VentAHood RM1000 Manual de funcionamiento
Owner and Maintenance Guide
Models Equipped with External
Blower RM1000/RM1500
Thank You For Choosing Vent-A-Hood®
We know you will be pleased with your purchase decision.
Since 1933, our company has earned an outstanding reputation
because of our commitment to performance, quality, and
reliability.
Safety
READ AND SAVE THESE INSTRUCTIONS
WARNING - TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK, OR INJURY TO PERSONS, OBSERVE THE
FOLLOWING:
A. Use this unit only in the manner intended by the manufacturer.
If you have questions, call the manufacturer.
B. Before servicing or cleaning unit, switch power off at service panel
and lock the service disconnecting means to prevent power from
being switched on accidentally. When the service disconnecting
means cannot be locked, securely fasten a prominent warning
device, such as a tag, to the service panel.
C. Installationworkandelectricalwiringmustbedonebyqualied
person(s) in accordance with all applicable codes and standards,
includingre-relatedconstruction.
D. Sufcientairisneededforpropercombustionandexhausting
ofgasesthroughtheue(chimney)offuelburningequipment
to prevent back drafting. Follow the heating equipment
manufacturer’s guideline and safety standards such as those
published by the National Fire Protection Association (NFPA),
and the American Society for Heating, Refrigeration, and
Air Conditioning Engineers (ASHRAE) and the local code
authorities.
L021 0910A
Page 2L021
E. When cutting or drilling into wall or ceiling, do not damage
electrical wiring and other hidden utilities.
F. Ducted fans must always be vented to the outdoors. Do not vent
exhaustairintospaceswithinwallsorceilings,crawlspaces,
attics, or garages.
WARNING - TO REDUCE THE RISK OF A RANGE
TOP GREASE FIRE:
A. Never leave surface units unattended at high settings. Boilovers
cause smoking and greasy spillovers that may ignite. Heat oils
slowly on low or medium settings.
B. Always turn hood ON when cooking at high heat or when
ambeingfood(i.e.CrepesSuzette,CherriesJubilee,Peppercorn
Beef Flambe).
C. Clean ventilating fans frequently. Grease should not be allowed
to accumulate on fan or in blower housing.
D. Useproperpansize.Alwaysusecookwareappropriateforthe
sizeofthesurfaceheatingelement.
WARNING - TO REDUCE THE RISK OF INJURY TO PERSONS,
IN THE EVENT OF A RANGE TOP GREASE FIRE, OBSERVE THE
FOLLOWING:
A. SMOTHER FLAMES with a close-tting lid, cookie sheet, or
metal tray, then turn off the burner. BE CAREFUL TO PREVENT
BURNS.Iftheamesdonotgooutimmediately,EVACUATE
AND CALL THE FIRE DEPARTMENT.
B. NEVERPICKUPAFLAMINGPAN-Youmaybeburned.
C. DONOTUSEWATER,includingwetdishclothsortowels-a
violentsteamexplosionwillresult.
D. UseanextinguisherONLYIF:
1) YouknowyouhaveaClassABCreextinguisherandyou
already know how to operate it.
2) Thereissmallandcontainedintheareawhereitstarted.
3) Theredepartmentisbeingcalled.
4) Youcanghttherewithyourbacktoanexit.
Safety (Continued)
Page 3 L021
Safety (Continued)
CAUTION
TO REDUCE THE RISK OF FIRE, AND TO PROPERLY EXHAUST
AIR, BE SURE TO DUCT EXHAUST AIR OUTSIDE. DO NOT VENT
EXHAUST AIR INTO SPACES WITHIN WALLS OR CEILINGS, OR
INTO ATTICS, CRAWL SPACES, OR GARAGES.
CAUTION
FOR GENERAL VENTILATION USE ONLY. DO NOT USE TO
EXHAUST HAZARDOUS OR EXPLOSIVE MATERIALS AND
VAPORS.
WARNING
TO REDUCE THE RISK OF FIRE, USE ONLY METAL DUCTWORK.
THIS MANUAL SHOULD REMAIN WITH THE HOOD
FOR FUTURE REFERENCE
Operating Instructions
Onexternalblowermodels,theusershouldgenerallystartonthe
lowest setting and then increase speed or turn on additional blower
motors as required.
