Vertiv Liebert GXT5-500LVRT2UXL Guía del usuario

Liebert®

GXT5™ UPS

Installer/User Guide

120V, 500 VA to 3,000 VA

Vertiv | Liebert® GXT5™ Installer/User Guide

Technical Support Site

If you encounter any installation or operational issues with your product, check the pertinent

section of this manual to see if the issue can be resolved by following outlined procedures.

Visit https://www.Vertiv.com/en-us/support/ for additional assistance.

The information contained in this document is subject to change

without notice and may not be suitable for all applications. While

every precaution has been taken to ensure the accuracy and

completeness of this document, Vertiv assumes no responsibility

and disclaims all liability for damages resulting from use of this

information or for any errors or omissions. Refer to other local

practices or building codes as applicable for the correct methods,

tools, and materials to be used in performing procedures not

specifically described in this document.

The products covered by this instruction manual are manufactured

and/or sold by Vertiv. This document is the property of Vertiv and

contains confidential and proprietary information owned by Vertiv.

Any copying, use or disclosure of it without the written permission

of Vertiv is strictly prohibited.

Names of companies and products are trademarks or registered

trademarks of the respective companies. Any questions regarding

usage of trademark names should be directed to the original

manufacturer.

TABLE OF CONTENTS

Important Safety Information 1

1 GXT5 Description 3

1.1 UPS Features and Available Models 3

1.2 Front Panels 4

1.3 Rear Panels 4

1.4 Battery Cabinet 7

1.5 Major Internal Components and Operating Principle 7

1.6 UPS States and Operating Modes 9

1.6.1 Normal Mode 9

1.6.2 Bypass Mode 10

1.6.3 Battery Mode 10

1.6.4 Frequency Converter Mode 10

1.6.5 ECO Mode 10

2 Installation 11

2.1 Unpacking and Inspection 11

2.2 Pre-installation Preparation 11

2.2.1 Installation Clearances 11

2.3 Installing the UPS 11

2.3.1 Tower Installation 12

2.3.2 Rack Installation 12

2.4 Installing External Battery Cabinets 12

2.5 Connecting AC Input Power 15

2.6 Connecting Loads 15

2.7 Communication Connections 15

2.7.1 Connecting IntelliSlot Communication 16

2.7.2 Connecting to the Dry-contact Port 16

2.7.3 Connecting a Remote Emergency Power-off (REPO) Switch 17

2.7.4 Connecting a USB Cable 18

2.7.5 Connecting CLI Communication Cables 18

2.7.6 Connecting Sensors to the Control Port 19

3 Operating the UPS 21

3.1 Silencingthe Audible Alarm 21

3.2 Starting-up the UPS 21

3.3 Transferring to Battery Mode 22

3.4 Transferring from Normal to Bypass Mode 22

3.5 Transferring from Bypass to Normal Mode 22

3.6 Shutting-down the UPS Completely 22

3.7 Remote Emergency Power-off (REPO) 22

4 Operation and Display Panel 23

4.1 LED Indicators 25

Vertiv | Liebert® GXT5™ Installer/User Guide | iii

4.2 LCD Menu and Screens 25

4.2.1 Start-up and Flow Screens 25

4.2.2 Main Menu 26

4.3 Editing Display and Operation Settings 41

4.3.1 Changing the Password 41

4.3.2 Selecting the Display Language 42

4.3.3 Setting the Date and Time 42

5 Maintenance 43

5.1 Replacing Batteries 43

5.2 Charging Batteries 45

5.3 Checking UPS Operation 46

5.4 Cleaning the UPS 46

6 Troubleshooting 47

6.1 Symptoms that Require Troubleshooting 47

6.2 Audible Alarm (Buzzer) 47

6.2.1 Faults 47

6.3 Troubleshooting UPS Issues 48

7 Specifications 49

7.1 Battery Run Times 54

Appendices 57

Appendix A: Technical Support 57

Vertiv | Liebert® GXT5™ Installer/User Guide | iv

IMPORTANT SAFETY INFORMATION

IMPORTANT! This manual contains important safety instructions that must be followed during the

installation and maintenance of the UPS and batteries. Read this manual thoroughly and the safety and

regulatory information, available at https://www.vertivco.com/ComplianceRegulatoryInfo, before

attempting to install, connect to supply, or operate this UPS.

