VDR-208&216 QUICK MANUAL

Digital Hard Disk Recorde

Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your

requirements or that the operation will be entirely error free or perform precisely as described in the

documentation. This system has not been designed to be used in life-critical situations and must

not be used for this purpose.

Warning: To prevent fire or shock hazard, do not expose the unit to rain or

moisture.

Product specifications subject to change without notice.

Vicon and its logo are registered trademarks of Vicon Industries Inc.

VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NY 11788

TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288)

TOLL FREE: 800-645-9116

24-Hour Technical Support: 800-34-VICON (800-348-4266)

UK: 44 (0) 1489-566300 WEB: www.vicon-cctv.com

Vicon part number 8009-8165-40-00 Rev 206

To prevent fire or shock hazard, do not expose the unit to rain

or moisture.

The symbol is intended to alert the user to the presence of important operating and

maintenance (servicing) instructions in the literature accompanying the unit.

The symbol is intended to alert the user to the presence of uninsulated "dangerous

voltage" within the product's enclosure that may be of sufficient magnitude to constitute a

risk of electric shock to persons.

Warning -- This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial environment.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used

in accordance with the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference in which case

the user will be required to correct the interference at its own expense.

Warning – If TIMEKEEPER NVRAM IC that is consist of RTC, SRAM, POWER-FAIL CONTROL

CIRCUIT and BATTERY is replaced, the replacement is to be done by a trained technician with the

same type of component.

Caution -- Any changes or modifications in construction of this device which are not expressly

approved by the party responsible for compliance could void the user's authority to operate the

equipment.

WARNING

Warranty will be made void if the product is disassembled or manipulated by the user.

Safety Instructions

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings.

Install in accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators,

heat registers, stoves, or other apparatus (including amplifiers)

that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-

type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has

two blades and a third grounding prong. The wide blade or the third prong is provided for your safety.

If the provided plug does not fit into your outlet, consult an electrician for replacement of the

obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience

receptacles, and the point where they exit from the apparatus.

11) Only use attachments/accessories specified by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold

with the apparatus. When a cart is used, use caution when moving the cart/apparatus

combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus

has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been

spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or

moisture, does not operate normally, or has been dropped.

1. Packing list

The following items are included with the VDR-204. Please be certain that all items are included as

soon as you open the box:

1.1 Components

 VDR-208 (Main Assembly) : CD-RW

 Power cable

 Rack mount brackets

 DSUB-15 connector for PTZ / AUX / ALARM

 Quick Manual

 Software CD (RAMS, UniPlayer, MultiViewer, QuickInstaller and Operation Manual)

 Screws

1.2 Options

 Remote control (two battery included)

 Hard disk drive (Option or included)

2. Specifications

Item 8 Channel 16 Channel

Image System NTSC, PAL selectable

Video Channel 8 CH 16 CH

Multi-tasking Quad-plex

Video Output 2 Ch Composite(BNC), 1Ch S-Video, 1 Ch Spot, VGA

Video Compression MPEG-2

Recording Resolution NTSC : 640x240, 320x240

PAL : 640x288, 320x288

Recording Quality 4 Levels (Normal, Enhanced, Fine, Super Fine)

Max Recording Speed 120fps (320*240), 100 fps (30*288), 60 fps (640*240)

50 fps (640*288)

NTSC: 1,2,3,4,5,6,7,8,9,10,15,10,30Time Laps Recording

Interval (FPS) PAL : 1,2,3,4,5,6,7,8,9,10,15,20,25

Recording Mode Schedule, Event (sensor, motion detection),manual,

Continuous

Playback Search Date/Time, Event (Alarm, Motion detection)

Playback Speed x1, x2, x4, x8, x16, x32, x64, x128, Field by Field

(Forward/ Backward)

Slow Motion X1/4, x1/2 (Forward only)

Sensor Input 8 (NO/NC Selectable) 16 (NO/NC Selectable)

Alarm Output 1 (NO/NC)

Aux Control In/Out 2/3 (Selectable Function Menu)

Alarm Reset In, Record Start In, Record ON/OFF, Alarm Out,

Error Out, Record Start Out, Disk Full Out, Record Status Out

Audio 1CH, mono

Network 10Base-T (STATIC,DHCP, PPPoE, E-mail, & FTP)

