KEY INFORMATION YOU

SHOULD KNOW:

VEC120FS

3,000,000 POWER SERIES™ SPOTLIGHT

RECHARGEABLE WITH BUILT-IN AREA LIGHT

IF YOU SHOULD EXPERIENCE A PROBLEM WITH YOUR

VECTOR PURCHASE CALL TOLL FREE (866) 584-5504.

IN MOST CASES A VECTOR SERVICE REPRESENTATIVE

CAN RESOLVE YOUR PROBLEM OVER THE PHONE.

BEFORE RETURNING THIS PRODUCT FOR ANY REASON,

PLEASE CALL TOLL FREE (866) 584-5504

• Charge 10 hours before first use.

• Simple two-position lock trigger.

• AC/DC Recharge Adapter

• DC Fused Recharge/Power Adapter

OWNER’S MANUAL AND WARRANTY

INFORMATION

THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY,

OPERATION, MAINTENANCE AND STORAGE OF THIS PRODUCT. READ

CAREFULLY BEFORE USE, AND RETAIN FOR FUTURE REFERENCE.

4140 S.W. 28th Way, Ft. Lauderdale, FL 33312

Tel: (954) 584-4446 Fax: (954) 584-5556 Toll Free: (866) 584-5504

www.vectormfg.com

IMPORTANT SAFETY INSTRUCTIONS

WARNINGS: Contains non-spillable sealed lead acid batteries. They must be recy-

cled or disposed of properly.

DO NOT dispose of batteries in fire, as this may result in an explosion. DO NOT open

battery or short circuit, as this may cause the battery to leak or get hot causing per-

sonal injury. Any disposal questions call toll-free (877) 288-7722.

Please read Instruction Manual completely for all safety and warning instructions.

CAUTIONS: USE ONLY WITH AC AND DC CHARGING ADAPTERS THAT ARE

PROVIDED WITH UNIT. PLUG IN THE CHARGING ADAPTER AT THE

SPOTLIGHT FIRST, THEN PLUG INTO THE CHARGING SOURCE

DO NOT OVERCHARGE: CHARGE UNTIL GREEN BATTERY STATUS LED LIGHTS OR FLASHES

DO NOT CHARGE FOR MORE THAN 24 HOURS USING AC CHARGING ADAPTER

a) First use - typical charge time is 8-10 hours.

b) Charge after first use - typical charge time is 10-12 hours.

c) If unit is not used for two months, typical charge time is 4 hours.

After recharge, disconnect charging adapter and wait 5 minutes before use.

1. Do not substitute power cords or charging adapters. Only charge with supplied

AC and DC charging adapters. Charging adapters for this unit supply 12 volts

DC.

2. Do not submerge in water. This unit is not waterproof - it is water resistant.

3. Keep children away from spotlight. This is not a toy!

4. Lens gets very hot when spotlight is operating. Do not touch lens while operating.

5. Keep combustibles away from spotlight lens - extreme heat can cause fires.

6. Keep sharp objects away from lens - it is glass and it can break.

7. Do not drop or throw spotlight, it contains glass and a sealed lead acid battery.

8. Dispose of unusable batteries in a responsible manner. See battery disposal

section.

9. Do not crush, cut, pull or expose charging adapter cords to extreme heat.

10. Keep charging adapter cords away from sharp edges.

11. Position charging adapter cords so that they do not become entangled or become

a safety hazard.

12. Do not shine spotlight in eyes.

1. INTRODUCTION

Congratulations on purchasing VectorLiteTM Model VEC120, an advanced design

dual-bulb 3,000,000 candlepower spotlight and long lasting, area work light. It uses

two powerful, proven-technology, rechargeable, non-spillable, sealed, lead acid bat-

teries that allow for years of dependable use, recharge after recharge. It was designed

from the ground up to be the most versatile and practical light for travel, camping,

picnicking, tailgate parties and boating. The spotlight gives you the kind of light you

need, when and where you need it.

Extremely rugged construction protects the unit from damage from most vibration and

shock. It is water and dust resistant. (See Figure 1)

The area worklight assembly flips up to provide a ultra bright area light. A 12 volt

accessory socket allows powering any DC appliance that does not exceed 10 amps.

To power an appliance, flip up the accessory outlet cover and insert the DC plug. After

use, close the cover.

