VIA Mainboard VB7007 Manual de usuario

January 13, 2011 Version 1.04

Operating Guide

VB7007 Mainboard

VB7007 Operating Guide

January 13, 2011 - i - Version 1.04

Table of Contents

Table of Contents ..................................................................................................................i

VIA VB7007 Overview...........................................................................................................1

VIA VB7007 Layout (Top and ide Views)................................................................................2

VIA VB7007 pecifications.....................................................................................................3

VIA VB7007 Processor KU ...................................................................................................4

VIA VB7007 I/O Back Panel Layout.........................................................................................5

VIA VB7007 Dimensions & Mounting Holes ..............................................................................6

VIA VB7007 Layout & Height Distribution ................................................................................8

Power Consumption..............................................................................................................9

VB7007 C7_D 16000 .........................................................................................................9

A. Playing DVDs with PowerDVD 5.0 .................................................................................9

B. Playing MP3 with Media Player......................................................................................9

C. Running Network Applications - Copying Files (VT6103L) .................................................9

D. Running Network Applications - Copying Files (VT6107) ..................................................9

E. Idle tate................................................................................................................. 10

F. Running C.C. Winstone 2004 ...................................................................................... 10

G. 3 Mode.................................................................................................................. 10

VB7007 C7 10000 ........................................................................................................... 11

A. Playing DVDs with PowerDVD 5.0 ............................................................................... 11

B. Playing MP3 with Media Player.................................................................................... 11

C. Running Network Applications - Copying Files (VT6103L) ...............................................11

D. Running Network Applications - Copying Files (VT6107) ................................................11

E. Idle tate................................................................................................................. 11

F. Running C.C. Winstone 2004 ...................................................................................... 12

G. 3 Mode.................................................................................................................. 12

Power pecifications ...........................................................................................................13

VIA VB7007 Microsoft and Linux Driver upport ..................................................................... 14

Microsoft Driver upport................................................................................................... 14

Linux Driver upport........................................................................................................ 14

Contact ............................................................................................................................. 15

VB7007 Operating Guide

January 13, 2011 - 1 - Version 1.04

VIA VB7007 Overview

The VIA VB7007 Mini-ITX mainboard is a compact native x86 platform for PO and kiosk

applications. The mainboard is based on the VIA CN700 chipset featuring the VIA UniChrome™ Pro

II IGP with 2D/3D graphics and video accelerators for rich digital media performance.

The VIA VB7007 onboard VIA C7 processor is a powerful, secure, and efficient processor with its

included VIA Padlock ecurity Engine, VIA Cool tream™ Architecture, VIA tepAhead™ Technology

uite, and VIA TwinTurbo™ technology.

The VIA VB7007 delivers the performance levels with its included sizeable support of up to 1 GB of

533 MHz DDR2 memory and native support for ATA 3Gb/s storage devices. High-bandwidth

connectivity is supported with the included eight U B 2.0 ports and two Fast Ethernet LAN ports

on the back panel. Four additional U B 2.0 ports are available through the onboard pin

connectors.

The VIA VB7007 is fully compatible with Microsoft

and Linux operating systems and is available in

a variety of configurations.

One of the Fast Ethernet ports can be exchanged for a Gigabit LAN as a manufacturing option.

VB7007 Operating Guide

January 13, 2011 - 2 - Version 1.04

VIA VB7007 Layout (Top and Side Views)

SATA Clear CMOS

Front Panel

IDE

CN700 North Bridge

VIA C7 proce or

DDR2 Memory lot

DIO

Buzzer

SMBu

Battery

VT8237S South Bridge

PCI

CPU_Fan

SYS_Fan

SPDIF

Front Audio

KB/MS

ATX Power

USB_2/3

USB_0/1

LVDS Panel

IVDD_SEL

PVDD

Inverter

COM2

COM4

FIR

COM3

VB7007 Operating Guide

January 13, 2011 - 3 - Version 1.04

VIA VB7007 Spe ifi ations

Model Name - VB7007-16 - VB7007-10E

Processor - VIA C7

-D 1.6 GHz anoBGA2 processor - VIA C7

1.0 GHz anoBGA2 processor

Chipset - VIA C 700 orth Bridge

- VIA VT8237S South Bridge

System Memory - 1 x DDR2 533/667

DIMM slot

- Up to 1 GB memory size

VGA - VIA UniChrome™ Pro II Integrated Graphics with 2D/3D and MPEG-2 accelerators

Onboard Storage - 1 x UltraDMA 133/100/66/33 connector

- 2 x SATA 3Gb/s connectors

Expansion Slots - 1 x PCI slot

Onboard LAN - 1 x VIA VT6103L 10/100 Mbps Fast Ethernet PHY

- 1 x VIA VT6107 10/100 Mbps Fast Ethernet controller or

1 x VIA VT6122 PCI Gigabit Ethernet Controller

Onboard Audio - VIA VT1708B High Definition audio codec

Onboard /O Connectors - 3 x COM pin headers (with 5V/12V select)

- 1 x digital I/O pin header

- 2 x USB pin headers (4 additional ports)

- 1 x SMBus pin header

- 1 x S/PDIF-out connector

- 1 x Dual-channel LVDS panel connector (18/24-bit)

- 1 x LVDS panel power selector (5V/3.3V)

- 1 x LVDS inverter pin header

- 1 x LVDS inverter power selector (5V/12V)

- 1 x FIR pin header

- 2 x fan connectors (CPU and SYS)

- 1 x fan panel connector

- 1 x front panel audio pin header

- 1 x ATX power connector

Back Panel /O - 1 x VGA port

- 1 x COM port

- 1 x parallel port

- 2 x RJ45 LA ports

- 4 x USB 2.0 ports

- 3 x audio jacks: Line-in, Line-out, and MIC-in

- 2 x PS/2 ports: keyboard and mouse

- 4 x USB 2.0 ports

B OS - Award BIOS

- SPI 4/8 Mbit flash memory

Operating System Windows 2000/XP, Linux, Win CE/XPe

System Monitoring &

Management

- Wake-on LA , keyboard, and mouse

- RTC Timer

- System power management, AC Power failure recovery

Operating Temperature 0°C ~ 50°C

Operating Humidity 0% ~ 95% (relative humidity; non-condensing)

Form Factor - Mini-ITX (17 cm x 17 cm)

Specifications subject to change without notice.

DD 2 667 MHz memory modules can be used, but the effective speed will be 533 MHz.

Manufacturing option

VB7007 Operating Guide

January 13, 2011 - 4 - Version 1.04

VIA VB7007 Pro essor SKU

The VIA VB7007 is available in the following speed grade:

•1.6 GHz VIA C7

-D NanoBGA2 Processor

•1.0 GHz VIA C7

NanoBGA2 Processor

VB7007 Operating Guide

January 13, 2011 - 5 - Version 1.04

VIA VB7007 I/O Ba k Panel Layout

The VIA VB7007 mainboard comes in the compact dimensions of 17 cm x 17 cm. Its integrated

design supports most of the standard legacy x86 connectivity options through its onboard pin

connectors. Its back panel IO includes one P /2 mouse port, one P /2 keyboard port, one parallel

port, one VGA port, one COM port, four standard U B 2.0 ports, two RJ45 LAN ports, and three

audio jacks (Line-in, Line-out, and MIC-in).

VB7007 Operating Guide

January 13, 2011 - 6 - Version 1.04

VIA VB7007 Dimensions & Mounting Holes

VB7007 Operating Guide

January 13, 2011 - 7 - Version 1.04

VB7007 Operating Guide

January 13, 2011 - 8 - Version 1.04

VIA VB7007 Layout & Height Distribution
