Vaporesso Target 80 Manual de usuario

User Manual

Thank you for choosing Vaporesso product. Please read this instruction carefully before use to ensure a perfect

experience. If there is any additional requirement about this product, please consult the local agent or contact us

through our website: www.vaporesso.com

Drip Tip

Power Button

0.96" TFT Screen

“+” Button

Mode/ Conﬁrm Button

“-” Button

Type-C USB Port

PCTG Tube

Top Cap

Air-inlet Port

EXPLODED VIEW

SPECIFICATIONS

Dimensions: 130.9 x 38.3 x 30.8mm

POD Capacity: 5ml/2ml(TPD)

Coils & Suggested Waage:

GTX 0.2ΩMESH Coil (45-60W)

GTX 0.3ΩMESH Coil (32-45W)

Baery Capacity: 3000mAh

Output Power: 5-80W

Charging Current: DC 5V/2A,Type-C

Baery Display: 0.96’’ TFT Screen

PACKING LIST

1 x TARGET 80 MOD

1 x GTX PODTANK 26 (5ml/2ml TPD)

1 x GTX 0.2Ω MESH Coil (In-BOX)

1 x GTX 0.3Ω MESH Coil (In-BOX)

1 x Type-C Cable

1 x User Manual

1 x Warranty Card

FIGURES

Figure 1: Replace the coil

Figure 2: Fill e-liquid

OPEN CLOSE

English

ENGLISH

USE INSTRUCTIONS

1. Install the Tank

Install the tank to the battery by screwing the 510 thread. Make sure they are ﬁrmly connected.

2. Replace the Coil

- Place the drip tip of the pod face down, and pull out the used coil;

- Install a new coil to the pod;

- Press the coil to align the coil base with the pod.

* Refer to the ﬁgure 1.

3. Fill E-liquid

- Unscrew the top cap from the pod;

- Fill e-liquid through the ﬁlling slot;

- Screw the top cap to reinstall it back into place as shown;

- Please wait 5 minutes for the e-liquid to soak into the coil completely.

* Refer to the ﬁgure 2.

4. Adjust the Airﬂow

Please rotate the pod to match the air-inlet port to adjust the airﬂow volume.

5. Power On/Off the Device

Power on/off: press the power button 5 times in 2s.

6. Power Adjustment

TARGET 80 Kit is using the powerful GTX coil platform, and the suggested power need to be noticed

before start vaping.

GTX MESH Coils GTX 0.2Ω MESH GTX 0.3Ω MESH

Suggested Power 45-60W 32-45W

7. Start Vaping

Press the power button to enjoy extraordinary vaping experience.

2English

8. Charge the Baery

After connecting the Type-C cable to the battery, the battery indicator and remaining charging time will be showed on

the screen.

9.Lock or unlock the device

Press the ﬁre button 3 times, then the +, - and mode buttons will be locked. In the same way, the buttons will be

unlocked and the screen will be unlocked.

10. Choose a Mode

1. Long press the mode button for main mode selection (Pulse Mode/F(t) Mode/VWN Mode).

2. Press the mode button 3 times continuously for secondary menu setting.

*F(t): F(t) MODE (DEFAULT)

F(t) MODE is by adjusting temperature,

heating speed and time, F(t) mode releases

the ﬂavors of e-liquid adequately, delivering

the perfect balanced tasting experience

consistently from the ﬁrst puff throughout.

*DIY: DIY MODE

You can choose traditional VW (H, N, S), VV,

BP (Bypass) modes in this section.

*PUL: PULSE MODE (DEFAULT)

PULSE MODE: It’s a mode to improve

vaping experience through constant voltage

output, delivering optimal ﬂavor production,

throat hit, nicotine satisfaction, and perfect

temperature cloud continuously.

*SET: SYSTEM SET

System setting includes DEFAULT, SMART VW,

PUFF, and VERSION options.

SMART VW: when this function is turned

on and a POD is installed, the system will

recommend the best power.

English

1. Short circuit protection & Low resistance protection:

When the load resistance is less than 0.1±0.01Ω, press power button could trigger the short circuit protection or Low

resistance protection, the device will close the output, at the same time OLED display will show “SHORT ATOMIZER”.

2. No load protection:

When no load resistance is detected, press power button could trigger the no load protection, the device will close the

output, at the same time OLED display will show “CHECK ATOMIZER”.

3. High resistance protection:

When the load resistance is greater than 5±0.5Ω, press power button could trigger the high resistance protection, the

device will close the output, at the same time OLED display will show “ CHECK ATOMIZER ”.

4. Low voltage protection:

When the voltage of the battery cell is lower than 3.3±0.1V, press power button could trigger the low voltage protection,

the device will close the output, at the same time OLED display will show “LOW BATTERY”.

