ViewSonic LCD Display VS11349 Manual de usuario

ViewSonic®

VX2245wm

LCD Display

Model No. : VS11349

ViewSonic VX2245wm

Contents

Compliance Information.............................................................................. 1

Important Safety Instructions...................................................................... 2

Product Registration................................................................................... 3

Getting Started

Package Contents ...................................................................................... 4

Precautions ................................................................................................ 4

Quick Installation ........................................................................................ 5

ViewDockTM Connecting to PC................................................................... 6

Wall Mounting (Optional) ............................................................................ 7

Using the LCD Display

Setting the Timing Mode............................................................................. 8

OSD and Power Lock Settings ................................................................... 8

Adjusting the Screen Image ....................................................................... 9

Main Menu Controls ................................................................................. 11

ViewDockTM Key Features........................................................................ 15

Physical Description ................................................................................. 16

Card reader Installation ............................................................................ 17

USB Hub Installation ................................................................................ 18

ViewDockTM Connecting with iPod .......................................................... 19

Volume control of Sub Woofer.................................................................. 19

Other Information

Specifications ........................................................................................... 20

Troubleshooting........................................................................................ 21

Customer Support .................................................................................... 22

Cleaning the LCD Display ........................................................................ 23

Limited Warranty ...................................................................................... 24

ViewSonic VX2245wm 1

Compliance Information

For U.S.A.

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses, and can radiate radio frequency energy, and if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV technician for help.

FCC Warning

To assure continued FCC compliance, the user must use grounded power supply cord and the

cables which are included with the equipment or specified. Also, any unauthorized changes or

modifications not expressly approved by the party responsible for compliance could void the

user's authority to operate this device.

For Canada

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

For European Countries

CE Conformity

The device complies with the requirements of the EEC directive 89/336/EEC as

amended by 92/31/EEC and 93/68/EEC Art.5 with regard to “Electromagnetic

compatibility,” and 73/23/EEC as amended by 93/68/EEC Art.13 with regard to

“Safety.”

User Information for all Countries

Notice: Use the cables which are included with the unit or specified.

Following information is only for EU-member states:

The mark shown to the right is in compliance with the Waste Electrical and Electronic

Equipment Directive 2002/96/EC (WEEE).

The mark indicates the requirement NOT to dispose the equipment as unsorted municipal

waste, but use the return and collection systems according to local law.

ViewSonic VX2245wm 2

Important Safety Instructions

1. Read these instructions completely before using the equipment.

2. Keep these instructions in a safe place.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this equipment near water. Warning: To reduce the risk of fire or electric shock,

do not expose this apparatus to rain or moisture.

6. Clean with a soft, dry cloth. If further cleaning is required, see “Cleaning the Display” in

this guide for further instructions.

7. Do not block any ventilation openings. Install the equipment in accordance with the

manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other

devices (including amplifiers) that produce heat.

9. Do not attempt to circumvent the safety provisions of the polarized or grounding-type

plug. A polarized plug has two blades with one wider than the other. A grounding type

plug has two blades and a third grounding prong. The wide blade and the third prong are

provided for your safety. If the plug does not fit into your outlet, consult an electrician for

replacement of the outlet.

10. Protect the power cord from being tread upon or pinched, particularly at the plug, and the

point where if emerges from the equipment. Be sure that the power outlet is located near

the equipment so that it is easily accessible.

11. Only use attachments/accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified by the

manufacturer, or sold with the equipment. When a cart is used, use caution

when moving the cart/equipment combination to avoid injury from tipping

over.

13. Unplug this equipment when it will be unused for long periods of time.

14. Refer all servicing to qualified service personnel. Service is required when the unit has

been damaged in any way, such as: if the power-supply cord or plug is damaged, if liquid

is spilled onto or objects fall into the unit, if the unit is exposed to rain or moisture, or if

the unit does not operate normally or has been dropped.

ViewSonic VX2245wm 3

Macintosh and Power Macintosh are registered trademarks of Apple Computer, Inc.

Microsoft, Windows, Windows NT, and the Windows logo are registered trademarks of

Microsoft Corporation in the United States and other countries.

ViewSonic, the three birds logo, OnView, ViewMatch, and ViewMeter are registered

trademarks of ViewSonic Corporation.

VESA is a registered trademark of the Video Electronics Standards Association. DPMS and

DDC are trademarks of VESA.

ENERGY STAR®is a registered trademark of the U.S. Environmental Protection Agency (EPA).

As an ENERGY STAR®partner, ViewSonic Corporation has determined that this product meets

the ENERGY STAR®guidelines for energy efficiency.

Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or

omissions contained herein; nor for incidental or consequential damages resulting from

furnishing this material, or the performance or use of this product.

In the interest of continuing product improvement, ViewSonic Corporation reserves the right

to change product specifications without notice. Information in this document may change

without notice.

No part of this document may be copied, reproduced, or transmitted by any means, for any

purpose without prior written permission from ViewSonic Corporation.

Product Registration

To meet your future needs, and to receive any additional product information as it becomes

available, please register your product on the Internet at: www.viewsonic.com. The ViewSonic

Wizard CD-ROM also provides an opportunity for you to print the registration form, which

you may mail or fax to ViewSonic.

