ViewSonic NMP-200 - Network Media Player Ess-based... Manual de usuario

NMP-200

NETWORK MEDIA PLAYER

ViewSonic’s NMP-200 Network Media Player features a reliable

ESS-based processor for 24x7 digital signage applications.

Connect to any display having a VGA/S-Video/RCA composite

input, this cost-effective solution integrates into your existing

network and supports MPEG1/2/4 videos. The built-in CF Slot

allows you to install high capacity memory cards for content

storage. The included Signage Manager Express Software

makes it quick and easy to setup and manage all your digital

signage content.

Standard Definition (480p)

Network Media Player

Solid-state device for extreme reliability

720x480p video performance

Reliable 24/7/365 operation

WAN and LAN connectivity

MPEG 1/2/4 decoding

SCALA Content Manager Release 5 compatible

For more product information, visit us on the web at ViewSonic.com

Sales: (888) 881-8781 • [email protected] • ViewSonic.com

Specications subject to change without notice. Selection, offers and programs may vary by country; see your

ViewSonic representative for complete details. Corporate names, trademarks stated herein are the property of their

NMP-200 NETWORK MEDIA PLAYER

PRODUCT TYPE Network Media Player

PROCESSOR IAdea™ IAN411 Multimedia Networking Processor

ESS Digital Media Processor 2 (DMP2)

Dual Processor

NETWORKING IEEE 802.3 Ethernet 10/100 Base-T with Auto-MDIX

PLAYBACK CONTROL Signage Manager Express Software (LAN)

Adfotain Central Management Server (WAN)

SUPPORTED MEDIA FORMATS MPEG 1/2 MP@ML (480p)

MPEG 4 ASP@L2 AVI

CONTENT CAPACITY Typically 3 Mbps data rate, equivalent to 25 minutes

per 512MB memory card and 1 hour per 1.2GB memory card

STORAGE MEDIUM CompactFlash Type I/II memory card

VIDEO PERFORMANCE up to 720x480 resolution, 30 frames per second

VIDEO OUTPUT VGA, S-video, composite RCA video

AUDIO OUTPUT Stereo line-out

DIMENSIONS (W x H x D) Physical 5.3" x 4.4" x 1.0" (133.5mm x 113.5mm x 25mm)

WEIGHT Net 1.8 lb. (0.8 kg)

MOUNTING HOLES 4 VESA®compliant (10-cm/4-inch)

POWER CONSUMPTION 4-watt (typ)

OPERATING CONDITIONS Temperature 0–40º C

Humidity 5–85% @ 40º C

REGULATIONS UL approved AC adapter

PACKAGE CONTENTS Media Player, AC power adapter, User Guide,

Signage Manager Express software

WARRANTY One-year limited warranty on parts and labor

ViewSonic®recommends our

commercial displays, open frame

display or any ViewSonic large screen LCD or LCD TV

and the included Signage Manger Express software

for use with the NMP-200 to give you the best possible

digital signage results.

ViewSonic Digital Signage Software Partners

1:1

1:50 (LAN)

100+ (WAN)

Offsite Hosted

Recommended

Network Media Player

NMP-610

NMP-700

NMP-530

NMP-200

NMP-550

NMP-600

NMP-610

NMP-700

Signage

Manager Express

Upload and automatically play

content via the USB port.

ViewSonic Corporation’s QMS & EMS have been registered

to ISO 9001 & ISO 14001, respectively, by TUV NORD.