5. PCBA(Printed Circuit Board Assembly):

When the temperature of the PCBA(Printed Circuit Board Assembly) temperature sensor is higher than 70+5℃/-10℃,

press power button could trigger the PCBA (Printed Circuit Board Assembly) over heat protection, the device will close

the output, at the same time OLED display will show “OVER HEAT”.

6. Over discharge protection:

During the process of smoking, when the battery cell voltage is lower than 2.9±0.1 V, the device will close the

output automatically.

7. Over charge protection:

During charging, when the battery cell voltage is greater than 4.1±0.1V, OLED display will show “100%”. At the end of

charging, battery cell voltage will not exceed 4.2±0.03V.

8. Auto-shut off protection:

When POWER button is held for 10±1 seconds, the device will close the output, at the same time OLED display will

show “OVER TIME”.

9. Baery cell anti-reverse connection protection:

The inversion of battery cell will not damage the battery.

PROTECTIONS

4English

1. Please turn off the device when it is not in use.

2. Do not leave the charging device unattended.

3. Do not drop, throw or abuse your device, which may cause damage.

4. Please use a standard USB output charger with proper charging current and voltage range.

5. Keep away from the water or any ﬂammable gas, liquid .

6. Do not expose the device to direct sunlight, dust, moisture or mechanical shock.

7. Do not expose the device to extreme temperature. (Recommended temperature range: -10~60℃/14~140℉while

using and -10~45℃/14~113℉while storing).

8. EEE Recycling: the product should not be treated as household waste, instead, it should be handed over to the

applicable collection point for the recycling of electrical and electronic equipment.

9. Battery Recycling: the product battery should not be treated as household waste, instead, it should be handed over

to the applicable used battery collection point for recycling.

10. Only have your device repaired by Vaporesso. Do not attempt to repair it by yourself as damage or personal injury

may occur.

WARNINGS

This reﬁllable electronic cigaree is intended for use with compatible e-liquid, which may contain nicotine. Nicotine is

an addictive substance and it is not suitable or recommended to use in following cases:

1. This device is not suitable for:

- Persons under the legal smoking age.

- Persons experiencing heart disease, stomach or duodenal ulcers, liver or kidney problems, long-term throat disease

or difﬁcult breathing due to bronchitis, emphysema or asthma.

- Persons with an overactive thyroid gland or experiencing phaeochromocytoma (a tumour of the adrenal gland that

can affect blood pressure).

- Persons taking certain medications like Theophylline, Ropinirole or Clozapine and etc..

CAUTIONS

English

2. This device is not recommended for:

- Non-smokers

- Pregnant or breastfeeding women

3. You may experience the following results if you use nicotine containing e-liquid with this product. If it happens,

please consult a healthcare professional and show them this leaﬂet if possible:

- Feeling faint - Nausea - Dizziness - Headache - Coughing - Irritation of the mouth or throat

- Stomach discomfort - Hiccups - Nasal congestion - Vomition

- Chest palpitations/pain or an irregular heart rate

This device should not be used by persons under the legal smoking age.

1Français

FRANÇAIS

CONSIGNES D’UTILISATION

1. Installation du réservoir

Installez le réservoir sur la batterie en les vissant ensemble grâce au filetage 510. Vérifiez qu’ils sont fermement

connectés.

2. Remplacement de la résistance

- Tournez l’embout de remplissage du POD vers le bas, et tirez sur la résistance coil usée pour la retirer ;

- Installez une nouvelle coil sur le POD ;

- Appuyez sur la coil pour aligner sa base sur le pod.

* Voyez la ﬁgure 1.

3. Recharge de l’e-liquide

- Dévissez le bouchon du haut du POD en suivant le sens de la ﬂèche ;

- Versez l’e-liquide dans le trou de remplissage ;

- Vissez le bouchon du haut pour le remettre en place comme illustré ;

- Veuillez patienter 5 minutes, le temps que l’E.-liquide imbibe complètement la résistance.

* Voyez la ﬁgure 2.

4. Réglage du débit d’air

Veuillez faire tourner le POD pour aligner le port d’entrée d’air sur la batterie et ajuster le débit d’air.

5. Mise en marche/arrêt de l’appareil

- Marche/Arrêt : appuyez sur le bouton d'alimentation à 5 reprises en 2 secondes.

6. Réglage de la puissance

Le kit TARGET 80 utilise la plateforme GTX puissante, et il est donc nécessaire de vériﬁer la puissance

avant de commencer à vapoter.

7. Commencer à vapoter

Appuyez sur le bouton d’alimentation pour vivre une expérience de vapotage extraordinaire.

Résistances GTX MESH GTX 0,2Ω MESH GTX 0,3Ω MESH

Puissance suggérée 45-60 W 32-45 W
