ViewSonic ColorPro VP3256-4K Manual de usuario

6/11/23, 12:31

VP3256-4K - ViewSonic Monitor

https://manuals.viewsonic.com/VP3256-4K_Full_Guide

1/49

ViewSonic Online User Guide Database

VP3256-4K

Package Contents

Monitor

Power cord

Video cable

Quick start guide

Front View / Rear View

Front View

Rear View

VS18845

6/11/23, 12:31

VP3256-4K - ViewSonic Monitor

https://manuals.viewsonic.com/VP3256-4K_Full_Guide

2/49

Letter Item

ADisplay Screen

BControl Panel Keys

CPower Button

DSecurity Slot

I/O Ports

Number Item

1AC IN

2HDMI

3DisplayPort

4USB Type C

5USB Type B (Upstream)

6USB Type A (Downstream)

Stand Installation

1. Place the monitor on a flat, stable surface with the screen facing down.

2. Align and slide the upper hooks of the stand into the stand mounting slots.

3. Lift the device into its upright position on a flat, stable surface.

6/11/23, 12:31

VP3256-4K - ViewSonic Monitor

https://manuals.viewsonic.com/VP3256-4K_Full_Guide

3/49

Always place the device on a flat, stable surface.

Failure to do so may cause the device to fall and

damage the device and/or result in personal injury.

Wall Mounting

Refer to the table below for the standard dimensions for wall mount kits.

For use only with a UL certified wall mount

kit/bracket. To obtain a wall-mounting kit or height

adjustment base, contact ViewSonic® or your local

dealer.

Maximum

Hole Pattern (W x

Interface Pad (W x H x

Pad

Hole

Screw Specification &

Quantity

14 kg 100 x 100 mm 115 x 115 x 2.6 mm Ø 5 mm M4 x 10 mm - 4 pieces

1. Turn off the device and disconnect all cables.

2. Place the device on a flat, stable surface with the screen facing down.

3. Pull down slightly to disengage the hooks and remove the stand.

4. Attach the mounting bracket to the VESA mounting holes at the rear of the monitor. Then secure it

with four (4) screws (M4 x 10 mm).

5. Follow the instructions that come with the wall mounting kit to mount the monitor onto the wall.

6/11/23, 12:31

VP3256-4K - ViewSonic Monitor

https://manuals.viewsonic.com/VP3256-4K_Full_Guide

4/49

Using the Security Slot

To help prevent the device from being stolen, use a security slot locking device to secure the device to

a fixed object.

Additionally, fastening the monitor to a wall or fixed object using a security cable can help support the

weight of the monitor in order to prevent the monitor from falling over.

Below is an example of setting up a security slot locking device on a table.

Connecting to Power

1. Connect the power cord to the AC IN jack at the rear of the device.

2. Connect the power cord plug to a power outlet.

Connecting External Devices

Note: To connect the monitor to an external device (PC, laptop…etc.), please use

one of the included video cables for your application and connect it to both terminals.

6/11/23, 12:31

VP3256-4K - ViewSonic Monitor

https://manuals.viewsonic.com/VP3256-4K_Full_Guide

5/49

Connecting to Power

HDMI Connection

DisplayPort Connection

USB Connection

Connect one end of an HDMI cable to the HDMI port of your monitor. Then connect the other end of

the cable to the HDMI port of your computer.

NOTE: The monitor is equipped with two HDMI 2.0 ports.

Connect one end of a DisplayPort cable to the DisplayPort port. Then connect the other end of the

cable to the DisplayPort or mini DP port of your computer.

NOTE: To connect the monitor to the Thunderbolt port (v. 1&2) on your Mac, connect the mini DP end

of the “mini DP to DisplayPort cable” to the Thunderbolt output of your Mac. Then connect the other

end of the cable to the DisplayPort port of the monitor.

HDMI

DisplayPort

USB

6/11/23, 12:31

VP3256-4K - ViewSonic Monitor

https://manuals.viewsonic.com/VP3256-4K_Full_Guide

6/49

Connect one end of a USB cable to a USB port of the monitor. Then connect the other end of the cable

to a USB port of your computer.

USB Number Description

Type

ATwo (2)

Connection for your Type A

peripheral device(s). (e.g., storage

device).

NOTE: To use some peripherals,

please ensure your computer is

also connected to the monitor’s

USB Type B port.

Type

BOne (1)

Connect the USB Type B male

cable (square with 2 cut corners)

to this port, and then connect the

other end of the cable to the USB

downstream port of your

computer.

Type

COne (1)

Make sure your Type C output

device and cable support video

signal transmission.

Height Adjustment

Swivel Adjustment

Tilt Angle Adjustment

Lower or raise the monitor to the desired height (0 to 130 mm).

NOTE: When adjusting, press down firmly along the adjustment track holding the monitor with both

hands on the side.

Swivel the monitor to the left or right for the desired viewing angle (60˚).

Tilt the monitor forwards or backwards to the desired viewing angle (-5˚ to 21˚).

Height Adjustment

Swivel Adjustment

Tilt Angle Adjustment

6/11/23, 12:31

VP3256-4K - ViewSonic Monitor

https://manuals.viewsonic.com/VP3256-4K_Full_Guide

7/49

NOTE: When adjusting, support the stand firmly with one hand while tilting the monitor forwards or

backwards with the other hand.

Screen Orientation Adjustment

1. Adjust the monitor height to the highest position. Then tilt the monitor backwards to the full tilt

position.

2. Rotate the monitor 90° clockwise or counter clockwise from landscape to portrait orientation.

NOTE:

When adjusting, make sure to hold both sides of your monitor firmly with both hands.

If using the Auto Pivot function, the system can detect the screen orientation

automatically.

Using the Control Panel Keys

Use the control panel keys to access the Quick Access Menu, navigate the On-Screen Display (OSD)

Menu, and change the settings.

Quick Menu

Screen Orientation Adjustment (Monitor Pivot)

6/11/23, 12:31

VP3256-4K - ViewSonic Monitor

https://manuals.viewsonic.com/VP3256-4K_Full_Guide

8/49

Touch the 1/2/3/4 key to activate the Quick menu. Follow the key guide that appears on the screen to

select options or make adjustments.

Standard Color

Contrast / Brightness

Input Select

Main Menu

6/11/23, 12:31

VP3256-4K - ViewSonic Monitor

https://manuals.viewsonic.com/VP3256-4K_Full_Guide

9/49

Icon Name Description

Standard Color Select one of the preset standard color settings.

Contrast / Brightness Adjust the contrast or brightness.

Input Select Select the input source.

Main Menu Enter the On-Screen Display (OSD) Menu.

Exit Exit the Quick Menu.

Hot Keys

When the On-Screen Display (OSD) Menu is off, you can quickly access special functions by using the

control panel keys.

6/11/23, 12:31

VP3256-4K - ViewSonic Monitor

https://manuals.viewsonic.com/VP3256-4K_Full_Guide

10/49

Key Description

Press and hold the key for 5 seconds to select

User mode. Then select the desired User mode to

activate.

2+3

Press and hold the keys to lock/unlock the OSD

Menu.

When the menu appears on the screen,

continue holding both keys for 10 seconds

to lock/unlock the OSD Menu.

2+4

Press and hold the keys to lock/unlock the Power

button.

When the menu appears on the screen,

continue holding the key for 10 seconds to

lock/unlock the Power button.

3+5 Press the keys to display/hide the boot up screen

when the device is turned on.