Motion Detection 12* 12, 8 Level Sensitivity

Hard Disk Max Two HDD

Backup Method CD-RW,USB Memory, Network

Watermarking Still image backup

PTZ Control RS-485

System Log Video Loss, Power On/Off, HDD Full, HDD Fail, Menu called,

Reset HDD, Format, Reset SW Upgrade, E-mail Fail, FTP fail

Language Korean, English, Japanese, French, Spanish

S/W upgarde Network, USB Memory stick

Password Function Power ON/OFF, MENU, Record OFF, Key Lock

Digital Zoom x 2

Timer Built-in real time clock

Remote control Optional

Power Source Free Voltage (100 - 240VAC, 50Hz/60Hz, 70W)

Dimension 433(W) x 385(D) x 88(H)

Operating Temperature 5℃~ 40℃

Weight 7 Kg (w/o HDD)

3. Front view

① CD-RW

② LED Display

 POWER : Power off status is indicated by a Red light and ON status is indicated by

a Green light.

 REC : Green light (Recording)

 ALARM : Green light (Alarm triggered)

 HDD FULL : Green light (No more disk space for recording)

 PTZ : PAN,TILT,ZOOM,FOCUS status is indicated by Green.

③ Numeric button – Live Viewing mode button

 Each numeric button shows each channel No and also converts the channel No

in the “ Live Mode” . In case of 16 ch, each button shows two channel No

alternately.

 MULTI : used to select different types of divided screen in “ Live Mode” .

 SEQ : used to show the input channels in sequence in “ Live Mode”.

Also in “ Motion area setting menu” , used to cancel he area setting.

④ Function button

 POWER : Press this button to power ON/OFF.

 LOCK : Press this button to lock/unlock the buttons of DVR, in order to prevent

the use by Unapproved user. If “ LOCK” button is pressed, DVR is locked, and

it’ s unlocked by inputting correct password.

 ZOOM : Zoom In/Out on the images during Live Viewing.

 FRZ (Freeze)

- Press button once to freeze the frame at live mode. Press again to return.

- To take s still image capture at playback mode.

- Exchange of video input type : Press power button with “ FRZ” button from

NTSC to PAL or PAL to NTSC.

 MISC/SH : Miscellaneous function or Shuttle Hold

 SEARCH : Press once to open the menu to search for recorded files.

 PTZ (Pan/Tilt/Zoom) : Pan/Tilt/Zoom. Press once to access the

Pan/Tilt/Zoom/Focus control mode. Press again to exit.

 MENU : Press button to access Main Menu. Press again to return.

⑤ Direction/select button

 UP : Used to move the cursor up, change possible values in the setup menu; under

PTZ control sub menu, used to move camera; or used to adjust focus.

 DOWN : Used to move the cursor up; changed possible values in the setup menu;

under PTZ control sub menu, used to move camera; or used to adjust focus.

 LEFT : Used to change possible values in the setup menu. Under PTZ control menu,

used to move the camera left or used to do Zoom Out; At playback mode, used to

decrease playback speed.

 RIGHT : Used to change possible values in the setup menu. Under PTZ menu, used

to move the camera left or used to do Zoom In; At playback mode, used to

increase playback speed.

 OK : Used as a selection key. Under PTZ control menu, used to be interchanged

P/T mode with Z/F mode.

⑥ Jog/Shuttle

 Shuttle : Multi-speed forward/reverse playback. Under Network setup sub menu,

used to input parameters fast.

 Jog : Frame by frame search.

⑦ IR receiver

⑧ Recording/Playback buttons

 RECORD : Press once to begin recording all active channels. Press again to end

recording. (except continuous record mode)

 R.PLAY(Reverse Play) : Reverse playback. Press to begin reverse playback. Under

PTZ control menu, used to decrease the speed of Pan, Tilt, Zoom and Focus.

 STOP : Stop playback.

 PLAY : Access to playback.

- Playback button will activate assigned starting position and Channel at playback

setup of menu.

- At pause mode, it will release pause mode.

- Under PTZ control menu, used to increase the speed of Pan, Tilt, Zoom and Focus.

 PAUSE : Press to freeze the picture at playback mode.

⑨ USB

4. Rear panel view.

① USB

② ETHERNET (10Base-T)

③ PTZ/AUX/ALARM/SENSOR

④ VGA and SERIAL

 VGA : Terminal for VGA video output. (DSUB-15 Male Connector)

 SERIAL : Terminal for RS-232C(PC) for console or quick installation. (DSUB-9 Male

Connector)

⑤ AUDIO

 IN/OUT : Terminal for Audio signal IN/OUT.

⑥ VIDEO OUT

 Terminals for composite and s-video to connector with monitor.

⑦ CAMERA

 Up to Sixteen cameras for Video input.

