to maintain the tness equipment in accordance with the manufacturer’s instructions (see

the enclosed manual).

SAFETY INSTRUCTIONS

VirtuFit Pro Elite HiiT Running Treadmill

5EN

TOOLKIT

When you open the carton, and you will nd the below parts in the carton:

Main body

Hand rail left + right Upright post cover Console

Console frame Upright post

Plastic cover Aluminium slat

xing belt

Front roller Rear roller

Running belt

CHECKLIST

VirtuFit Pro Elite HiiT Running Treadmill 6

TOOLKIT

NUMBER DESCRIPTION SHAPE QTY

78 Allen head C.K.S half

thread bolt M8*55*20 8

79 Allen head C.K.S full

thread bolt M8*25 4

66 Allen head C.K.S full

thread bolt M8*15 2

97 Phillip head C.K.S. self-

tapping screw ST4*16 4

80 Curve washer

Φ 8.5*R25*t2.0 4

101 Hexagon socket head

full thread bolt M8*45 4

-T-shape wrench

6*80 -

-Cross open wrench

14*17*75 -

-L-shape wrench

6*35*80 -

CHECKLIST

VirtuFit Pro Elite HiiT Running Treadmill

7EN

Missing parts: If you think you are missing certain parts in your package, carefully check the styrofoa and

the rowing machine. Some parts (bolts, screws, etc.) are already attached to / in the rowing machine.

Error message: Ensure that all cables are carefully attached. The aluminum legs are very sensitive and

must remain straight. Do you receive an error message after mounting your device? Then you have to

straighten these aluminum legs again, this may cause the error message to disappear.

Socket screws: The rowing machine contains socket screws, make sure that the allen key is rmly in the

bolt before you apply force to the key. In this way you prevent the head of the socket head screw from

being rotated.

STEP 1

• Take out the console frame and console from the carton, connect the connect cable, then x them

with 4 pcs of M5X10 screws.

ASSEMBLY INSTRUCTIONS

VirtuFit Pro Elite HiiT Running Treadmill 8

STEP 2

• Take out the main body from the carton.

ASSEMBLY INSTRUCTIONS

VirtuFit Pro Elite HiiT Running Treadmill

9EN

STEP 3

• Connect the right side upright post connecting wires, insert the redundant wire into the upright

post, put the right side upright post on the bracket, then x it with 4 pcs M8×55×20 screws.

• Same assembly step on the left side upright post. No need to connect wires.

ASSEMBLY INSTRUCTIONS

VirtuFit Pro Elite HiiT Running Treadmill 10

STEP 4

• Attached the right hand rail to the right upright post, then x the upper holes with 2 pcs M8*45

screws.

• Fix the bottom hole with 1 pcs M8*15 screw, then fasten all the screws.

• Same assembling step on the left side.

ASSEMBLY INSTRUCTIONS