Product disposal at end of product life

The lamp in this produc contains mercury. Please dispose of in accordance with local, state or

federal laws.

ViewSonic is concerned about the preservation of our environment. Please dispose of this

product properly at the end of its useful life.

For Your Records

Product Name:

Model Number:

Document Number:

Serial Number:

Purchase Date:

VX2245wm

ViewSonic 22" LCD Display

VS11349

VX2245wm-1_UG_ENG Rev. 1A 07-21-06

__________________________________

ViewSonic VX2245wm 4

Getting Started

Congratulations on your purchase of a ViewSonic®LCD display.

Important! Save the original box and all packing material for future shipping needs.

NOTE: The word “Windows” in this user guide refers to the following Microsoft operating

systems: Windows ‘95, Windows NT, Windows ‘98, Windows 2000, Windows Me

(Millennium), and Windows XP.

Package Contents

Your LCD display package includes:

NOTE: The CD includes the User Guide PDF files and INF/ICM display optimization files.

The INF file ensures compatibility with Windows operating systems, and the ICM file (Image

Color Matching) ensures accurate on-screen colors. ViewSonic recommends that you install

both the INF and ICM files.

Precautions

• LCD display

• Power cable (for monitor)

• 15 Pin VGA video cable

• DVI-D cable

• USB connector cable * 1 (A-B Type)

• Stereo audio cable * 1

• 2 in 1 audio cable * 1

• iPod adaptors

• Power adapter *1 (for ViewDockTM)

• ViewSonic Wizard CD-ROM * 2

• Quick Start Guide

• Sit at least 18” from the LCD display.

•Avoid touching the screen. Skin oils are

difficult to remove.

•Never remove the rear cover. This LCD

display contains high-voltage parts. You

may be seriously injured if you touch

them.

• Avoid exposing the LCD display to direct

sunlight or another heat source. Orient the

LCD display away from direct sunlight to

reduce glare.

• Always handle the LCD display with care

when moving it.

• Place the LCD display in a well ventilated

area. Do not place anything on the LCD

display that prevents heat dissipation.

• Ensure the area around the LCD display is

clean and free of moisture.

• Do not place heavy objects on the LCD

display, video cable, or power cord.

• If smoke, an abnormal noise, or a strange

odor is present, immediately switch the

LCD display off and call your dealer or

ViewSonic. It is dangerous to continue

using the LCD display.

• Do not rub or apply pressure to the LCD

panel, as it may permanently damage the

screen.

ViewSonic VX2245wm 5

Quick Installation

1. Connect power cord (and AC/DC

adapter if required)

2. Connect video cable

• Make sure both the LCD display and

computer are turned OFF

• Remove rear panel covers if necessary

• Connect the video cable from the LCD

display to the computer

Macintosh users: Models older than G3

require a Macintosh adapter. Attach the

adapter to the computer and plug the video

cable into the adapter.

To order a ViewSonic®Macintosh adapter,

contact ViewSonic Customer Support.

3. Turn ON LCD display and computer

Turn ON the LCD display, then turn ON

the computer. This sequence (LCD display

before computer) is important.

NOTE: Windows users may receive a

message asking them to install the INF

file. This is on the CD.

4. Insert the ViewSonic Wizard CD into

the computer’s CD drive.

Follow the on-screen instructions. If your

computer does not have a CD-ROM drive,

see “Customer Support” on page 16.

• Wait for the CD-ROM to auto-start.

NOTE: If the CD-ROM does not auto-

start: double-click on the CD-ROM icon in

the Windows Explorer, then double-click

on viewsonic.exe.

• Follow the on-screen instructions.

5. Windows users: Set the timing mode

(resolution and refresh rate)

Example: 1680 x 1050 @ 60 Hz.

For instructions on changing the resolution

and refresh rate, see the graphics card’s

user guide.

Installation is complete. Enjoy your new

ViewSonic LCD display.

To be best prepared for any future

customer service needs: print this user

guide and write the serial number in “For

Your Records” on page 3. (See back of

LCD display.)

You can register your product online at the

ViewSonic website for your region. See

the Customer Support table in this guide.

The ViewSonic Wizard CD-ROM also

provides an opportunity for you to print

the registration form which you may mail

or fax to ViewSonic.

Audio Cable

AC IN

Power Code

AC Outlet

(Wall Socket)

Computer Power Cord

DVI

D-SUB

ViewSonic VX2245wm 6

ViewDockTM Connecting to PC

Use the supplied cables to connect the ViewDock to your PC.

Refer to the following illustration:

Step 1. Please check your USB cable (A-B type)

Step 2. Connect the USB cable from PC (A type) to the ViewDock (B type)

Step 3. Plug in the power adaptor into the DC jack.

Step 4. Connect the stereo audio cable from audio-out of ViewDock base to audio-in of

monitor panel head.

Step 5. Connect the 2-in-1 audio cable from audio-in of ViewDock to audio-out / MIC-in of

PC.

Step 6. Turn on the power.