Two recharge adapters are supplied with the spotlight. It can be recharged from any

110/120 volt 60 Hz AC receptacle. It can also be recharged and powered from a 12

volt DC accessory socket. This permits recharge flexibility for use around home, busi-

ness or in the field. 12 volt DC power is available from most vehicles, boats, jump

starters and portable battery packs. Vector has a variety of portable power products

that would make ideal companions.

Spotlight

Trigger Switch

Rubber Bezel

12 Volt DC

Accessory Outlet

Flip-up

Area Worklight

Figure 1

Dual Halogen Bulbs

Battery

Compartment

Battery

2. ADDITIONAL FEATURES

• Two powerful, prefocused, replaceable quartz halogen bulbs in spotlight.

• Area light provides up to 24 hours of continuous operation.

• Area light flips up for good light distribution.

• Three-position slide switch selects single or dual spotlight.

• Trigger switch operates spotlight.

• Rubber safety guard (bezel) around lens protects spotlight.

• Safety end caps protect upper and lower battery compartments.

• Comfortable pistol grip.

• LED lights while battery is charging.

• UL approved AC/DC recharge adapter.

• Fused DC recharge/power cord.

3. OPERATION

The Trigger switch is squeezed to turn the spotlight on. Release the trigger switch to

turn off the spotlight. Selection of single bulb or dual bulb spotlight, or area light, is

controlled by a three-position slide switch on the rear of the unit. (see Figure 2)

Left Position: Selects area light

Center Position: Selects single spotlight

Right Position: Selects both spotlights

Note:The area light can operate continuously for up to 24 hours on a full battery charge.

Screw (6) Area Work Light

DC Recharge Port

Battery Status Display

Screw (2)

Lower Battery

Compartment

AC Recharge Port

Battery Status Pushbutton

Upper Battery

Compartment

Figure 2

AC/DC Recharge Adapter DC/DC Recharge Adapter

4. CHARGING THE VECTORLITE USING THE AC

RECHARGE ADAPTER

NOTE: This unit is shipped in a partially charged state. Initially charge unit using the

AC charger. To check the battery level, press the battery status pushbutton

(Figure 2). Charge until battery status displays green LED lights when the

battery status display pushbutton is pressed. Charge after each use. (See

Figure 3A)

IMPORTANT: DO NOT TURN ON ANY LAMPS OR OPERATE ANY DC APPLI-

ANCES THROUGH THE SPOTLIGHTS ACCESSORY OUTLET WHEN

THE AC/DC RECHARGE ADAPTER IS CHARGING THE UNIT.

1. Make sure all lamps and connected appliances are turned OFF.

2. Locate the recharge port on the rear of the spotlight (see Figure 2).

3. Connect the AC charger to a 110 VAC, 60 Hz power source.

4. Plug the AC charger’s barrel connecter into the AC recharge port.

5. Recharge for 10 hours maximum or until the green LED lights when the battery

status display pushbutton is pressed.

6. After recharge, disconnect the adapter from the external charging source then dis-

connect barrel connector from the recharge port.

7. After AC recharge, wait 5 minutes before using spotlight.

5. CHARGING AND POWERING THE VECTORLITE

USING THE DC RECHARGE ADAPTER

The VEC120 can be simultaneously charged and operated from a12 volt DC source.

Make sure the 12 volt source can supply at least 15 amperes of current if the spot-

light is to be operated while the batteries are being charged.

To check the battery level, press the battery status pushbutton (Figure 2). Charge until

battery status display’s green LED lights when the battery status display pushbutton is

pressed. Charge after each use. (See Figure 3B).

1. Locate the DC recharge port on the rear of the spotlight (see Figure 2).

Figure 3A Figure 3B

17. Secure retainer with two Phillips screws.

18. Replace rubber bezel by sliding to the rear of the spotlight.

19. Operate switches to ensure proper operation of spotlight.

REPLACING THE BATTERIES

The rechargeable, sealed, lead acid batteries have a life of several years, if

recharged promptly after each use. When the fully charged batteries only provide

about 10 minutes or less of spotlight operation, they should be replaced with new

batteries. To replace the batteries, you will need a Phillips type screwdriver and

replacement batteries Vector Part VEC191. The batteries are in compartments

referred to as upper and lower. Because of spotlight construction, there are two pro-

cedures: upper battery replacement, and lower battery replacement. Both batteries

are wired in series so they should be replaced at the same time. DO NOT MIX BAT-

TERY TYPES, OR NEW AND OLD BATTERIES.

