VTX
Assembly and Operating Instructions
Electrical Drawing #: Rev:______
D-100 and D-1000 Series Dryer
Doc. # 01-23-001K
Year of Manufacture: 20____
Contents Page#
Safety Information 2
General Information 3
Package Contents 4-5
Component Identification 6
Assembly 7-14
Belt Tracking 15
Electrical Requirements/Controls 16
Operation 17
Chain Drive Adjustment 18
Warranty 19
Watch Assembly Video Here!
Introduction
Congratulations, you have chosen a VASTEX conveyor curing system. VASTEX has been designing and build-
ing dryers since 1960 and has the knowledge and expertise to supply a quality dryer and help you keep it running for
years to come. VASTEX has innovated many of the features found in conveyor ovens today from control methods,
modular features, air movements and belt tracking.
Vastex Infrared Dryer have been Factory tested and burned in for a period of 2-8 hours. All components are
tested to be sure they work correctly when the Dryer leaves our factory.
The Instruction Manual and Safety Instructions must be read and understood by anyone operating
the Vastex Conveyor Drying System.
The operator should read and understand the instruction manual before operating this equipment. Store instruc-
tion manual and safety instructions near equipment for easy access to operators.
VASTEX Conveyor Drying System is intended for the curing of non-flammable inks on screen printed materials.
Do not use for any other purpose unless authorized by Vastex International, Inc. Use of this equipment for any
other purpose can be dangerous and may cause damage to this equipment, voiding the warranty.
It is recommended that the area around this equipment be designated as a work area and only authorized em-
ployees be allowed in the area.
Children and pets must be kept clear of the work area.
Do not place any objects on top of the drying chamber. Surfaces are hot!
Never leave equipment unattended.
Do not operate conveyor or dryer with any cover or guard removed.
Operator must be familiar with controls of the dryer and conveyor.
Never put excessive load on the conveyor belt.
Before starting production, the operator must check that all covers and guards are in place, no material has been
left on the conveyor, and the work area is clear of obstructions.
Switch on and verify conveyor belt is moving before turning on the heat.
Allow dryer to cool to 300°F (149°C) or turn off heat for 10 to 15 minutes before switching off conveyor.
Always turn off power at the main disconnect at the end of production.
In case an abnormal symptom occurs, for example excessive vibration, noise, and strong smell or smoke devel-
opment, turn off the VASTEX Conveyor Curing System and contact a qualified technician.
Immediately turn off the VASTEX Conveyor Curing System if products become jammed in the drying chamber or
conveyor belt.
Do not remove any cover or guard until power at the main disconnect is switched off and locked out. No unau-
thorized persons are to be allowed inside the control boxes.
Turn off and lock out power at the main disconnect before any cleaning or maintenance.
Only qualified technicians should be allowed to make repairs on the VASTEX Conveyor Drying System.
Safety
Inspect all packages and notify the shipping company
if any damages are detected.
Vastex International Inc. | www.vastex.com | techsupport@vastex.com | [email protected] | 610-625-2702
Pg. 2
Stability during use, transportation, assembly, testing, and foreseeable break-
The D-100 and D-1000 dryers are designed and expected to be inherently stable under all
foreseeable conditions of use, assembly, testing, etc., so long as the procedures listed in
this manual are followed. Be certain that your workbench, table, or stand can safely sup-
port the weight of your machine (see below).
Safe handling, transport, and storage:
Unplug your dryer and allow it to cool before storing. When handling or transporting your
machinery, be aware of the following weights and dimensions:
D-100: Assembled — 89 lbs (40.4 kg); 46” x 24” x 24” (119 x 61 x 61 cm)
Boxes: #1 – 57 lbs (25.9 kg); #2 – 14 lbs (6.4 kg); #3 – 18 lbs (8.2 kg); Boxes on skid: 115
lbs (52.2 kg)
D-1000: Assembled — 116 lbs (52.6 kg), 46” x 32” x 24” (119 x 81 x 61 cm)
Boxes: #1 – 38 lbs (17.2 kg); #2 – 43 lbs (19.5 kg); #3 – 35 lbs (15.9 kg); Boxes on skid:
137 lbs (62.1 kg)
Adjustment and Maintenance:
In the event of a malfunction or breakdown:
Safety during adjustment and maintenance
Before beginning any maintenance or adjustment procedures on your dryer:
If the machine’s heater has been ON, shut the heat control OFF, but allow the belt to
continue running for 10 -15 minutes, or until the heater has cooled to 300°F (149°C) or
lower . If the belt is stopped while the heater is hot, belt damage will occur.