ViewSonic VX2245wm 7

Wall Mounting (Optional)

To obtain a wall-mounting kit, contact ViewSonic®or your local dealer. Refer to the

instructions that come with the base mounting kit. To convert your LCD display from a desk-

mounted to a wall-mounted display, do the following:

1. Verify that the Power button is turned Off, then

disconnect the power cord.

2. Lay the LCD display face down on a towel or

blanket.

3. Remove the Plastic Covers from the back of the

LCD display.

4. Remove the four screws attaching the base.

5. Remove the Rubber Plugs from inside the four

VESA screw holes.

6. Attach the mounting bracket from the VESA

compatible wall mounting kit (100 mm x 100 mm

distance).

7. Attach the LCD display to the wall, following the

instructions in the wall-mounting kit.

Four VESA screw holes

ViewSonic VX2245wm 8

Using the LCD Display

Setting the Timing Mode

Setting the timing mode is important for maximizing the quality of the screen image and

minimizing eye strain. The timing mode consists of the resolution (example 1680 x 1050) and

refresh rate (or vertical frequency; example 60 Hz). After setting the timing mode, use the

OSD (On-screen Display) controls to adjust the screen image.

For the best picture quality set your LCD display timing mode to:

VESA 1680 x 1050 @ 60Hz.

To set the Timing Mode:

1. Set the resolution: Right-click on the Windows desktop > Properties > Settings > set the

resolution.

2. Set the refresh rate: See your graphic card's user guide for instructions.

WARNING: Do not set the graphics card in your computer to exceed the maximum refresh

rate of 75Hz; doing so may result in permanent damage to your LCD display.

OSD and Power Lock Settings

•OSD Lock: Press and hold [1] and the up arrow Sfor 10 seconds. If any buttons are

pressed the message OSD Locked will display for 5 seconds.

•OSD Unlock: Press and hold [1] and the up arrow Sagain for 10 seconds.

•Power Button Lock: Press and hold [1] and the down arrow Tfor 10 seconds. If the

power button is pressed the message Power Button Locked will display for 5 seconds. With

or without this setting, after a power failure, your LCD display’s power will automatically

turn ON when power is restored.

•Power Button Unlock: Press and hold [1] and the down arrow Tagain for 10 seconds.

Otros manuales para LCD Display VS11349

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Monitor de ViewSonic

ViewSonic

ViewSonic E91fB Manual de usuario

ViewSonic

ViewSonic VA2430-h Manual de usuario

ViewSonic

ViewSonic PF790 - 19" CRT Display Manual de usuario

ViewSonic

ViewSonic VX500 - 15" LCD Monitor Manual de usuario

ViewSonic

ViewSonic VX2336s-LED Manual de usuario

ViewSonic

ViewSonic VE910 Manual de usuario

ViewSonic

ViewSonic CDE30 Series Manual de usuario

ViewSonic

ViewSonic VA2432-MH-IN2 Manual de usuario

ViewSonic

ViewSonic VS12319 Manual de usuario

ViewSonic

ViewSonic VG2039m-LED Manual de usuario

ViewSonic

ViewSonic VP2765-LED Manual de usuario

ViewSonic

ViewSonic APV110P - Airpanel V110P DISPLAY-10.4 Instrucciones de instalación

ViewSonic

ViewSonic ViewPanel VG191 Manual de usuario

ViewSonic

ViewSonic ND4210w Instrucciones de uso

ViewSonic

ViewSonic VA926 - 19" LCD Monitor Guía de inicio rápido

ViewSonic

ViewSonic CDE3204 Manual de usuario

ViewSonic

ViewSonic CLED5500 Manual de usuario

ViewSonic

ViewSonic VX2770Smh-LED Manual de usuario

ViewSonic

ViewSonic CDX4952 Manual de usuario

ViewSonic

ViewSonic VS16523 Manual de usuario

ViewSonic

ViewSonic VS17471 Manual de usuario

ViewSonic

ViewSonic G220F - 21" CRT Display Manual de usuario

ViewSonic

ViewSonic VX2450w-LED Manual de usuario

ViewSonic

ViewSonic VX2240W-4 Manual de usuario

Manuales populares de Monitor de otras marcas

Linear Acoustic

Linear Acoustic LQ-1000 Manual de usuario

AOC

AOC I2579V Manual de usuario

Gateway

Gateway FPD1520 Manual de usuario

Furuno

Furuno Mu 120c Manual de usuario

Asus

Asus VB171D - 17" LCD Monitor Manual de usuario

Dell

Dell S2230MX Instrucciones de uso

Philips

Philips 107C64 Manual de usuario

Dell

Dell S2409WFP Manual de usuario

EverFocus

EverFocus EN-7517E Manual de usuario

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manual de usuario

Dell

Dell Precision 7680 Manual de instrucciones

LG 50PM1M - - 50" Plasma Panel Manual de usuario

Bosch

Bosch DDU 9 Manual de usuario

Acer

Acer A231HL Manual de usuario

Philips

Philips 86BDL4152T Manual de usuario

NEC

NEC AccuSync LCD5V Manual de usuario

Emay

Emay SleepO2 Manual de usuario

IBM

IBM 6360 Instrucciones de instalación