The upper battery is replaced as follows:

1. Remove the six Phillips screws (clockwise) that fasten the plastic end cap. See

Figure 2 for locations.

3. Remove the upper end cap from the body.

4. Note, the battery can slide out of the body, so keep the body level.

5. The battery terminals are attached to two wires. These wires must be disconnected

from the terminals of the battery.

WARNINGS: DO NOT ALLOW BARE WIRES OR CONNECTORS TO CONTACT EACH

OTHER. DANGEROUS SPARKING CAN OCCUR - NOTE WHICH WIRES

ARE ON THE BATTERY TERMINALS

6. Note polarity of battery. Note which wire is on which terminal.

7. Disconnect the wires from the battery, and set the battery aside.

8. Connect the replacement battery, making sure the correct wires are on the new

battery terminals. Make sure POS (+) is red and NEG (-) is black.

CAUTION: Incorrectly connected wires will not allow the spotlight to operate or

recharge. Incorrect battery polarity will damage the circuits inside the

spotlight. Double check battery polarity before reassembly!

9. Replace battery compartment end cap. Make sure wires are not crushed.

10. Replace four Phillips screws in battery compartment cover. Do not over-tighten.

The lower battery pack can be replaced by following the upper battery replacement

procedure except there are only two Phillips screws to be removed.

After the lower battery is replaced and the lower end cap secured, recharge for 10-

12 hours using the AC recharge adapter before using the spotlight.

2. Connect the DC charger to a 12 volt DC source that can supply at least 15 amps

of current.

3. Plug the DC charger’s polarized connecter into the DC recharge port.

4. Recharge for 10-12 hours maximum or until the green LED lights when the battery

status display pushbutton is pressed.

5. After recharge, disconnect the adapter from the external charging/power source,

then disconnect the connector from the DC recharge port.

Note: Some vehicles must have the ignition switch on to power the vehicle

accessory outlet.

WARNING: NEVER SIMULTANEOUSLY CONNECT AC/DC AND DC/DC CHARGERS TO

SPOTLIGHT.

6. PERIODIC MAINTENANCE

All batteries lose charge over time, especially when they are warm. AC recharge is

recommended every two months, when not in frequent use. Use the AC/DC recharge

adapter and charge for the recommended time. If the unit has dirt on it, gently clean

the outer surfaces of the spotlight unit with a soft cloth moistened with a mild solution

of water and detergent. Periodically inspect the condition of recharge adapters, con-

nectors, and wires. Replace any components that may have become worn or broken.

7. PARTS REPLACEMENT

Several parts are replaceable by users. The quartz halogen bulbs and two sealed lead

acid batteries are available through Vector Manufacturing. A substitute 12 volt, H3,

55 watt bulb may be used instead of a Vector bulb. These can also be purchased from

popular automotive parts suppliers nationwide. Vector Manufacturing’s technical

support department for replacement parts and any additional information that you

may need. They may be reached at (954) 584-4446 or toll free (866) 584-5504.

To replace either or both H3 type 12 volt bulbs, you will need a small Phillips type

screwdriver and a replacement bulb (or bulbs), Vector part VEC190. Bulb life can be

shortened by installing a bulb with dirt or fingerprints on it. The bulb can be wiped

clean with a cloth moistened with alcohol. During bulb installation, avoid touching the

glass part of the bulb. See Figures 4, and details 4A and 4B. Note which bulb is

burned out.

1. Disconnect the unit from any charging adapters

2. Pull the rubber bezel towards the front of the spotlight to reveal two small Phillips

screws in the wide reflector assembly retainer. The screws are on opposite sides of

the retainer.

3. Using the screwdriver, remove (counterclockwise) the two screws. Set them aside.

4. Lift off the retainer, glass lens, and rubber ring and set them aside.

5. Carefully remove the dual reflector and bulb assembly.

6. Disconnect the bulb wire from the red power wire and set the burned out bulb

aside.

7. Unsnap the hairpin retaining wires from the reflector’s flange (see details 4A and

4B)

8. Using the screwdriver, loosen the retaining screw to remove the bulb from the

reflector (no need to completely remove this screw).

