ViewSonic XG2431 Manual de usuario

30-01-2023 10:09

XG2431 - ViewSonic Monitor

https://manuals.viewsonic.com/index.php?title=XG2431_Full_Guide&mobileaction=toggle_view_desktop

1/31

XG2431

Package Contents

Monitor

Power cord

Video cable

Quick start guide

Front View / Rear View

Front View

HDMI

12 DP

D D

Rear View

Letter Item

ADisplay Screen

BControl Panel Keys

CSecurity Slot

DMouse Anchor

I/O Ports

30-01-2023 10:09

XG2431 - ViewSonic Monitor

https://manuals.viewsonic.com/index.php?title=XG2431_Full_Guide&mobileaction=toggle_view_desktop

2/31

Number Item

1AC IN

2HDMI

3DisplayPort

4Audio Out

5USB Type B (USB Upstream)

6USB Type A (USB Downstream)

Stand Installation

Always place the device on a flat, stable surface.

Failure to do so may cause the device to fall and

damage the device and/or result in personal injury.

Using the Mouse Anchor

30-01-2023 10:09

XG2431 - ViewSonic Monitor

https://manuals.viewsonic.com/index.php?title=XG2431_Full_Guide&mobileaction=toggle_view_desktop

3/31

Included at the rear of the display, under the I/O ports, are two mouse anchors. Use these to prevent mouse cable

dragging and personalize your mouse use setup.

Wall Mounting

Refer to the table below for the standard dimensions for wall mount kits.

For use only with a UL certified wall mount

kit/bracket. To obtain a wall-mounting kit or height

adjustment base, contact ViewSonic® or your local

dealer.

30-01-2023 10:09

XG2431 - ViewSonic Monitor

https://manuals.viewsonic.com/index.php?title=XG2431_Full_Guide&mobileaction=toggle_view_desktop

4/31

Maximum

Hole Pattern (W x

Interface Pad (W x H x

Pad

Hole

Screw Specification &

Quantity

14 kg 100 x 100 mm 115 x 115 x 2.6 mm Ø 5 mm M4 x 10 mm - 4 pieces

1. Turn off the device and disconnect all cables.

2. Place the device on a flat, stable surface with the scree facing down.

3. Remove the stand.

4. Attach the mounting bracket to the VESA mounting holes at the rear of the monitor. Then secure it with four (4)

screws (M4 x 10 mm).

5. Follow the instructions that come with the wall mounting kit to mount the monitor onto the wall.

Connecting to Power

1. Connect the power cord to the AC IN jack at the rear of the device.

2. Connect the power cord plug to a power outlet.

30-01-2023 10:09

XG2431 - ViewSonic Monitor

https://manuals.viewsonic.com/index.php?title=XG2431_Full_Guide&mobileaction=toggle_view_desktop

5/31

Connecting External Devices

30-01-2023 10:09

XG2431 - ViewSonic Monitor

https://manuals.viewsonic.com/index.php?title=XG2431_Full_Guide&mobileaction=toggle_view_desktop

6/31

Note: To connect the monitor to an external device (PC, laptop…etc.), please use

one of the included video cables for your application and connect it to both

terminals.

Tilt the monitor backwards to the desired viewing angle via the attached stand

(-5˚ to 15˚).

NOTE: When adjusting, support the monitor firmly with one

hand while tilting the stand backwards with the other hand.

Using the Control Panel Keys

Use the control panel keys to access the Quick Menu, activate Hot Keys,

navigate the On-Screen Display (OSD) Menu, and change the settings.

Quick Menu

Press the 1 (Shortcut) key to activate the Quick Menu.

Tilt Angle Adjustment

Angle Adjustment

30-01-2023 10:09

XG2431 - ViewSonic Monitor

https://manuals.viewsonic.com/index.php?title=XG2431_Full_Guide&mobileaction=toggle_view_desktop

7/31

NOTE: Follow the key guide that appears on the screen to select the option or make adjustments.

Icon Menu Description

ViewMode Select one of the preset color settings.

Volume Adjust the level, or mute the volume.

Contrast/Brightness Adjust the contrast or brightness level.

Input Select Select the input source.

Exit Exit the Quick Menu.

Hot Keys

When the On-Screen Display (OSD) Menu is off, you can quickly access special functions by using the control panel

keys.

30-01-2023 10:09

XG2431 - ViewSonic Monitor

https://manuals.viewsonic.com/index.php?title=XG2431_Full_Guide&mobileaction=toggle_view_desktop

8/31

Key Description

2+3

Press and hold the keys to lock/unlock the OSD

Menu.

When the menu appears on the screen, continue

holding both keys for 10 seconds to lock/unlock

the OSD Menu.

2+4

Press and hold the keys to lock/unlock the Power

button.

When the menu appears on the screen, continue

holding the key for 10 seconds to lock/unlock the

Power button.

3+5

Press the keys to display/hide the boot up screen

when the device is turned on.

General Operation

1. Press the 2/3/4/5 key to display the OSD Menu.

30-01-2023 10:09

XG2431 - ViewSonic Monitor

https://manuals.viewsonic.com/index.php?title=XG2431_Full_Guide&mobileaction=toggle_view_desktop

9/31

2. Press the 1 or 2 key to select the main menu. Then press the 3 key to enter the selected menu.

3. Press the 1 or 2 key to select the desired menu option. Then press the 3 key to enter the sub-menu.

4. Press the 1 or 2 key to adjust/select the setting. Then press the 3 key to confirm.

30-01-2023 10:09

XG2431 - ViewSonic Monitor

https://manuals.viewsonic.com/index.php?title=XG2431_Full_Guide&mobileaction=toggle_view_desktop

10/31

NOTE: Follow the key guide to select the option or make adjustments.

5. Press the 4 key to return to the previous menu.

OSD Tree

Sub-menu Menu Option

HDMI 1

HDMI 2

DisplayPort

Sub-menu Menu Option

Volume (-/+, 0~100)

Sub-menu

Standard

FPS Game

RTS Game

MOBA Game

Movie

Web

Text

MAC

Mono

Input Select

Audio Adjust

ViewMode
