Viking Range D30FTW Manual de usuario
F20702B EN (020113)
Viking Range Corporation
111 Front Street
Greenwood, Mississippi 38930 USA
(662) 455-1200
For product information,
call 1-888-845-4641
Installation Guide
D30FTW - Warming Drawer
Accessory Flush Mount Kit
2 3
Removing Existing Trim
Remove the two existing side trim pieces from the warming drawer. There should be one trim
piece on each side of the drawer.
Installing Flush Mount Trim
After removing the existing side trim pieces, install the flush mount trim piece to the warming
drawer.
1. Remove the protective plastic from the flush mount trim piece.
2. Install the flush mount trim piece to the unit with screws provided.
3. After installing the flush mount trim piece, the warming drawer can be installed into the
4 5
Securing Inside the Cutout
Side View
Screw
A
Vertical Blocking
B
Bottom Spacer Blocking
CRITICAL
DIMENSIONS
A1/2” (1.3 cm)
B1-3/8” (3.5 cm)
Preparing the Cutout
In order for the unit to sit properly inside the cutout, the bottom must be built-up or “shimmed”
by 1/2” blocking (See illustrations below). This will provide stability for the unit and allow it to sit
upright when pushed back into the wall.
Finished Surfaces
Vertical Blocking
Bottom Spacer Blocking
LEGEND
Blocking
Finished
Surfaces
B
A
C
FLUSH CUTOUT
A29-5/8” (75.2 cm)
B25-1/8” (63.8 cm)
C10-1/8” (25.7 cm)
67
Securing Inside the Cutout (cont.)
Vertical
Blocking
Distance will
vary depending
on the cabinet
A
B
Top View
ScrewScrew
CRITICAL
DIMENSIONS
A28-1/2” (72.4 cm)
B1-1/2” (3.8 cm)