Switch machine OFF and disconnect from power before beginning any adjustment or
maintenance.
Do not attempt any maintenance while machine is powered.
Do not run machine with panels or guards removed.
Periodically check ink temperature on garments exiting machine. See page 11,
“Operation Tips.” Readjust temperature control as necessary to maintain correct tem-
perature for your application.
Occasionally, check belt tracking and adjust if necessary. See page 9, step 12.
Chains in chain drives can loosen over time; occasionally check the tension on the
chain in your machine.
Allow heater to cool, then shut off machine and disconnect from power as described above
in “Safety during adjustment and maintenance.”
Follow the troubleshooting chart below
If the chart does not resolve the trouble, contact Vastex for additional assistance.
Symptom Possible Cause Solution
No functions operate Machine unplugged
Building wiring fault
Make sure machine is plugged
in.
Have wiring checked.
Belt does not move Belt circuit fuse(s) blown
Speed control faulty
Belt motor faulty
Check or replace fuse(s).
Replace. Contact Vastex.
Replace. Contact Vastex.
No heat Faulty heater control
Faulty heater assembly
Replace. Contact Vastex.
Replace. Contact Vastex.
Vastex International Inc. | www.vastex.com | techsupport@vastex.com | [email protected] | 610-625-2702
Pg. 3
Package Contents D-100 only
3 Separate Cartons
Carton #1 Conveyor Components
Side
Top Cov-
Side Pan-
Back Pan-
Front Pan-
Wire Cov-
Knobs
Carton #3 Chamber Components Carton #2
16 x 16 Infrared Heater
Hardware Package Contains
(1) Wire Cover
(2) Knobs
(2) Heater Hold Down Tab
(2) Heater Hanger Bracket
(40) Black #8 Sheet Mtl Screws
(1) 1/4” & 7/16” Hex Wrench
Conveyor Assembly
1) Chain Guard
1) Hardware package with:
6 screws and 2 belt guards.
Conveyor Belt
Heater Hold
Down Tabs
Vastex International Inc. | www.vastex.com | techsupport@vastex.com | [email protected] | 610-625-2702
Pg. 4
Package Contents D-1000 only
Carton #1 Front Conveyor Components
Carton #2 Rear Conveyor Components
Carton #3 10” Conveyor Extension Components
Side
Top Cov-
Side Pan-
Back Pan-
Front Pan-
Wire Cov-Knobs
Carton #5 Chamber Components
Rear conveyor with Drive
motor, controls and rear
pulley
Additional items above:
1) Belt, 1) Chain guard, and 1) Hardware
package with: 6 screws and 2 belt guards.
Front conveyor with belt
aligner and front pulley.
5 Separate Cartons
Heater Hold
Down Tabs
Carton #4
16 x 20 Infrared Heater
Hardware Package Contains
(1) Wire Cover
(2) Knobs
(2) Heater Hold Down Tab
(2) Heater Hanger Bracket
(40) Black #8 Sheet Mtl Screws
(1) 1/4” & 7/16” Hex Wrench
10” conveyor
extension
Vastex International Inc. | www.vastex.com | techsupport@vastex.com | [email protected] | 610-625-2702
Pg. 5
Component Identification
Heater Height Adjustment Knob
(one each side)
Heater Assembly
Heat / Belt Speed
Controls & Fuses
Conveyor Drive,
under chain guard
Chamber Assembly
Belt Guards
(one each
Belt Tracking Adjustor
(one each side)
Conveyor Components
IR Heater The infrared heaters in VASTEX dryers emit medium wave infrared heat, perfect for curing
many types of fabric inks. The heater height and tilt is adjusted by knobs located on the sides
of the chamber. A heater height scale allows for accurate height adjustment.
HI-16-D100-120
HI-16-D100-240
HI-1620-D1000-120
HI-1620-D1000-240
Chamber Components
Conveyor Assembly
3 pc D1000
Conveyor Assembly
1 pc D100
P/N 04-03-057
(Fuse AGC 1 amp)
P/N 04-01-008 (120V)
P/N 04-01-009 (240V)
P/N 04-01-004 (120V)
P/N 04-01-005 (240V)
P/N 04-02-005
D100 p/n 04-06-065
D1000 p/n 04-06-131
D1000 extension belt
p/n 04-06-132
Belt The conveyor belt is made of Teflon coated fiberglass. It is joined together with an alliga-
tor lace using a steel pin to connect each side. The belt will not burn under normal
conditions but the dryer should always have the belt moving while the heater is hot. The
belt should remain tracked in the center of each pulley. (See Belt Installation and
Tracking for adjustment instructions.)