9. Lift out the bulb and the attached wire.

10. Insert the replacement bulb into the reflector’s flange.

11. Put back and secure the hairpin retaining wires.

12. Connect the white bulb power wire to the red power wire.

13. Tighten the retaining screw on the flange.

14. Place the reflector in position in the body of the spotlight.

15. Replace the rubber ring in the groove around the perimeter of the reflector.

16. Replace glass and retainer so that the screw holes are aligned.

Rubber

Bezel

Reflector

Assembly

Retainer

Reflector

Rubber Ring

Glass Lens

Figure 4

Hairpin

Retainer Wires

Figure 4BFigure 4A

SAFE BATTERY DISPOSAL

Contains maintenance-free, sealed, non-spillable, lead acid

batteries, which must be disposed of properly. Recycling is

required, contact your local authority for information. Failure to

comply with local, state and federal regulations can result in

fines, or imprisonment.

Battery Disposal Warnings:

• Do not dispose of a battery in fire as this may result in an explosion.

• Before disposing of the battery, protect exposed terminals with heavy-duty electrical

tape to prevent shorting (shorting can result in injury or fire).

• Do not expose batteries to fire or intense heat as they may explode.

• For more information on recycling these batteries, call toll-free 877-288-7722.

7. SPECIFICATIONS

Spotlight Bulb . . . . . . . . . . . . . . . .12 volt, H3 series Vector Part No. VEC190

Flip Up Area Light . . . . . . . . . . . .Long-life fused (no replacement needed)

Battery . . . . . . . . . . . . . . . . . . . . .Two maintenance free, sealed, lead acid, 6 volt,

6.0 Amp hour Vector Part No. VEC191

Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7.75 lbs. (3.52 Kg)

Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9.0 in (22.86 cm)

Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7.38 in (18.75 cm)

Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12.0 in (30.48 cm)

Otros manuales para 3

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Destacar de Vector

Vector

Vector VEC184POB Manual de instrucciones

Vector

Vector VEC280 Manual de instrucciones

Vector

Vector VEC156 Suplemento

Vector

Vector 000 Power Series Manual de usuario

Vector

Vector SL3AKV Manual de usuario

Vector

Vector VECTORLITE VEC117FS Suplemento

Vector

Vector VEC157 Suplemento

Vector

Vector VEC271MG Manual de instrucciones

Vector

Vector VEC157CFL Manual de usuario

Vector

Vector 000 Power Series Manual de instrucciones

Vector

Vector 90519434 Manual de instrucciones

Vector

Vector VEC37R Suplemento

Vector

Vector SPORTSPOT VEC189 Manual de usuario

Vector

Vector SPORT SPOT VEC124B Manual de usuario

Vector

Vector Ultra SPORT SPOT Manual de usuario

Vector

Vector SPORTSPOT CSL105V Manual de usuario

Vector

Vector Power VEC141 Manual de usuario

Vector

Vector VECTORLITE VEC118S Manual de usuario

Vector

Vector SL3WAKV Manual de usuario

Vector

Vector SPORT SPOT VEC190POB Manual de usuario

Vector

Vector VectorLite VEC117 Suplemento

Vector

Vector SPORT SPOT VEC138Y Manual de instrucciones

Vector

Vector 90510392 Guía

Vector

Vector 3 Manual de instrucciones

Manuales populares de Destacar de otras marcas

Guangzhou Yinhe Lighting&Sound Equipment Factory

Guangzhou Yinhe Lighting&Sound Equipment Factory NE-204 Manual de usuario

LIVARNO home

LIVARNO home 375304 2101 Instrucciones originales

Cameo

Cameo CLQS40WW Manual de usuario

Leviton

Leviton Ellipsoid 5/50 Manual de usuario

Monacor

Monacor img Stage Line PARL-56PDX/CR Manual de usuario

Quantum

Quantum Q262 Manual operacional

Philips

Philips Vari-lite VL3015LT Manual de usuario

EUROSPOT

EUROSPOT C51 Manual de usuario

DTS

DTS MINI BRICK ARC Manual de usuario

Federal Signal Corporation

Federal Signal Corporation VISIBEAM II Manual

ACME

ACME LED-MS350B Manual de usuario

EuroLite

EuroLite Akku flat light 1 Manual de usuario

Commercial Electric

Commercial Electric SPTM-1401 Manual de usuario

Vision & Control

Vision & Control SLB-500-W5K7-P-SL Manual de usuario

Teknik

Teknik FLEXI Manual de usuario

Craftsman

Craftsman CMXLSB10 Manual de usuario

EuroLite

EuroLite LED SLS-144 UV Floor Spot Manual de usuario

Ignition

Ignition WAL-L412 BP Manual de usuario
