VEC-121K Owner's Manual Crystal Radio Set Kit
1
INTRODUCTION
Relive those bygone days of radio--a time almost 90 years ago, when early radio
pioneers experimented with crystal radio receivers! Wind your own “inductor”
coil, wire up the earliest radio circuit; and, there’s no soldering needed!
Everything is assembled on a pine “breadboard”, just like great, great granddad
did when he was a youngster. Learn about basic radio theory. Put up an antenna
(wire included), connect a ground, and experience the magic of a radio that
needs no power. A special high-sensitivity earphone allows you to hear AM
Broadcast signals from many miles away; this little baby really performs. The
VEC-121K is a fascinating project for youngsters of all ages!
The VEC-121K features a modern “fixed detector”, eliminating the need for
frequent and frustrating catwhisker adjustments. A large, Hi-Q antenna coil, and
a modern miniature Hi-Q tuning capacitor, are used for best sensitivity and
selectivity. The high-impedance parallel-resonant tuning circuit allows a short
receiving antenna to deliver maximum signal to the set.
TOOLS AND SUPPLIES
Having the right tool to do a job always makes things go better. There is no
soldering required, and only a few basic hand tools are needed to assemble your
VEC-121K crystal radio set.
This is a list of the tools you will need:
SAFETY EYEGLASSES or GOGGLES! Working with wires, tools and radio
parts is a lot of fun, but please, safety first! Your local hardware store carries
inexpensive safety goggles. Before you are going to be cutting or working with
wires, hammering, handling any chemicals, or using any tools, put on your
safety eye wear first!
1. Phillips screwdriver. There are eight Phillips head screws included in the
kit, and we will use this tool when it is time to mount parts on the wood
board. Try to find a screwdriver with a shaft (the distance between the tip
and start of the handle) that is at least 3” long.
2. Long-nose pliers. These pliers have a long and tapered nose and are used
by electricians. The long slender nose makes it easy to hold or bend a wire
that is being worked on.
3. Wire cutters. These special pliers have sharp cutters to cut wires. Some
long-nose pliers styles feature built-in wire cutters. Wire cutters are
sometimes called “nippy cutters” or “diagonal wire cutters”—depending on
how they’re made.
VEC-121K Owner's Manual Crystal Radio Set Kit
2
4. Ruler or tape measure. A small 12” ruler or flexible tape measure will do.
5. Small penknife. A penknife, or small ExactoTM knife, is needed to scrape
off wire insulation. If you aren’t old enough to use a knife, a small section of
sandpaper will do.
6. Small Hammer. It will be used with a finishing nail to mark where the
screw holes are placed on the pine board.
7. Small-Screwdriver or Hex-Tool. Size to fit the set screw in the tuning
knob--depending on which type of knob is supplied with your kit.
Radio Shack carries many inexpensive small hand tools for electronics work.
Here are some items that will come handy:
1. Masking tape.
2. Cyanoacrylate adhesive. This is the fancy name for contact cement, which
is sold as “Super GlueTM ” or “Crazy GlueTM ”. You’ll use the contact cement
to hold the coil windings in place. These adhesives are very strong, and can
instantly glue your fingers together if you are not careful! If you are not old
enough to work with contact cements, have someone who is older help you
when gluing is directed in the instructions. The glues used to assemble
plastic model airplanes are safer to work with and may also be used instead
of super glue. However, they will require a longer time to dry. Always have
an adult advise and supervise your use of any chemicals!
WOODWORKING AND FINISHING (OPTIONAL)
Perhaps this is your first kit building experience, or your first homemade
receiver project. If so, your VEC-121K crystal receiver will be a source of pride
for many years to come. Before assembling this kit, you might wish to consider
sanding and staining the pine board—this will bring out the beauty of the wood,
and make your project look as if it was done by an “old pro”. Many early radios
were built in what was called “breadboard” fashion. The radio parts were laid
out on a small section of wood board.
Early radio parts were very expensive, even a simple crystal radio set could cost
a week’s pay! Most experimenters had to improvise. Often an old breadboard
(used to roll out bread dough) was used as a base to mount radio parts. If you
were well-to-do, your “breadboard” was probably a fine piece of mahogany or
walnut board!
Sanding: Before applying a stain finish, carefully sand the pine board using 200
grit sandpaper. When sanding the surfaces, always sand in the direction of the
grain to avoid scratching the wood. The two board edges that expose the end
VEC-121K Owner's Manual Crystal Radio Set Kit
3
grains of the wood will be rather rough to the touch, and will require some extra
sanding to produce a smooth even surface. You may have to use a 150 grit in
the beginning on the end grains. Sanding is best done outdoors. Wear a
disposable paper dust mask while sanding.
Finishing: Your local hardware store stocks small cans of woodworker stains.
Either a walnut or mahogany wood stain finish is a good choice. Both oil-based
and water-based stains are available. We suggest using a water-based stain for
this project—it is easier to work with and easier to clean up afterwards. You
will need a clean cloth, or staining cloth, to apply the stain. Follow the
manufacturer’s directions very carefully, and read the safety information on the
label. Use disposable latex gloves when handling stain. If you’re too young to
safely work with wood stains, ask an adult for assistance with this portion of the
project. Always handle any chemicals with great care!
Important Note:Once the stain is dry to the touch, the assembly work may
begin. Before attaching the tuning capacitor with the double-sided adhesive
tape, the board should be allowed to dry for a few days. This will allow the stain
to fully cure, or dry, so it does not interfere with the tape adhesive.