Aligner The aligner is a device for tracking the belt and keeping it on the pulley. As the belt moves
from side to side the aligner is used for adjustments to keep it centered. The belt does
not have to be perfectly centered on the pulley but should not be hanging over either
edge.
Pulley The pulleys at either end of the conveyor are made by VASTEX of 4 ½ inch tubing with ¾
inch center shaft. They are mounted on self aligning flange bearing blocks for precision
rolling.
Gear Motor A 90 Volt DC gear motor is located to the rear of the conveyor. It drives the rear pulley
and belt with a roller and a #25 chain.
Belt Speed Control Rotate knob clockwise to increase, counter clockwise to decrease belt speed. Turn knob
counter clockwise until it clicks for off position.
Heat Control Turns power on/off and varies heater temperature.
Fuses Protects the belt drive control circuit.
One required for 120V Dryers, two required for 240V Dryers
Vastex International Inc. | www.vastex.com | techsupport@vastex.com | [email protected] | 610-625-2702
Pg. 6
Assembly D1000 Conveyor Only
The D1000 conveyor comes in three sections. Slide them
together while interlocking the joiner plates and insert six
(6) screws on each side as shown below.
1) Slide the (3) conveyor pieces together.
2) Fasten the conveyor pieces together with (6)
black sheet metal screws. Each section has a
connection on both sides of the conveyor.
Sheet metal screw
3) Finished conveyor will look as shown.
Vastex International Inc. | www.vastex.com | techsupport@vastex.com | [email protected] | 610-625-2702
Front Middle Extension Rear
Pg. 7
1) Install a Heater Knob in to both chamber side panels. Each chamber side will come with the Heater
Mount pre installed.
NOTE: Make sure the Pointer and Weld Nut line up before installing the Heater Knob.
Heater Knob
Pointer
Weld Nut
Heater Mount
2) Install the Front and Rear Panel to one of the Side Panels with (6) black sheet metal screws.
Sheet Mtl Screw
Rear Panel
Front Panel
Side Panel
3) Install the opposite Side Panel to the Front and Rear Panels with (6) sheet metal screws.
Sheet Mtl Screw
Side Panel
Assembly
Vastex International Inc. | www.vastex.com | techsupport@vastex.com | [email protected] | 610-625-2702
Pg. 8
Assembly Continued
4) Install a Heater Hanger on to each side of the Heater using (4) black sheet metal screws. Be sure to
use the top set of holes on the side of the heater.
NOTE: If you desire to have your heater height 1”(25.4mm) higher than the scale on the side of the
chamber use the bottom set of holes.
Sheet Mtl Screw
Heater Hanger
Use for heater
heights 1-6
Use for heater
heights 2-7
5) Lay the assembled heater into the chamber. The tabs pointing up on the Heater Mounts will fit into
the openings on the Heater Hanger. Make sure to have the heater wires on the right side of the
chamber.
Tabs aligning with
openings on hanger
Wires on right side
Vastex International Inc. | www.vastex.com | techsupport@vastex.com | [email protected] | 610-625-2702
Pg. 9
6) Install a the Heater Hold Down on each side of the heater using (2) black sheet metal screws.
Assembly Continued
Sheet Mtl Screw
Heater Hold Down
7) Place the chamber on to the conveyor. The bottom of the chamber has tabs that fit into slots on the
conveyor.
8) Fasten the chamber to the conveyor with (6) black sheet metal screws, (3) per side.
Sheet Mtl Screw
Vastex International Inc. | www.vastex.com | techsupport@vastex.com | [email protected] | 610-625-2702
Make sure tabs
are in the slots
of the conveyor
!
Pg. 10
Otros manuales para D-100
1
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Secadora de VASTEX
Manuales populares de Secadora de otras marcas
Indesit
Indesit IDV 75 Manual de usuario
Infiniton
Infiniton SD-DG85C Manual de usuario
BOMANN
BOMANN WT 5019 Manual de usuario
Alliance Laundry Systems
Alliance Laundry Systems TMB795C Manual de usuario
Asko
Asko T793C Manual de usuario
Kenmore
Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manual de usuario
