Viking VK1815

Egress 18 IP Par Light

User Manual

Please read the instruction carefully before use

Caution!

Be careful with your operations. With a dangerous voltage you can suffer a dangerous

electric shock when touching the wires!

Keep this device away from rain and moisture!

Make sure it is grounded when using it!

Unplug mains lead before opening the housing!

For your own safety, please read this user manual carefully before you initial start-up.

Introduction

Thank you for having chosen this Item. You will see you acquired a powerful and versatile

device. Unpack your item. Before you initial start-up, please make sure that there is no

damage caused by transportation. Should there be any, consult your dealer and do not

use the device.

Safety instructions

This device has left our premises in absolutely perfect condition. In order to maintain this

condition and to ensure a safe operation, it is absolutely necessary for the user to follow

the safety instructions and warning notes written in this user manual. Always disconnect

from the mains, when the device is not in use or before cleaning it. Keep away children

and amateurs from the device! There are no serviceable parts inside the device.

Specifications

Input power：AC100-240V 50/60 Hz

Power consumption：165w

LED：18 pcs15W RGBWA+UV LED

Light effect：pure color ,light is evenly spread

DMX channel：2/3/6/9/11 channel

Display: Touch panel menu with LCD display

Control mode：DMX512/Master-Slave/Auto run/IR remote control

0-100% linear dimmer

With RDM function

IP-Rating：IP65

product size：220×280×230mm

packing size：290×290×275mm

N.W：4.6Kg

G.W：5.3Kg

Control menu

[MENU] Main menu to select or return to the previous menu

[UP] Menu selection or parameter increase

[DOWN] Menu selection or parameter decrease

[ENTER] OK / enter or select sub menu

First

Manual

Secondary

Menu Value 1 Value 2 Value 3 Function

DMX

Address 001-512 DMX512 Address Code Setting

DMX

Channel

11CH Channel 11Mode

9CH Channel 9 Mode

6CH Channel 6 Mode

3CH Channel 3 Mode

2CH Channel 2 Mode

Stand Alone

Auto

Program 1 Dim 000-255

Program 2 Speed 000-255

Program 3

……

Program 16

Color Macro

Color Off

Color1

001-255

Color2

Color3

Color4

Color5

Color6

Color7

Color8

Color9

Color10

Color11

Color12

Color13

Color14

Color15

Color16

Color17

Color18

Color19

Color20

Color21

Color22

Color23

Color24

Color25

Color26

Color27

Color28

Color29

Color30

Color31

Color32

Color33

Color34

Color35

Static

Dimmer

000-255

Strobe

Red

Green

Blue

White

Amber

Tunable

White

Dimmer 000-255

CTC 2800~8000K

User Color Color1 Dimmer 000-255

Color2 Strobe 000-255

Color3 Red 000-255

Color4 Green 000-255

Color5 Blue 000-255

Color6 White 000-255

Color7 Amber 000-255

Color8 UB 000-255

Slave Yes/No

Settings

Output Set Standard Normal output 150W

Full High power output 180W

Display

Reverse

On The display is reversed

Off Normal display

Display

Backlight

On The display is always on

Off

Automatically turn off after

displaying for one minute

DMX Fail

Hold Keep the last state

Blackout Blackout

Emergency Light

Bright and cool white as an

emergency light

Dimmer

Curve

Linear Dimming curve 1 (straight line)

Exponential Dimming curve 2 (index)

Logarithmic Dimming curve 3 (logarithmic)

S-Curve Dimming curve 4 (S curve)

Dimmer

Response

LED LED effect

Halogen Halogen bubble effect

Auto Lock On

The screen will automatically lock

after one minute. The screen can

also be locked manually: press "up"

& "down" button for 5 seconds at

the same time, then will display "

Locked". To unlock, press "up" &

"down" button for 5 seconds at the

same time.

Off Turn off screen lock

IR Remote On

Off

Factory

Reset

ENTER-Reset

Now-ENTER

System Info

Firmwre V1.0 Display version number

Operation

Hours xxxHrs Total hours for the light run

RDMxxxxx

Press the "ENTER" button for 5

seconds into the backstage to set

the RDM value

DMX Controlling:

After having addressed all items, you may now start operating these via your lighting

controller. After switching on, the item will automatically detect whether DMX 512 data is

received or not.

Channel modes:

2 channel mode

3 channel mode

2 CH Mode

Ch. Function Values Sub-Group

1 Dimmer 000 - 255 0% to 100% Dimmer

2 Full White RGBW 000 - 255 7200K - 3200K @ Full on

3 CH Mode

Ch. Function Values Sub-Group

1 Dimmer 000 - 255 0% to 100% Dimmer

2 Strobe functions

000 - 005 Strobe open

Multifunctional-Strobe

006 - 010 Strobe closed

011 - 033 Puls Random, slow -> fast

034 - 056 Ramp up Random, slow -> fast

057 - 079 Ramp down Random, slow -> fast

080 - 102 Random Strobe Effect, slow -> fast

103 - 127

Strobe Break Effekt, 5s…..1s (Sh

ort

burst with break)

128 - 250 Strobe slow -> fast <1Hz - 20Hz

251 - 255 Strobe open

Colour Macro

(override RGBAWV)