The light switch operates halogen lights as low, off, or high, and
uorescentlightsasofforon.
Fluorescent Light Models
Blower Off/On Speed Control Light(s) Off/On
Halogen Light Models
Blower Off/On Speed Control Lights Low/Off/High
Note:Inordertoproperlycapturethemaximumamountofoil/grease
from cooking, the remote blower should be operated at the higher
setting-lowerspeedsmaylowerthenoiselevel,butmaynotcreate
sufcientairowandpressurethroughtheltertoliquifyoil/grease
properly.
Page 4L021
FILTER
FILTER
ISLAND SIDE VIEW
FILTER
WALL MOUNT SIDE VIEW
Wipedowntheinteriorandexteriorofthehoodasneededwithasoft
cloth and warm, soapy water (liquid dish setergent is acceptable).
Do not use acids, abrasives, strong detergents, solvents, or scouring
pads.
Stainless steel should be treated with a quality stainless steel cleaner
such as Stainless Steel Magic®(Vent-A-Hood®part number SS64).
Follow all label instructions. Do not polish across the grain or in
circles.
Realbrass,realcopper,andhammeredcopperhoodswilloxidize
and/ortarnishovertime.Useaqualitycopperorbrasscleanersuch
as Red Bear®CopperPolish(Vent-A-Hood®part number CP101).
Follow all label instructions. Do not use acids, abrasives, strong
detergents, degreasers, solvents, or scouring pads.
A. Hood Canopy
Hood Cleaning
WARNING: To reduce the risk of personal injury, be sure the
blower is turned off before removing lter(s).
Vent-A-Hood® range hoods that use external/remote blower units
haveastainlesssteelbafelter(s)locatedinsidethehood.The
lter(s)collectoil/greasefromcookingandneedtoberemovedand
cleanedonaregularbasis.Toremovethelter,graspthehandles,
liftupward,andpullthebottomoutward.Soakthelter(s)inwarm,
soapywaterorwashinadishwasher.Toreinstallthelter(s),follow
the above removel procedure in reverse.
Note: Filter elements cannot always collect 100% of the grease
fromcooking.Somegreasemaycollectbehindthelterorinthe
duct pipe.
B. Hood Filters
Page 5 L021
A. Light Bulb Replacement
WARNING: To reduce the risk of personal injury, turn off power
and allow lights to cool before proceeding.
Halogen Bulbs
Toremovethebulb,turnitcounterclockwise.Ifthelightisdifcultto
remove, it may be necessary to use the light bulb suction cup that
has been provided with this manual.
ReplacethebulbwithaPAR20120volt,50watthalogenbulb(Vent-
A-Hood®part number P1130).
Fluorescent Bulbs and Starter
Non-covered xtures-ToRemovethelamp,facingthehood,grasp
the bulb at each end and twist up and away. Take Care not to put
too much force on the glass as it may easily be broken.
Covered Fixtures-Toremovethelamp,facingthehood,remove
the plastic cover, grasp the bulb at each end and twist down and
away. Take care not to put too much force on the glass as it may
easily be broken.
Replacethebulbwithan18inch,15wattT8uorescentbulb(Vent-
A-Hood®part number P1120). Hold the new lamp at each end and
rotate it slowly into the sockets until it locks into position.
To remove the starter, turn the starter counterclockwise (when facing
thestarter).ReplacethestarterwithaFS-2 typestarter(Vent-A-
Hood®part number P1105).
Maintenance/Troubleshooting
Page 6L021
Maintenance/Troubleshooting (Continued)
B. What To Do If...
Smoke is in the kitchen. Check the following:
Is the hood sized appropriately for the type of cooking equipment
it is ventilating?
The purpose of a hood is to collect cooking contaminants and hold
themuntiltheblowerunitcanexhaustthemtotheoutside.Therefore,it
isnecessarytosizethehoodbasedonthetypeofcookingequipment
that is being used. Whenever possible, hoods should overlap the
cooking equipment by at least three inches on each side. For island
applications, this is mandatory. The hood should also project out to
the front edge of the front burners. Finally, the height of the hood can
affect its performance. Generally speaking, taller hoods are more
suitable for professional style ranges, whereas under cabinet hoods
are recommended for standard cooking equipment.
Does the blower capacity of the hood match the cooking
equipment it is over?