⑧ VIDEO OUT (SPOT and VIDEO2)

 SPOT : User can use this connector for a specific Spot Monitor.

 VIDEO2 : With the Extra Output, user can connector with other monitor.(Same video

image as Video 1)

⑨ FAN

⑩POWER INPUT

5. Basic operation procedures

5.1 Power ON/OFF

 Power ON : Using either the keypad or the remote control, press the “Power” button. (Note:

In case of power outage or rare instance of system failure, the DVR will reboot automatically)

The Power LED light will turn from red to green when it has turned on properly.

In a standby mode, the LED is red.

 Power OFF : In order to shutdown the system, you must type in the password. The default

password for shutdown is “111111”.

5.2 Date & time setting

Set the date and time for the DVR.

(System Setup in Main menu -> Time/Date)

5.3 Password setting procedure

Select or change your password for the DVR. The password must be a 6-digit number

consisting of numbers 0 ~ 8.

(System Setup in Main Menu System Password)

5.4 Recording

 Recording types

Enter in Recording setup of menu. For resolution, select either 640*240 (NTSC), 640*288

(PAL) or 320*240 (NTSC), 320*288 (PAL). Audio channel is synchronized with the selected

video signal. Select Video input quality (Enhance/ Normal/ Fine/ Super fine), Frame rate (120 fps

–NTSC/ 100 fps –PAL), and recording mode. 8 or 16 channels can be selected at the same time.

 Recording modes

Recording mode are made up of MANUAL, CONTINUOUS, MOTION, SENSOR,

MOTION+SENSOR, and SCHEDULE mode. A red record light ( ) on the top right corner of

each channel will indicate DVR recording.

In the MANUAL mode, the DVR starts to record on/off whenever the RECORD button is pressed.

Refer to the article 3.2.2.6 for details of Record mode.

5.5 Playback

 The DVR will playback either the first recorded file or the last recorded file according to the

setting in the Playback Setup menu.

Otros manuales para VDR-208

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de DVR de Vicon

Vicon

Vicon 4CH Manual de usuario

Vicon

Vicon Kollector Pro Manual de usuario

Vicon

Vicon VN-VIEWER-64 Manual de usuario

Vicon

Vicon Kollector Elite KE12 Manual de usuario

Vicon

Vicon VDR-208 Manual de usuario

Vicon

Vicon VDR-404 Manual de usuario

Vicon

Vicon 4CH Manual de usuario

Vicon

Vicon Valerus Shadow Elite Manual de usuario

Vicon

Vicon 301-00-00 Series Manual de usuario

Vicon

Vicon KollectorProXG XX128-03-00 Manual de usuario

Vicon

Vicon VDR-204 Manual de usuario

Vicon

Vicon Kollector Elite Manual de usuario

Vicon

Vicon VCR30RT Manual de usuario

Vicon

Vicon Kollector Elite Manual de usuario

Vicon

Vicon kollector KOL-8000 Manual de usuario

Vicon

Vicon VDR-204 Guía de instalación

Vicon

Vicon iSCSI RAID Manual técnico

Vicon

Vicon 301-20-00 Series Manual de usuario

Vicon

Vicon VDR-304 Manual de usuario

Vicon

Vicon Express Manual de usuario

Vicon

Vicon ViconNet JUMP Manual de usuario

Vicon

Vicon AurorAcord Manual de usuario

Vicon

Vicon VN-NVR Shadow Manual de usuario

Vicon

Vicon KollectorLite XG Manual de usuario

Manuales populares de DVR de otras marcas

FLIR

FLIR M3100E Series Manual de usuario

VTRACKPRO

VTRACKPRO FPRO300 Manual de usuario

Swann

Swann NVR-7085 models Manual de usuario

XtendLan

XtendLan DVR-1670C Manual de usuario

urmet domus

urmet domus 1093/004AHD Manual de usuario

Holux

Holux M1 Manual de usuario

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Manual de usuario

Whistler

Whistler D16VRS Manual de usuario

Defender Security

Defender Security 82-20235 Manual de usuario

MISUMI

MISUMI MP-WF100M Manual de usuario

Speco

Speco D8HU Manual de usuario

UST

UST DDR-E04AA Instrucciones de uso

Consolidated

Consolidated Digital Video Recorder Manual de usuario

Mace

Mace DVR0404RW Guía de inicio rápido

RCA

RCA RTD315W Manual de usuario

FSM

FSM Colibri Grande PRO Manual de usuario

Hauppauge

Hauppauge HD PVR 2 Manual de usuario

Identivision

Identivision ICR-PH161i PIONEER Manual de usuario
