V-1069A

EXPLOSION PROOF TALKBACK HORN

INTRODUCTION

The V-1069A is an Explosion Proof Handsfree

Talkback Horn designed to be used with Valcom

Handsfree Talkback Control Units features -

explosion proof construction, metal and

polycarbonate plastic construction, a wide dispersion

angle, and an omni-directional mounting bracket and

may be used for either interior or exterior paging

applications.

The horn meets or exceeds UL standards for use in

hazardous areas classified as:

Class I, Division I, Groups C & D: Gas Atmospheres

The V-1069A has received an FCC type KX

registration, designed to be used with FCC registered

Key Telephone Systems. In accordance with FCC

rules with applicable tariffs, this Paging Unit may

only be installed with the authorization of the host

system. Installations may be made by Valcom, Inc.,

an authorized agent of the same, equipment

manufacturers, telephone companies, registered

telephone refurbishers, and those qualified for

installation of FCC registered systems under FCC

Rules Section 68.215. The FCC Registration

Number, BAF9I7-69358-KX-N, will be listed in the

affidavits filed with the telephone company; it will

also be recorded in the system log kept by installation

and maintenance personnel. The local telephone

company is to be notified of the FCC Registration

Number when this Paging Unit is installed.

NOMINAL SPECIFICATIONS

Frequency 250-12,000Hz

Dimensions 8.0” H x 14.6" W x 17.0" D

(20.32cm H x 37.08cm W x 43.18cm D)

Dispersion 120 x 60

Conduit access 1/2"

Weight 19 lbs. (8.63Kg)

INSTALLATION

CAUTION: To prevent ignition of hazardous

atmosphere, disconnect product from supply circuit

before opening. Keep assembly tightly closed when

in operation. Unit must be installed in accordance

with National Electrical Code requirements for

hazardous atmospheres.

Exercise special care in removing back cover of

explosion-proof driver enclosure to avoid damaging

machined surfaces. Prior to re-assembly, make

certain that joining surfaces of enclosure are free of

dirt. Install and tighten all bolts completely. To

provide the specified protection in hazardous

locations, please note that no compound of any type

is to be applied on machined flange.

Caution must be exercised in not placing the speaker

assembly near noise making equipment such as fans,

transformers, air conditioner units, etc., as this will

impair the transmission back to the caller.

Mount the horn to a suitable surface 10 to 15 feet

from the floor taking into account installation and

maintenance accessibility. By loosening the two nuts

which fasten the mounting bracket to the horn, the

horn may be moved up and down to obtain the

desired position.

Connect "D" station wire (or other suitable pairs) to

the proper speaker leads for connection to the audio

source (tip and ring). Limit cable runs from Valcom

Talkback Control Unit to talkback horns to not more

than 800 feet.

2947068

TECHNICAL ASSISTANCE

When trouble is reported, verify there are no broken connections. Assistance in troubleshooting is available from the

factory. Call (540) 427-3900, and ask for Technical Support, or call (540) 427-6000 for Valcom 24-hour Automated

Support or visit our website at http://www.valcom.com.

Valcom equipment is not field repairable. Valcom, Inc. maintains service facilities in Roanoke, VA. Should repairs

be necessary, attach a tag to the unit clearly stating company name, address, phone number, contact person, and the

nature of the problem. Send the unit to: Valcom, Inc.

Repair and Return Dept.

5614 Hollins Road

Roanoke, VA 24019-5056

TROUBLESHOOTING CHART

PROBLEM PROBABLE CAUSES AND CORRECTIONS

No Sound in Page Mode

Low Sound in Page Mode

Poor Listening in Talkback

Mode

1. Check tip and ring for audio at speaker.

2. Check tip and ring at control unit.

1. Check volume controls at page control.

1. Check talkback volume controls at page control. Set control at minimum suitable

listening level.

VALCOM LIMITED WARRANTY

Valcom, Inc. warrants its products to be free from defects in materials and workmanship under conditions of normal use and service for

a period of one year from the date of shipment. The obligation under this warranty shall be limited to the replacement, repair or refund

of any such defective device within the warranty period, provided that:

1. inspection by Valcom, Inc. indicates the validity of the claim,

2. the defect is not the result of damage, misuse, or negligence after the original shipment,

3. the product has not been altered in any or repaired by others and that factory sealed units are unopened (A service charge plus parts

and labor will be applied to units defaced or physically damaged)

4. freight charges for the return of products to Valcom are prepaid,

5. all units 'out of warranty' are subject to a service charge. The service charge will cover minor repairs (major repairs will be subject

to additional charges for parts and labor).

This warranty is in lieu of and excludes all other warranties, expressed or implied, and in no event shall Valcom, Inc. be liable

for any anticipated profits, consequential damages, loss of time or other losses incurred by the buyer in connection with the

purchase, operation or use of the product.

This warranty specifically excludes damage incurred in shipment. In the event a product is received in damaged condition, the carrier

should be notified immediately. Claims for such damage should be filed with the carrier involved in accordance with the F. O. B. point.

Headquarters:

Valcom, Inc.

1111 Industry Avenue

Roanoke, VA 24013

Phone: (540) 427-3900

FAX: (540) 427-3517

In Canada:

CMX Corporation

35 Van Kirk Drive #11 and 12

Brampton, Ontario L7A1A5

Phone: (905) 456-1072

FAX: (905) 456-2269

Valcom

Talkback

Page Control

Power Supply

(if required)

V-1069A

(up to 2

per zone)

Zone

Output

(Blue) Tip

(Orange) Ring

CONNECTIONS TO A V-1069A
