Vaporesso TARGET 100 Manual de usuario

User Manual

Thank you for choosing Vaporesso product. Please read this instruction carefully before use to ensure a perfect

experience. If there is any additional requirement about this product, please consult the local agent or contact us

through our website: www.vaporesso.com

Drip Tip

Power Button

0.96" TFT Screen

“+” Button

Mode/ Conrm Button

“-” Button

Type-C USB Port

Glass Tube

Top Cap

Air-inlet Port

EXPLODED VIEW

SPECIFICATIONS

Dimensions: 140.3*28.6*35.1mm

POD Capacity: 5ml/2ml(TPD)

Coils & Suggested Wattage:

GTi 0.2Ω MESH Coil (60-75W)

GTi 0.4Ω MESH Coil (50-60W)

Battery Capacity: 1 x 18650/21700 Battery(Not Included)

Output Power: 5-100W

Charging Current: DC 5V/2A,Type-C

Battery Display : 0.96’’ TFT Screen

PACKING LIST

1 x VAPORESSO TARGET 100 MOD

1 x VAPORESSO iTANK (5ml/2ml TPD)

1 x GTi 0.2Ω MESH Coil (Pre-installed)

1 x GTi 0.4Ω MESH Coil (In-BOX)

1 x Extra Glass Tube

3 x O-ring

1 x Type-C Cable

1 x User Manual

1 x Warranty Card

FIGURES

Figure 1: Replace the coil Figure 3 User Interface

OPEN CLOSE

Figure 2: Fill e-liquid

Wattage

Output Voltage

Battery Level

Vaping Time

System Lock

Output Mode

Pu Counter

Resistance

Smart VW

English

ENGLISH

USE INSTRUCTIONS

1. Install the Tank

Install the tank to the battery by screwing the 510 thread. Make sure they are rmly connected.

2. Replace the Coil

- Unscrew the thread base from the tank;

- Pull out the used coil from the tank;

- Install a new coil to the tank;

- Reattach the thread base into place.

* Refer to the gure 1.

3. Fill E-liquid

- Push the top cap according to the arrow direction;

- ll e-liquid through the hole, then lock the top cap in place after lling is nished.

- Please wait 5 minutes for the e-liquid to soak into the coil completely.

* Refer to the gure 2.

4. Adjust the Airow

To adjust the airow volume, please rotate the air-inlet ring on the bottom of the tank.

5. Power On/O the Device

Power on/o: press the power button 5 times in 2s.

6. Power Adjustment

TARGET 100 Kit is using the powerful GTi coil platform, and the suggested power need to be noticed

before start vaping.

GTi MESH Coils GTi 0.2 MESH GTi 0.4 MESH

Suggested Power 60-75W 50-60W

7. Start Vaping

Press the power button to enjoy extraordinary vaping experience.

2English

8. Charge the Battery

After connecting the Type-C cable to the battery, the battery indicator and remaining charging time will be showed on

the screen.

9.Lock or unlock the device

Press the re button 3 times, then the +, - and mode buttons will be locked. In the same way, the buttons will be

unlocked and the screen will be unlocked.

10. Choose a Mode

1. Long press the mode button for main mode selection ( Pulse Mode/F(t) Mode/VWN Mode).

2. Press the mode button 3 times continuously for secondary menu setting.

*F(t): F(t) MODE (DEFAULT)

F(t) MODE is by adjusting temperature, heating speed and time, F(t) mode releases the avors of e-liquid adequately,

delivering the perfect balanced tasting experience consistently from the rst pu throughout.

*PUL: PULSE MODE

PULSE MODE is a mode to improve vaping experience through constant voltage output, delivering optimal flavor

production, throat hit, nicotine satisfaction, and perfect temperature cloud continuously.

*VWN: VARIABLE WATTAGE MODE/ SIMPLE MODE

VWN MODE is a normal mode of output wattage, you can according to the coil resistance to adjust the best wattage for

your needs. The user interface shows wattage, resistance and pu counter for your immersive vaping experience.

*DIY: DIY MODE

You can choose traditional VW (H, N, S), VV, BP (Bypass) modes in this section.

