ViewSonic®

N4200w

LCD Display

- User Guide

- Guide de l’utilisateur

- Guida dell’utente

Model No. : VS10945-1M

ViewSonic N4200w

Contents

Compliance Information.............................................................................................1

Declaration of RoHS Compliance ..............................................................................2

Important Safety Instructions .....................................................................................3

Product Registration ..................................................................................................4

Cleaning the LCD Display..........................................................................................5

Disclaimer..................................................................................................................5

Getting Started

Package Contents .....................................................................................................6

The wall type is installed............................................................................................7

Move loudspeaker secure..........................................................................................8

View of the Product ...................................................................................................9

Remote Control .......................................................................................................12

Installation ...............................................................................................................14

RS232 Module.........................................................................................................21

Basic Operation .......................................................................................................24

OSD Functions

OSD style and operation tips ...................................................................................26

OSD Operation ........................................................................................................26

Other Information

Specifications ..........................................................................................................35

Troubleshooting.......................................................................................................36

Customer Support ...................................................................................................38

Limited Warranty .....................................................................................................39

1 ViewSonic N4200w

Compliance Information

FCC Statement

This device complies with part 15 of FCC Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses, and can radiate radio frequency energy, and if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV technician for help.

Warning: You are cautioned that changes or modifications not expressly approved by the

party responsible for compliance could void your authority to operate the equipment.

Following information is only for EU-member states:

The mark shown to the right is in compliance with the Waste Electrical and Electronic

Equipment Directive 2002/96/EC (WEEE).

The mark indicates the requirement NOT to dispose the equipment as unsorted

municipal waste, but use the return and collection systems according to local law.

ViewSonic N4200w 2

Declaration of RoHS Compliance

This product has been designed and manufactured in compliance with Directive 2002/95/EC

of the European Parliament and the Council on restriction of the use of certain hazardous

substances in electrical and electronic equipment (RoHS Directive) and is deemed to comply

with the maximum concentration values issued by the European Technical Adaptation

Committee (TAC) as shown below:

Substance Proposed Maximum

Concentration

Actual

Concentration

Lead (Pb) 0.1% < 0.1%

Mercury (Hg) 0.1% < 0.1%

Cadmium (Cd) 0.01% < 0.01%

Hexavalent Chromium (Cr6+) 0.1% < 0.1%

Polybrominated biphenyls (PBB) 0.1% < 0.1%

Polybrominated diphenyl ethers (PBDE) 0.1% < 0.1%

Certain components of products as stated above are exempted under the Annex of the RoHS

Directives as noted below:

Examples of exempted components are:

1. Mercury in compact fluorescent lamps not exceeding 5 mg per lamp and in other lamps not

specifically mentioned in the Annex of RoHS Directive.

2. Lead in glass of cathode ray tubes, electronic components, fluorescent tubes, and electronic

ceramic parts (e.g. piezoelectronic devices).

3. Lead in high temperature type solders (i.e. lead-based alloys containing 85% by weight or

more lead).

4. Lead as an allotting element in steel containing up to 0.35% lead by weight, aluminium

containing up to 0.4% lead by weight and as a cooper alloy containing up to 4% lead by

weight.

3 ViewSonic N4200w

Important Safety Instructions

1. Read these instructions completely before using the equipment.

2. Keep these instructions in a safe place.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this equipment near water.

6. Clean with a soft, dry cloth. If further cleaning is required, see “Cleaning the Display” in

this guide for further instructions.

7. Do not block any ventilation openings. Install the equipment in accordance with the

manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other

devices (including amplifiers) that produce heat.

9. Do not attempt to circumvent the safety provisions of the polarized or grounding-type

plug. A polarized plug has two blades with one wider than the other. A grounding type

plug has two blades and a third grounding prong. The wide blade and the third prong are

provided for your safety. If the plug does not fit into your outlet, consult an electrician

for replacement of the outlet.

