VEVOR LB360TA Instrucciones de instalación y funcionamiento
Technical Support and E-Warranty Certificate www.vevor.com/support
ICE-MAKING MACHINE
INSTALLATION MAINTENANCE
INSTRUCTIONS
MODEL:LB360TA/LB400TA/LB440TA/LB550TA
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and doses not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
MODEL:LB360TA/LB400TA/LB440TA/LB550TA
Have product questions? Need technical support? Please feel free to
contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
ICE-MAKING MACHINE
- 2 -
SAFETY PRECAUTION
Before the appliance is used, please read the manual carefully. To
reduce the risk of fire, electrical shock or injury when using the
appliance, follow basic precaution, including the following:
DANGER:
Read all instructions before using the ice-making machine.
Plug into a grounded 3-prong outlet, do not remove grounding prong, do not
use an adapter, and do not use an extension cord.
It is recommended that a separate circuit, serving only your appliance be
provided. Use an outlet that cannot be turned off by a switch.
Never clean appliance parts with flammable fluids. These fumes can create a
fire hazard or explosion. And do not store or use gasoline or other flammable
vapours and liquids in the vicinity of this or any other appliance. The fumes
can create a fire hazard or explosion.
Before proceeding with cleaning and maintenance operations, make sure the
power line of the unit is disconnected.
Do not connect or disconnect the electric plug when your hands are wet.
Unplug the appliance or disconnect power before cleaning or servicing.
Failure to do so can result in electrical shock or death.
Do not attempt to repair or replace any part of your appliance unless it is
specifically recommended in this material. All other servicing should be
referred to a qualified technician.
To prevent a child from being entrapped, Keep out of reach of children and
- 3 -
not in the vicinity of ice-making machine.
Before you throw away your old ice-making machine, take off the door but
leave the shelves in place so that children may not easily climb inside.
Never allow children to operate, play with, or crawl inside the appliance.
Warning：
This machine should be operated by professionals or trained personnel;
Make sure the machine is reliably connected to the ground to keep safe
Use the power consistent with the one in the nameplate, and the bias voltage
is less than ± 10% of the rated voltage. The professionals must do the wiring;
If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.;
Before maintaining the machine, make sure you have cut off the power;
Don’t wet or sprinkle the liquid onto the plugs, motors, or other electrical parts
to avoid electric shock;
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
FLAMMABLE REFRIGERANT
For your safety observe the following recommendations.
- 4 -
This appliance contains a small quantity of R290/R600a ice-making machine
which is environmentally friendly, but flammable. It does not damage the
ozone layer, nor does it increase the greenhouse effect.
During transportation and installation, ensure that the tubing of the refrigerant
circuit is not damaged.
when handling, moving and use of the refrigerator or freezer to avoid either
damaging the refrigerant tubing or increasing the risk of a leak.
Avoid using or manipulating sharp objects near by the appliances.
Leaking refrigerant can ignite and may damage the eyes.
In the event any damage does occur, avoid exposure to open fires and any
device which creates a spark. Disconnect the appliance from the mains
power.
Thoroughly ventilate the room in which the appliance is located for several
minutes.
Notify Customer Service for necessary action and advice.
The ice-making machine quantity contained in this appliance is listed above in
grams; it is also noted on the Rating Plate of the appliance.
WARNING: During using, service and disposal the
appliance, please pay attention to symbol similar as
left side, which is located on rear of appliance (rear
panel or compressor) and with yellow or orange color. It’s risk of fire
warning symbol. There are flammable materials in refrigerant pipes and
- 5 -
compressor. Please be far away fire source during using, service and
disposal.
Note:
Please keep the water or other conductive liquids away from the machine;
Don’t stick clubs into the machine;
During the movement of the machine, it should be carefully carried at an
angle of less than 45 degrees.
Prohibit water discharge pipe or water supply pipe from being bent so that the
pipes are damaged and water leaks out from the pipes.
The distance between the air outlets and the wall should be over 20 cm.
Besides, keep good ventilation and ensure the machine is dry and clean.
FCC STATEMENT: This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:(1)This device may not
cause harmful interference, and (2)this device must accept any interference
received, including interference that may cause undesired operation.
SAVE THESE INSTRUCTIONS
- 6 -
BASIC PARAMETER
Model
LB360TA
LB400TA
LB440TA
LB550TA
Power
700W
800W
1000W
1000W
Max ice
production
capacity
≥360
≥400
≥440
≥500
Number of ice
cells
12*13=156
PCS
12*13=156
PCS
13*14=182
PCS
13*14=182
PCS
Input
AC115V 60Hz
Ice size
22*22*22mm
Ice storage
capacity
Theoretical ice storage: 150Kg;
Automatic ice filling: 100Kg
Operator
schema
Touch Screen
Screen size
3.5-inch resistive display
Climate type
SN、N、ST
- 7 -
A
B
C
D
E
F
G
LB360TA
560
585
910
100
1570
615
837
LB400TA
560
585
910
100
1570
615
837
LB440TA
560
585
910
100
1570
615
837
LB550TA
560
585
910
100
1570
615
837
BASIC STRUCTURE
Split type
No.
Name
No.
Name
1
Top panel
8
Ventilation window
2
Water pump
9
Water supply valve
3
Water level sensor
10
Condenser
4
Front panel
11
Fan motor
5
Control panel
12
Compressor
6
Evaporator
13
Deicing solenoid valve
7
Right panel
14
Water storage tank
- 8 -
INSTALLATION
Open the case, move the machine to a appropriate location. Check the packing list
and the contents, if they are different, please inquire your dealer.
2. Operating environment
A. Environment temperature：SN、N：10℃～38℃
Environment humidity: relative humidity ≤90%
- 9 -
The distance between the air outlets and the wall should be over 20 cm. Besides,
keep good ventilation and ensure the machine is dry and clean. The position to
place the ice maker must be far away from the heat source, such as a bake oven、
electric cooker, etc.
B. Water source is suitable for the sanitary standards, the water temperature
and pressure is suitable. For getting the biggest efficiency, the inlet water
temperature value should be 0.6~32℃, and the pressure should be 0.138～
0.552MPa.
C. There should be a sewer. While working, some of the water will be
discharged, so the sewer is necessary. Furthermore, the sewer must be kept
unblocked.