*SET: SYSTEM SET

System setting includes DEFAULT, SMART VW, PUFF, and VERSION options.

SMART VW: when this function is turned on and a TANK is installed, the system will recommend the best power.

English

1. Short circuit protection & Low resistance protection:

When the load resistance is less than 0.1±0.01Ω, press power button could trigger the short circuit protection or Low

resistance protection, the device will close the output, at the same time OLED display will show “SHORT ATOMIZER”.

2. No load protection:

When no load resistance is detected, press power button could trigger the no load protection, the device will close the

output, at the same time OLED display will show “CHECK ATOMIZER”.

3. High resistance protection:

When the load resistance is greater than 5±0.5Ω, press power button could trigger the high resistance protection, the

device will close the output, at the same time OLED display will show “ CHECK ATOMIZER ”.

4. Low voltage protection:

When the voltage of the battery cell is lower than 3.3±0.1V, press power button could trigger the low voltage protection,

the device will close the output, at the same time OLED display will show “LOW BATTERY”.

5. PCBA(Printed Circuit Board Assembly):

When the temperature of the PCBA(Printed Circuit Board Assembly) temperature sensor is higher than 70+5℃/-10℃,

press power button could trigger the PCBA (Printed Circuit Board Assembly) over heat protection, the device will close

the output, at the same time OLED display will show “OVER HEAT”.

6. Over discharge protection:

During the process of smoking, when the battery cell voltage is lower than 2.9±0.1 V, the device will close the

output automatically.

7. Over charge protection:

During charging, when the battery cell voltage is greater than 4.1±0.1V, OLED display will show “100%”. At the end of

charging, battery cell voltage will not exceed 4.2±0.03V.

8. Auto-shut o protection:

When POWER button is held for 10±1 seconds, the device will close the output, at the same time OLED display will show

“OVER TIME”.

9. Battery cell anti-reverse connection protection:

The inversion of battery cell will not damage the battery.

PROTECTIONS

4English

1. Please turn o the device when it is not in use.

2. Do not leave the charging device unattended.

3. Do not drop, throw or abuse your device, which may cause damage.

4. Please use a standard USB output charger with proper charging current and voltage range.

5. Keep away from the water or any ammable gas, liquid .

6. Do not expose the device to direct sunlight, dust, moisture or mechanical shock.

7. Do not expose the device to extreme temperature. (Recommended temperature range: -10~60℃ /14~140℉while using

and -10~45℃ /14~113℉while storing).

8. EEE Recycling: the product should not be treated as household waste, instead, it should be handed over to the

applicable collection point for the recycling of electrical and electronic equipment.

9. Battery Recycling: the product battery should not be treated as household waste, instead, it should be handed over

to the applicable used battery collection point for recycling.

10. Only have your device repaired by Vaporesso. Do not attempt to repair it by yourself as damage or personal injury

may occur.

WARNINGS

This rellable electronic cigarette is intended for use with compatible e-liquid, which may contain nicotine. Nicotine is

an addictive substance and it is not suitable or recommended to use in following cases:

1. This device is not suitable for:

- Persons under the legal smoking age.

- Persons experiencing heart disease, stomach or duodenal ulcers, liver or kidney problems, long-term throat disease or

dicult breathing due to bronchitis, emphysema or asthma.

- Persons with an overactive thyroid gland or experiencing phaeochromocytoma (a tumour of the adrenal gland that can

aect blood pressure).

- Persons taking certain medications like Theophylline, Ropinirole or Clozapine and etc..

CAUTIONS

English

2. This device is not recommended for:

- Non-smokers

- Pregnant or breastfeeding women

3. You may experience the following results if you use nicotine containing e-liquid with this product. If it happens,

please consult a healthcare professional and show them this leaet if possible:

- Feeling faint - Nausea - Dizziness - Headache - Coughing - Irritation of the mouth or throat

- Stomach discomfort - Hiccups - Nasal congestion - Vomition

- Chest palpitations/pain or an irregular heart rate

This device should not be used by persons under the legal smoking age.