10. Protect the power cord from being tread upon or pinched, particularly at the plug, and the

point where if emerges from the equipment. Be sure that the power outlet is located near

the equipment so that it is easily accessible.

11. Only use attachments/accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified by the

manufacturer, or sold with the equipment. When a cart is used, use

caution when moving the cart/ equipment combination to avoid injury

from tipping over.

13. Unplug this equipment when it will be unused for long periods of time.

14. Refer all servicing to qualified service personnel. Service is required when the unit has

been damaged in any way, such as: if the power-supply cord or plug is damaged, if liquid

is spilled onto or objects fall into the unit, if the unit is exposed to rain or moisture, or if

the unit does not operate normally or has been dropped.

ViewSonic N4200w 4

ViewSonic, the three birds logo, OnView, ViewMatch, and ViewMeter are registered

trademarks of ViewSonic Corporation.

Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or

omissions contained herein; nor for incidental or consequential damages resulting from

furnishing this material, or the performance or use of this product.

In the interest of continuing product improvement, ViewSonic Corporation reserves the right

to change product specifications without notice. Information in this document may change

without notice.

No part of this document may be copied, reproduced, or transmitted by any means, for any

purpose without prior written permission from ViewSonic Corporation.

Product Registration

To meet your future needs, and to receive any additional product information as it becomes

available, please register your product on the Internet at: www.viewsonic.com.

For Your Records

Product Name: N4200w-2

ViewSonic LCD Display

Model Number: VS10945-1M

Document Number: N4200w-2M_UG_ENG Rev. 1A 12-13-06

Serial Number:

Purchase Date:

Product disposal at end of product life

ViewSonic is concerned about the preservation of our environment. Please dispose of this

product properly at the end of its useful life. Your local waste disposal company may provide

information about proper disposal.

The lamp in this product contains mercury. Please dispose of properly in accordance with

environmental laws of your location.

5 ViewSonic N4200w

Cleaning the LCD Display

yMake sure the LCD Display is turned off.

yNever spray or pour any liquid directly onto the screen or case.

To clean the screen:

1 Wipe the screen with a clean, soft, lint-free cloth. This removes dust and other particles.

2 If still not clean, apply a small amount of non-ammonia, non-alcohol based glass cleaner onto a clean, soft,

lint-free cloth, and wipe the screen.

To clean the case:

1 Use a soft, dry cloth.

2 If still not clean, apply a small amount of non-ammonia, non-alcohol based, mild non-abrasive detergent

onto a clean, soft, lint-free cloth, then wipe the surface.

Disclaimer

ViewSonic®does not recommend the use of any ammonia or alcohol-based cleaners on the LCD display screen

or case. Some chemical cleaners have been reported to damage the screen and/or case of the LCD display.

ViewSonic will not be liable for damage resulting from use of any ammonia or alcohol-based cleaners.

ViewSonic N4200w 6

Getting Started

Congratulations on your purchase of a ViewSonic®LCD display.

Important! Save the original box and all packing material for future shipping needs.

Package Contents

Your LCD display package includes:

yLCD Display

yVGA Cable

yQuick Start Guide

yPower Cable

yUniversal Remote Control with batteries

yViewSonic User Guide

7 ViewSonic N4200w

The wall type is installed

Use only approved wall-mounting brackets advised by ViewSonic or your local distributor.

To install the wall-mounting brackets to LCD display and fix LCD display to the wall safely,

please use the following guidelines:

1. Cut off the power.

2. Set the LCD display on a table or work surface, screen-down with a towel or woolen

blanket between the screen and the surface to protect the display.

3. Disassemble 6 screws in the base.

4. According to the wall type instruction, fix LCD display to the wall.

ViewSonic N4200w 8

Move loudspeaker secure

To detach the loudspeakers from the LCD display, please read the following guidelines:

1. Cut off the power.

2. Disassemble 6 screws of the back loudspeaker(3 screws on each side).

3. Exert oneself outward, remove the loudspeaker