BEFORE YOU START BUILDING
Your work area: Use a good workbench with good lighting so you can see
what you are doing. At times we will need to set items aside to allow glue to
dry; or you will need to stop working on your project for other activities. Your
work area should be in a place where your project does not interfere with others.
Keep your work area clean and free of clutter. Kit parts should be kept in the
box until you need to use them. When you are finished for the day, return the
tools to their proper place. Put unused kit parts back in the box so you will not
lose them. If you are old enough to use glues and wood stains, you may have
younger brothers and sisters who aren’t! Keep chemicals out of the reach of
younger children.
Following directions: Kits are built in “steps”. These steps follow a logical
order, that means following the instructions will make your kit building
experience easier and ensures that your project will work first time when
finished.
You will notice a check box !as each instruction gives you a simple task, or
direction, to follow. When the task is finished, make a small check mark in the
box to show that part has been completed. This will allow you to keep track of
where you left off when returning from a break.
For example, a direction may read:
VEC-121K Owner's Manual Crystal Radio Set Kit
4
!Tighten the screw until snug, this will make a good electrical connection
between the Fahnstock clip and wire.
When finished following the directions, “check off” that the step has been done.
"Tighten the screw until snug, this will make a good electrical connection
between the Fahnstock clip and wire.
Don’t rush!
Have you ever noticed that when you try to rush doing something, it never turns
out right? Don’t try to build the crystal set receiver in one day! The time spent
building a kit is most of the fun. We will be “breaking down” the kit assembly
into several phases. For example, the first phase is preparing the “breadboard”.
The next kit phase involves winding the coil.
Working with wire:
Unspooling: Your kit includes a 100-foot roll of 18 AWG enamel-coated wire.
This wire is used to wind the tuning coil, for your receiver’s antenna, and is also
to be used for making connections between the radio components. Do not
remove the wire tie from the roll of wire until you are ready to use it. There is a
right and wrong way to remove wire from the spool! Never allow the wire to
uncoil, like a SlinkyTM toy! Doing so will cause the wire to twist and make kinks
when you try to use it. Instead, hold the spool of wire in both hands, and
carefully unroll the wire from the spool. Re-tape the unused portion when
finished.
Removing insulation: Electrical connections are made by removing the
insulation from the enamel wire. When you need to make an electrical
connection, you will be instructed to remove the wire insulation. We will tell
you where the insulation should be removed, and how much to remove. This can
be done by using a small piece of 150 grit sandpaper. Fold the sandpaper in half
so the “sandy” sides face together. Place the wire into the sandpaper fold, and
slide the sandpaper back-and-forth over the wire while applying a gentle
pressure. Turn the sandpaper every so often to fully remove all of the insulation.
Gently scraping the insulation with a small penknife will also work. Lay the wire
on a piece of scrap board, and draw the knife blade over the insulation to scrape
it away. Always scrape in a direction away from your body!
All of the insulation must be removed to make a good electrical connection. The
bare area of the copper wire should be bright and shiny when you are finished.
Making connections:
The directions will tell you to make one of two types of connections: “End”
connections or “through” connections.
VEC-121K Owner's Manual Crystal Radio Set Kit
5
End Connections: End connections are made when the end of a wire is
connected. To make an end connection, you will have to remove about 1” of
insulation from the wire and form the end into a “fishhook” shape, as shown
below.
In the following drawing, a wire end connection is used to make an electrical
connection to one of the Fahnstock clips mounted on the pine board. Note we
show the wire as a “dotted line” where it passes under the Fahnstock clip. When
the Phillips screw is tightened, a good electrical connection is made. The
drawing shows how the wire hook is placed between the Fahnstock clip and
board.
Through connections are used when the wire goes to a electrical connection at a
Fahnstock clip, and then continues on to make one or more connections to other
points. The directions will tell where to make a through connection on a wire,
and how much insulation needs to be removed.
VEC-121K Owner's Manual Crystal Radio Set Kit
6
The wire insulation is removed where shown in the directions, and made into a
half loop as shown above.
The above drawing shows a through connection being made to a Fahnstock clip.
The dotted line shows where the wire runs under the clip body.
VEC-121K Owner's Manual Crystal Radio Set Kit
7
PARTS LIST
You are just about ready to begin your kit building adventure! But first, let’s
take a few minutes to make sure everything needed is present and accounted for.
If any parts are missing or damaged, you’ll need to refer to the directions given
in the Vectronics kit warranty section of the manual.
"Qty Part Description
!8 Phillips head screws
!1 5 inch length of white 2-1/2” diameter PVC plastic pipe
!1 100 foot spool of 18 AWG enamel coated wire.
!6 Fahnstock clips.
!1 Tuning capacitor shaft extension
!1 Tuning capacitor
!1 Tuning knob
!1 Double-sided foam tape
!1 Earphone
!1 Pine board , 3/4” high by 5-1/4” deep by 6” wide
!1 Insulated stranded wire, 7 feet long
!1 27K resistor (red-violet-orange-gold)
!1 1N34A germanium diode
Fahnstock clips
Tuning capacitor.
VEC-121K Owner's Manual Crystal Radio Set Kit
8
Resistor:
Germanium diode:
1N34A
STEP-BY-STEP CONSTRUCTION
Tabla de contenidos