Vertiv | Liebert® GXT5™ Installer/User Guide

This page intentionally left blank

1 GXT5 DESCRIPTION

The Liebert® GXT5 is a compact, online uninterruptible power system (UPS) that continuously conditions

and regulates its output voltage. The Liebert® GXT5 supplies microcomputers and other sensitive

equipment with clean sine-wave input power.

Upon generation, AC power is clean and stable. However, during transmission and distribution it is subject

to voltage sags, spikes, and complete failure that may interrupt computer operations, cause data loss, and

damage equipment.

The Liebert® GXT5 protects equipment from these disturbances. The Liebert® GXT5 continuously

charges its batteries from the utility power, enabling it to supply power to connected loads, even when the

mains fail.

1.1 UPS Features and Available Models

The GXT5 includes the following features. Table 1.1 below, lists the available models and power ratings.

•Enhanced load capacity with an output power factor of 1.

•Input power factor greater than 0.99

•Optional tower or rack installation to meet varying installation requirements.

•Adapts to areas with unstable power-mains supply via high-frequency double-conversion

topology structure, with high input-power factor, wide input-voltage range, and output

immune to grid interference.

•Full digital-control platform and hardware-design platform adapts to unstable mains supply

and load impact

•Programmable terminals with cascade protection protect key devices when load is heavy.

•Operation and display panel with model-specific color LCD offers simple configuration and

control of the UPS.

•ECO power-supply mode and smart-sleep mode help you save the maximum amount of energy.

MODEL NUMBER NOMINAL POWER RATING

GXT5-500LVRT2UXL 500VA/500W

GXT5-750LVRT2UXL 750VA/750W

GXT5-1000LVRT2UXL 1000VA/1000W

GXT5-1500LVRT2UXL 1500VA/1350W

GXT5-2000LVRT2UXL 2000VA/1800W

GXT5-3000LVRT2UXL 3000VA/2700W

Table 1.1 UPS Models and Power Ratings

1 GXT5 Description 3

1.2 Front Panels

The various GXT5 models have the same general appearance, with the main difference being the

receptacle types on the rear panel.

Figure 1.1 Front View

1.3 Rear Panels

The following figures detail the rear-panel features for each GXT5 model.

Figure 1.2 GXT5-500/750/1000/1500LVRT2UXL Rear Panel

ITEM DESCRIPTION

1 Liebert® IntelliSlot™ port

2 USB port

3 RS-485 port

4 External-battery connector

5 Non-programmable output receptacles, IEC-60906-1 15-A

6 Programmable output receptacles, IEC-60906-1 15-A

7 Input circuit breaker

8 Input-power plug and cable, IEC-60906-1 15-A

9 RS-232 port

10 Terminal-block communication connectors

Vertiv | Liebert® GXT5™ Installer/User Guide

Figure 1.3 GXT5-2000LVRT2UXL Rear Panel

ITEM DESCRIPTION

1 Liebert® IntelliSlot™ port

2 USB port

3 RS-485 port

4 External-battery connector

5 Non-programmable output receptacles, IEC-60906-1 20-A

6 Programmable output receptacles

7 Input circuit breaker

8 Input-power plug and cable, L5-20P

9 RS-232 port

10 Terminal-block communication connectors

11 Output-power plug and cable, L5-20R

1 GXT5 Description 5

Figure 1.4 GXT5-3000LVRT2UXL Rear Panel

ITEM DESCRIPTION

1 Liebert® IntelliSlot™ port

2 USB port

3 RS-485 port

4 External-battery connector

5 Non-programmable output receptacles, IEC-60906-1 20-A

6 Programmable output receptacles

7 Output circuit breakers

8 Input-power plug and cable, L5-30P

9 RS-232 port

10 Terminal-block communication connectors

11 Output-power plug and cable, L5-30R

12 Input circuit breaker

13 Cooling fan

Vertiv | Liebert® GXT5™ Installer/User Guide