000 - 010 Colour off

Colour Macro

011 - 013 Color1

014 - 016 Color2

017 - 019 Color3

020 - 022 Color4

023 - 025 Color5

026 - 028 Color6

029 - 031 Color7

032 - 034 Color8

035 - 037 Color9

038 - 040 Color10

6channel mode

6 CH Mode

Ch. Function Values Sub-Group

1 Red 000 - 255 0% to 100% Red

2 Green 000 - 255 0% to 100% Green

3 Blue 000 - 255 0% to 100% Blue

4 White 000 - 255 0% to 100% White

5 Amber 000 - 255 0% to 100% Amber

6 UV 000 - 255 0% to 100% UV

041 - 043 Color11

044 - 046 Color12

047 - 049 Color13

050 - 052 Color14

053 - 055 Color15

056 - 058 Color16

059 - 061 Color17

062 - 064 Color18

065 - 067 Color19

068 - 070 Color20

071 - 073 Color21

074 - 076 Color22

077 - 079 Color23

080 - 082 Color24

083 - 085 Color25

086 - 088 Color26

089 - 091 Color27

092 - 094 Color28

095 - 097 Color29

098 - 100 Color30

101 - 105 Color31

106 - 110 Color32

111 - 115 Color33

116 - 120 Color34

121 - 125 Color35

126 - 127 Colour Jumping Stop

128 - 191

Colour Jumping Speed slow -> fast

/ Colour 1 -> 12

192 - 255

Colour Fading Speed slow -> fast /

Colour 1 -> 12

9channel mode

9 CH Mode

Ch. Function Values Sub-Group

1 Dimmer 000 - 255 0% to 100% Dimmer

2 Strobe functions

000 - 005 Strobe open

Multifunctional-Strobe

006 - 010 Strobe closed

011 - 033 Puls Random, slow -> fast

034 - 056 Ramp up Random, slow -> fast

057 - 079 Ramp down Random, slow -> fast

080 - 102 Random Strobe Effect, slow -> fast

103 - 127

Strobe Break Effekt, 5s…..1s (Short

burst with break)

128 - 250 Strobe slow -> fast <1Hz - 20Hz

251 - 255 Strobe open

3 Red 000 - 255 0% to 100% Red

4 Green 000 - 255 0% to 100% Green

5 Blue 000 - 255 0% to 100% Blue

6 White 000 - 255 0% to 100% White

7 Amber 000 - 255 0% to 100% Amber

8 UV 000 - 255 0% to 100% UV

Colour Macro

(override RGBAWV

Cover up 3-8

channels at startup)

000 - 010 Colour off

Colour Macro

011 - 013 Color1

014 - 016 Color2

017 - 019 Color3

020 - 022 Color4

023 - 025 Color5

026 - 028 Color6

029 - 031 Color7

032 - 034 Color8

035 - 037 Color9

038 - 040 Color10

041 - 043 Color11

044 - 046 Color12

047 - 049 Color13

050 - 052 Color14

053 - 055 Color15

056 - 058 Color16

059 - 061 Color17

062 - 064 Color18

065 - 067 Color19

068 - 070 Color20

071 - 073 Color21

074 - 076 Color22

077 - 079 Color23

080 - 082 Color24

083 - 085 Color25

086 - 088 Color26

089 - 091 Color27

092 - 094 Color28

095 - 097 Color29

098 - 100 Color30

101 - 105 Color31

106 - 110 Color32

111 - 115 Color33

116 - 120 Color34

121 - 125 Color35

126 - 127 Colour Jumping Stop

128 - 191

Colour Jumping Speed slow -> fast

/ Colour 1 -> 12

192 - 255

Colour Fading Speed slow -> fast /

Colour 1 -> 12

11channel mode

11 CH Mode 2

Ch. Function Values Sub-Group

1 Dimmer 000 - 255 0% to 100% Dimmer

2 Strobe functions

000 - 005 Strobe open

Multifunctional-Strobe

006 - 010 Strobe closed

011 - 033 Puls Random, slow -> fast

034 - 056 Ramp up Random, slow -> fast

057 - 079 Ramp down Random, slow -> fast

080 - 102 Random Strobe Effect, slow -> fast

103 - 127

Strobe Break Effekt, 5s…..1s (Short

burst with break)

128 - 250 Strobe slow -> fast <1Hz - 20Hz

251 - 255 Strobe open

3 Red 000 - 255 0% to 100% Red

4 Green 000 - 255 0% to 100% Green

5 Blue 000 - 255 0% to 100% Blue

6 White 000 - 255 0% to 100% White

7 Amber 000 - 255 0% to 100% Amber

8 UV 000 - 255 0% to 100% UV

Colour Macro

(override RGBAWV

Cover up 3-8

channels at startup)

000 - 010 Colour off

Colour Macro

011 - 013 Color1

014 - 016 Color2

017 - 019 Color3

020 - 022 Color4

023 - 025 Color5

026 - 028 Color6

029 - 031 Color7

032 - 034 Color8

035 - 037 Color9

038 - 040 Color10

041 - 043 Color11

044 - 046 Color12

047 - 049 Color13

050 - 052 Color14

053 - 055 Color15

056 - 058 Color16

059 - 061 Color17

062 - 064 Color18

065 - 067 Color19

068 - 070 Color20

071 - 073 Color21

074 - 076 Color22

077 - 079 Color23

080 - 082 Color24

083 - 085 Color25

086 - 088 Color26

089 - 091 Color27

092 - 094 Color28

095 - 097 Color29

098 - 100 Color30

101 - 105 Color31

106 - 110 Color32

111 - 115 Color33

116 - 120 Color34

121 - 125 Color35

126 - 127 Colour Jumping Stop

128 - 191

Colour Jumping Speed slow -> fast

/ Colour 1 -> 12
