X532
MODEL V20A
POLE MOUNTING ADAPTER
Copyright © 1998 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
Vicon Part No. 8006-8532-01-00 Section 7 Rev 998
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TELEPHONE: 516-952-CCTV (2288) FACSIMILE: 516-951-CCTV (2288)
TOLL FREE: 800-645-9116 UK: 44/(0) 1489-566300 INFOFAX: 800-287-1207
Dear Valued Customer:
Thank you for selecting Vicon systems and products for your video
needs.
Since Vicon’s beginning in 1967, our only business has been the
design, engineering, and production of the highest quality video systems
and equipment for use in a wide variety of security, safety, control,
surveillance, and communication applications.
We stand behind the quality and dependability of every product
with an industry leading Beneficial Use warranty.
If you are not satisfied with a Vicon product or service, I would like
to know. Your complete satisfaction is the mission of every Vicon
employee.
Sincerely,
Kenneth M. Darby
President
X523 Rev 998 V20A Pole Mounting Adapter Contents •• i
Contents
Introduction.......................................................................................................................................1
Installation..........................................................................................................................................3
Unpacking and Inspection ...................................................................................................................3
Inspection For Visible Damage.............................................................................................................3
Inspection For Concealed Damage.......................................................................................................3
Installation Preparation.......................................................................................................................3
Bracket-to-Plate Installation.................................................................................................................4
Plate-to-Pole Installation .....................................................................................................................5
Extending the Chain Length................................................................................................................7
Maintenance......................................................................................................................................7
Shipping Instructions......................................................................................................................8
Technical Information.....................................................................................................................9
ii •• List of Figures X523 Rev 998 V20A Pole Mounting Adapter
List of Figures
Figure 1
Installing the Pole Mount Brackets to the Pole Adapter Plate.................................................................5
Figure 2
Pole Mounting Adapter Assembly Installation.........................................................................................6
Figure 3
Connecting Chain Link Installation.........................................................................................................7
X523 Rev 998 V20A Pole Mounting Adapter Introduction •• 1
Introduction
The information in this instruction manual covers the installation of Model V20A Pole Mounting Adapter. This unit
should only be installed by a qualified technician using approved materials in accordance with national, state
and local codes. Read this manual through completely before attempting installation.
The Model V20A Pole Mounting Adapter is a heavy-duty unit that accommodates Vicon’s medium-and heavy-
duty wall mounts for outdoor installation. Compatible mounts are V24WM, V2400WM, V2400AWM, V1600WM,
V2000WM, V7UWM, and V5UWM.
Designed to be installed on a pole with a minimum diameter of 3 inches (7.6 cm) and a maximum diameter of 10
inches (25 cm), the V20A with a wall mount attached can support a complete camera system, including a dome
system or a pan-and-tilt drive and camera housing with camera, up to the load rating of the particular wall mount
being used. Constructed of heavy-duty steel, the pole mounting adapter with an attached wall mount provides a
sturdy installation that is capable of withstanding extreme weather conditions.
X523 Rev 998 V20A Pole Mounting Adapter Installation •• 3
Installation
Unpacking and Inspection
All Vicon equipment is tested and inspected before leaving the factory. It is the carrier’s responsibility to deliver
the equipment in the same condition as it left the factory.
Inspection For Visible Damage
Immediately inspect the cartons upon delivery. Make a note of any visible damage on all copies of the carrier’s
freight bill.
Make sure the carrier’s agent (the person making the delivery) signs the note on all copies of the bill. If the agent
does not have claim forms, contact the carrier’s office.
Inspection For Concealed Damage
As soon as possible after delivery, unpack the unit and inspect it for concealed damage. Do not discard the
carton or packing materials. If the unit is damaged, contact the carrier immediately and request forms for filing a
damage claim. Make arrangements for a representative of the carrier to inspect the damaged equipment.
If the equipment must be returned for repair, follow the Shipping Instructions at the end of this manual.
Installation Preparation
Note: Use stainless steel hardware for all outdoor mountings.
Before beginning installation, run all necessary cabling to the location selected for the installation.
The V20A Pole Mounting Adapter has a variety of mounting holes to accommodate a variety of Vicon mounts,
pan-and-tilt drives, scanners and housings. The V20A consists of a pole adapter plate, two pole mount brackets,
an 18-and 24-inch chain (with two tension nuts and brackets and extension links), two hex-head bolts and eight
4•• Installation X523 Rev 998 V20A Pole Mounting Adapter
each 5/16-18 screws, nuts, lock washers and flat washers. The accessory kit is provided with three strain relief
plugs, two liquid tight fittings, and a compression fitting.
Table 1
Mounting Components
Item No. Component Quantity Function
1Pole adapter plate 1Secures wall mount
to pole
2Pole mount bracket 2Secures pole adapter
plate to pole
318-inch chain 2Secures pole adapter
assembly to pole
424-inch chain 2Secures pole adapter
assembly to pole
5Hex-head bolt
(5/16-18 x 2-1/2) 2Secures pole
adapter/chain
assembly to pole
6Tension nut 2Secures item 5
7Tension bracket 2Secures item 5
85/16-18 x 1 screw 8 (6 used) Secures item 2 to 1
95/16-18 nut 8 (6 used) Secures item 8
10 5/16 lock washer 8 (6 used) Secures item 8
11 Flat washer 8 (6 used) Secures item 8
12 Strain relief plugs 3Plugs unused cable
entries
13 Liquid-tight fitting
(large) 1Seals cable access
14 Liquid-tight fitting
(small) 2Seals cable access
15 Chain link 2Allows lengthening of
chain
Bracket-to-Plate Installation
1. Assemble the two (2) adapter brackets to each side of the pole adapter plate using the screws, nuts, lock
washers and flat washers provided (3 on each side). Refer to Figure 1 and Table 1.
Note: Specific installation circumstances may dictate whether the required wall mount should be installed before
or after the pole adapter is in place on the pole.
2. If it is appropriate at this time, mount the selected wall mount to the pole adapter plate. Refer to the
instruction manual for the particular wall mount for installation instructions.