RM1000 Remote Blower - Under cabinet for standard cooking
equipment, gas or electric. Wall mount or island hoods for standard
cooking equipment, gas or electric, and professional style ranges.
RM1500 Remote Blower - Wall mount or island hoods for larger
professional style ranges.
Is the hood ducted properly?
Theductshouldbesmoothwalled.Corrugatedor“ex”typeduct
mustnotbeusedasitrestrictsairow.Theductworkshouldbethe
same square inch area (or larger) as the hood discharge for the
entire length of the duct run. Run the duct as short and straight as
possible. Enlarge the duct for longer duct runs. Maintain 4 to 5 foot
spacing between turns. Turns should be smooth and gradual, not
sharp and angled. Roof jack and wall louver openings must be free
ofobstacles,atleastaslargeastheductsize,andopenfreely.
Page 7 L021
Maintenance/Troubleshooting (Continued)
Is the hood mounted at the appropriate height off of the cooking
surface?
The height of the hood off the cooking surface is very important. The
higher the hood is mounted, the less effective it will be. Hoods only
collect cooking vapors; they will not pull cooking contaminants back
into the hood if they escape unto the kitchen. Generally speaking,
the deeper the hood, the higher the hood can hang and still be
effective.
UnderCabinet9”tall 24-27”
WallMount 30”
Island 30”
LinerInserts *24-30”
*Note:therecommendedheightoffthecookingsurfaceisdependent
on the depth of the liner. In general, the deeper the liner, the higher
offthecookingsurfaceitcanbe,uptoamaximumrecommended
heightof30”.
Do the dampers open and close freely?
Withthelter(s)removed(seeHoodCleaningSection),locatethe
dampers(aps)andensurethattheyopenandclosefreely.Ifnot,
identify and remove any obstructions that are preventing the dampers
from opening. Screws protruding through the duct work are the most
common obstruction.
During installation, only duct tape should be used to connect duct
work to the top of the hood. Screws that are used to connect duct
workandtransitionsextendinsidetheductworkandmayobstruct
the dampers from opening.
Page 8L021
Vent-A-Hood® warrants to the original consumer-purchaser its
products to be free of defects in material and workmanship for a
period of one year from the date of purchase (internal motors for a
periodofveyears)withthefollowinglimitations:
A. Light bulbs
B. Freight damage
C. Damage caused by faulty installation
D. Incidental or consequential damage
E. Commercial application
F. Misapplication or modication of or to any part of the
Vent-A-Hood®product
Warranty
To make a warranty claim, contact the dealer where the hood was
purchased. They will contact the appropriate service agents. It is not
necessarytoregistertheproductdirectlywithVent-A-Hood®.
Service
Vent-A-HoodLtd.
P.O.Box830426
Richardson,TX75083-0426
(800)331-2492
(972)235-5201
www.VentAHood.com
Customer_Service@VentAHood.com
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Campana de ventilación de VentAHood
VentAHood
VentAHood VP526 Manual de usuario
VentAHood
VentAHood CWLH9 Manual de usuario
VentAHood
VentAHood EUROLINE Manual de usuario
VentAHood
VentAHood K Series Manual de usuario
VentAHood
VentAHood JCH/B1 Series Manual de usuario
VentAHood
VentAHood CWSH3 Manual de usuario
VentAHood
VentAHood AH12 Manual de usuario
VentAHood
VentAHood Equipped with Magic Lung Blower Manual de funcionamiento
VentAHood
VentAHood ISLAND RANGE HOOD Manual de usuario
VentAHood
VentAHood EUROLINE Manual de usuario
VentAHood
VentAHood Ventilation Hood Models Equipped with K250... Manual de usuario
VentAHood
VentAHood Ventilation Hood Models Equipped with K250... Manual de funcionamiento
VentAHood
VentAHood XLH12 Manual de usuario
VentAHood
VentAHood SLH6-K Manual de usuario
VentAHood
VentAHood B100 Manual de usuario
VentAHood
VentAHood Magic Lung Blower Manual de funcionamiento
VentAHood
VentAHood B100 Single Manual de usuario
VentAHood
VentAHood Ventilation Hood Models Equipped with K250... Manual de usuario
VentAHood
VentAHood ZTH Manual de usuario
VentAHood
VentAHood Ventilation Hood Models Equipped with K250... Manual de usuario
