Varytec VP-m5 Manual de usuario

Thomann GmbH • Hans-Thomann-Straße 1 • 96138 Burgebrach • www.thomann.de • [email protected] DocID: 522506_20.09.2021

VP-m5 Mobile Video BiLight

Quick start guide

This quick start guide contains important information on the safe operation of the

product. Read and follow the safety advice and instructions given. Retain the quick

start guide for future reference. If you pass the product on to others please include this

quick start guide.

Safety instructions

Intended use

This device is intended to be used as a portable video light. Any other use or use

under other operating conditions is considered to be improper and may result in per-

sonal injury or property damage. No liability will be assumed for damages resulting

from improper use.

Danger for children

Ensure that plastic bags, packaging, etc. are disposed of properly and are

not within reach of babies and young children. Choking hazard! Ensure

that children do not detach any small parts from the product. They could

swallow the pieces and choke!

Eye damage caused by high light intensity

Never look directly into the light source.

Where to use the product

Never use the product

• in conditions of extreme temperature or humidity

• in extremely dusty or dirty areas

• at locations where the unit can become wet

General handling

• To prevent damage, never use force when handling the product.

• Never immerse the product in water. Just wipe it with a clean dry cloth. Do not

use liquid cleaners such as benzene, thinners or ammable cleaning agents.

Using the product

1. First the internal battery must be charged. To do this, connect the device to a

suitable voltage source (not supplied) via its USB-C port e.

2. Place the device with its connection won the hot shoe of the camera to be used.

3. Press the switch tto switch on the device.

4. Set the desired lighting intensity with the brightness control r.

5. Set the desired colour temperature between 2600  5700K with the colour

temperature control y.

6. Observe the battery charge level indicator qto estimate the remaining operat-

ing time. If the video light goes out, the internal battery must be recharged.

7. Press the switch tto switch o the device.

Features

• Mini LED video light with variable colour temperature and built-in battery

• Steplessly dimmable

• Easy operation via rotary controls

• With 1/4" internal thread

• USB-C port for charging

• Battery charge level indicator

• Colour temperature steplessly adjustable from 2550–6140K

Operating elements





 

öBattery charge level indicator

#Connection for hot shoe

$USB-C port

%Brightness control

&On / o switch

'Colour temperature control

Thomann GmbH • Hans-Thomann-Straße 1 • 96138 Burgebrach • www.thomann.de • [email protected] DocID: 522506_20.09.2021

VP-m5 Mobile Video BiLight

For the transport and protective packaging, environmentally friendly materials

have been chosen that can be supplied to normal recycling. Ensure that plastic

bags, packaging, etc. are properly disposed of. Do not just dispose of these ma-

terials with your normal household waste, but make sure that they are collected for recy-

cling. Please follow the notes and markings on the packaging.

This product is subject to the European Waste Electrical and Electronic Equip-

ment Directive (WEEE) in its currently valid version. Do not dispose of your old

device with your normal household waste. Dispose of this product through an

approved waste disposal rm or through your local waste facility. Comply with the rules

and regulations that apply in your country. If in doubt, consult your local waste disposal

facility.

Remove lithium batteries from the device before disposal. Protect used lithium

batteries against short circuit, for example by taping the poles. Lithium batter-

ies must not be thrown away or incinerated; they must be disposed of in accordance with

local regulations for the disposal of hazardous waste. Use the existing collection points

for this.

Technical specications

Light source 66 × SMD-LED (33 × warm white, 33 × cold white)

Light source properties Colour temperature 2550–6140K, steplessly adjustable

Colour rendering index CRI >95

Optical properties Beam angle 120°

Light output 800lm

Input connections Charging port USB-C

Power consumption LEDs 5W

Power supply USB (5V )

Battery / rechargeable battery Battery type Lithium-Ion

Voltage 3.7V

Capacity 2000mAh

Charging time 3.5h

Operating time 210h (depending on brightness setting)

Protection class IP20

Mounting options camera hot shoe

Mounting options (W × H × D) 92 mm×21 mm×78 mm

Weight 110g

Ambient conditions Temperature range 0 °C40°C

Relative humidity 2080%, non-condensing
