VEVOR 4X3X2.75 Manual de usuario

Technical Support and E-Warranty Certificate

www.vevor.com/support

SPRAY PAINT BOOTH

USER MANUAL

We continue to be committed to offering tools at competitive prices. "Save Half", "Half Price",

or any other similar expressions used by us only represent an estimate of savings you might

benefit from buying certain tools with us compared to the major top brands and do not

necessarily mean to cover all categories of tools offered by us. You are kindly reminded to

verify carefully when placing an order with us if you are saving half in comparison with the top

major brands.

MODEL:4X3X2.75 / 6X3X2.5 / 7X4X2.75

8X4.5X3.3 / 8.5X4.8X3.3 / 10X6X4

Have product questions? Need technical support? Please feel free to

CustomerService@vevor.com

NEED HELP? CONTACT US!

This is the original instruction, please read all manual instructions carefully

before operating. VEVOR reserves a clear interpretation of our user manual. The

appearance of the product shall be subject to the product you received. Please

forgive us that we won't inform you again if there are any technology or software

updates on our product.

SPRAY PAINT

BOOTH

1、Safe Instructions

WARNING:

1) Avoid using this product in rain, strong wind, hail, and other bad weather.

2) Avoid sharp points, blades, and other items to scratch the product.

3) Keep away from fire sources.

4) The air inside the tent is scarce, so good ventilation must be ensured when

painting inside the tent.

5）Due to the large size of this product, installation requires 2 to 4 people to

assist.

CAUTION: Carefully read instructions and procedures for safe operations.

2、

PRODUCT INTRODUCTION

4X3X2.75 6X3X2.5 7X4X2.75 8X4.5X3.3 8.5X4.8X3.3 10X6X4

Size 13*10*9ft 20*10*8ft 23*13*8.5ft 26*15*11ft 28*16*11ft 33*20*13ft

Material

210D

Oxford-

fabric

210D

Oxford-

fabric

210D

Oxford-

fabric

210D

Oxford-

fabric

210D

Oxford-

fabric

210D

Oxford-

fabric

Color Blue Blue Blue Blue Blue Blue

Input

voltage

120V~

60Hz(USA)

220-240V~

50Hz(EUR/

AUS)

120V~

60Hz(USA)

220-240V~

50Hz(EUR/

AUS)

120V~

60Hz(USA)

220-240V~

50Hz(EUR/

AUS)

120V~

60Hz(USA)

220-240V~

50Hz(EUR/

AUS)

120V~

60Hz(USA)

220-240V~

50Hz(EUR/

AUS)

120V~

60Hz(USA)

220-240V~

50Hz(EUR/

AUS)

Inflation

blower

power

950W 750W 750W 950W 950W 1100W

Ventilation

blower

power

/480W

(USA)

480W

(USA)

750W

(USA)

750W

(USA)

950W

(USA)

/550W(EUR

/AUS)

550W(EUR

/AUS)

750W(EUR

/AUS)

750W(EUR

/AUS)

950W(EUR

/AUS)

G.W 25.4kg 36.2kg 44.4kg 56kg 57.4kg 74.6kg

N.W 21.6kg 31kg 39kg 50kg 51.2kg 67.6kg

Model

SPEC.

3、

PACKAGE CONTENT

4X3X2.75

6X3X2.5

7X4X2.75

8X4.5X3.3

8.5X4.8X3.3

10X6X4

Spray paint

booth

×1

inflation

blower

×1

Ventilation

blower

×1

Storage bag

×1

Sand bags

×4

×6

Stakes

×4

×6

Ropes

×4

×6

Pack of repair

patches

×1

model

Parts

PRODUCT DIAGRAM

1. Front Door 2. Air Column

3. Light Hook 4. Ceiling

5. Rope Ring 6. Activated Carbon Filter Cotton

7. Handle 8. Ventilating Tube

9. Air Column Filling Tube 10.Air Blower

11. Transparent Window 12. Emergency Escape Window

13. Double Filter Cotton 14. Exhaust Zipper Port

15. Bottom 16. Metal Ring

17. Power Line Inlet

5.INSTALLATION INSTRUCTION

1. Unfold the tent and

spread it out on a clean

and level ground.

2.Zip up both sides of the

product.

3. Tie the rope to the

rope ring.

4. Tie the air tube to the

air blower outlet, as

shown in the figure. 1 is

the ventilation blower; 2

is the inflation blower.

5. When the tent is

inflated, please fasten

the tent with stakes at the

bottom metal rings.

6. When the assembly is

complete, please tie the

windproof rope to the

fixed object.

6、Storage Instruction

It is recommended to store the product when it is dry to avoid dampness and

mildew.

It is recommended to put them in a storage bag and store them in a dry

environment.

Keep away from sharp objects to avoiding scratching.

After wet weather, it is recommended to air the tent on sunny days.

1.Unzip and open the

front and back doors.

2. Turn off the air

blowers and open both

exhaust zipper ports.

3. Drain all air and

flatten the tent as

shown below.

4. Roll up the tent, as

shown in the figure

5. Roll up the tent with

ropes.

6. Put it into a storage

bag and place in dry

environment.

7 Direction for Use

1) This product is only a simple tool room for painting and can not be used in

windy and rainy days.

2) The product requires the blower to keep inflating , and do not to cut off the

power supply.

3) In case of power failure, please escape through the front door or safety window

or back door.

4) In case of emergency, you can cut through the tent with a knife to escape.

5) It is recommended to choose a flat and clean open ground to use this product.

6) If the tent shakes too much in the wind, please use the windproof ropes and

stakes to fix the tent.

7) After repeated use, the ventilation of the tent may become poor. At this time,

the inner blue filter cotton can be removed or replaced to improve the ventilation.

8) If it is difficult to inflate the tent, zip up the front and back doors, turn on the

Ventilation blower to inflate the tent, and then turn on the Inflation blower to fully

inflate the tent.

8.Maintenance, Repair, and Troubleshooting

1) When the product is finished, it is recommended to dry the tent and put it away.

2) If the product is stored in a humid environment, it is recommended to take it out

to open it in sunny weathers.

3) If the product is torn, please repair it with the accompanying material and tools.

Troubleshooting

problem

cause

solution

Blower does

not work

·Voltage mismatch

·No power supply

·The blower switch is not on

·Voltage need to match

·Turn the power

·Turn on the blower

Lack of tent

pressure

·Voltage instability

·The air tube is connected to

a wrong blower

·Both exhaust ports are not

zipped properly

·Supply a stable voltage

·Connect the air tube to the

inflation blower

·Zip both sides of the exhaust

ports

Importer: WAITCHX

Address: 250 bis boulevard Saint-Germain 75007 Paris

Importer: FREE MOOD LTD

Address: 2 Holywell Lane, London, England, EC2A 3ET

Made in China

Manufacturer: Guangzhou Yijia Inflatable Co., Ltd

Add: No. 1, Lirong Road, Shiling Town, Huadu District, Guangzhou, China
