V-ZUG DW-SM9 Manual de usuario

Range hood

DW-SM9

Operating instructions

V-ZUG Ltd

Thank you for choosing to buy one of our products. Your appliance is made

to high standards and is easy to use. Nevertheless, please take the time to

read these operating instructions in order to familiarize yourself with the

appliance and get the best use out of it.

Please follow the safety precautions.

Modifications

Text, diagrams and data correspond to the technical standard of the appli-

ance at the time these operating instructions went to press. The right to make

technical modifications for the purpose of the further development of the

appliance is reserved.

Symbols used

AIndicates step-by-step instructions.

– Describes how the appliance reacts to the steps taken.

䡲Indicates a list.

Validity

The model number corresponds to the first three digits on the identification

plate. These operating instructions apply to the model:

Variations depending on the model are noted in the text.

Denotes important safety precautions. Failure to observe said pre-

cautions can result in injury or damage to the appliance or fittings!

Denotes useful tips for the user.

Type Model no.

DW-SM9 330

Contents

Safety precautions 5

Before using for the first time . . . . . . . . . . . . . . . . . . . . . . . . 5

Correct use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Children in the home . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Note on use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Appliance description 9

Extraction mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Recirculation mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Fitted with . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Construction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Operating and display elements . . . . . . . . . . . . . . . . . . . . . 12

Use 13

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Intensive level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Illumination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Saturation indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Care and maintenance 16

Cleaning the housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Cleaning the grease filters . . . . . . . . . . . . . . . . . . . . . . . . . 17

Changing the standard activated charcoal filter . . . . . . . . 19

Cleaning and changing the long-life activated

charcoal filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Changing the halogen light . . . . . . . . . . . . . . . . . . . . . . . . . 22

Trouble-shooting 23

What to do if … . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

… Contents

Accessories and spare parts 24

Technical data 25

Disposal 26

Notes 27

Index 29

Repair service 31

Quick instructions 32

Safety precautions

In accordance with the requirements of IEC 60335-1:

䡲This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless supervised or unless they have been given instruction

concerning the use of the appliance by a person responsible for their

safety.

Before using for the first time

䡲The appliance must be installed and connected up to the electricity supply

according to the separate installation instructions. The necessary work

should be carried out by a qualified fitter or electrician.

䡲Dispose of the packaging material in accordance with local regulations.

The appliance corresponds to recognised technology standards

and the relevant safety regulations. Proper use of the appliance is

however essential to avoid damage and accidents. Please there-

fore follow the precautions given in these operating instructions.

… Safety precautions

Correct use

䡲The appliance is designed for use in the home for extracting cooking fumes

and smells from above the cooking surface.

䡲Any repairs, modifications or manipulations to the appliance, especially

any electrically live parts, should only be carried out by the manufacturer,

its Customer Services or similarly qualified persons. Repairs if carried out

incorrectly may cause serious injury, damage to the appliance and fittings,

as well as affect the functioning of the appliance. If the appliance is not

working properly or in case of a repair order, follow the instructions given

in the 'Repair service' section. Please contact our Customer Services if

necessary.

䡲Use original spare parts only.

䡲Retain these operating instructions for future reference. If you sell or pass

the appliance on to a third party, please ensure these operating instruc-

tions, together with the installation instructions, accompany the appliance.

In this way, the new owner can inform themselves about how to use the

appliance correctly and read the pertinent safety precautions.

Children in the home

䡲Packaging material e.g. plastic and polystyrene can be dangerous for chil-

dren. Danger of suffocation! Please keep packaging material away from

children.

䡲The appliance is designed for use by adults who are familiar with these op-

erating instructions. Children are often unable to recognise the danger of

electrical appliances. Ensure proper supervision and do not allow children

to play with the appliance – there is a danger that children can hurt

themselves.

… Safety precautions

Note on use

䡲If the appliance is visibly damaged, do not use it. Contact our Customer

Services.

䡲If the appliance is not operating properly, disconnect it from the electricity

supply immediately.

䡲Caution: Accessible parts may become hot when used with cooking

appliances.

䡲Do not flambé food underneath the hood as the grease filters if laden with

grease could catch fire.

䡲If frying on the cooking surface, do not leave the frying appliance unattend-

ed. The cooking oil in the frying appliance could overheat and catch fire.

Constantly monitor the temperature of the cooking oil, keeping it below the

temperature at which it can catch fire. Change the cooking oil regularly –

dirty oil catches fire more easily than clean oil.

䡲Clean the filters regularly. Failure to do so can increase the fire hazard due

to the build-up of grease in the grease filter.

䡲Do not operate the individual cooking zones of the cooking surface without

a pan on them or with an empty pan on them so as to avoid damaging the

appliance or the kitchen fittings through a build-up of heat. Avoid open fires

with oil, gas, wood and coal fired cookers.

䡲Ensure there is adequate ventilation when the extraction fan is on so as to

avoid creating a disturbing underpressure in the kitchen and to achieve op-

timal air extraction.

䡲Avoid a cross-current of air, which could blow the cooking vapours over

the cooking area.

… Safety precautions

䡲If another appliance – fuelled by gas or other fuels – is being used at the

same time, ensure that there is a sufficient supply of fresh air. This does

not apply to air recirculation units.

䡲With the simultaneous operation of firing (e.g. wood, gas, oil or coal-fired

heating systems), safe operation is only possible providing a room nega-

tive pressure of 4 Pa (0.04 mbar) is not exceeded at the location of the ap-

pliance. Risk of toxic fumes! An adequate flow of fresh air must be

guaranteed, e.g. via non-closable openings in doors and windows and

combined with ventilation wall bricks for incoming and exhaust air or by

other technical means.

䡲When carrying out maintenance work on the appliance, including replacing

the light bulb, cut off the electricity supply to the appliance (remove the

screw fuse from the holder or switch the circuit breaker off, or disconnect

from the mains supply).

䡲When cleaning the appliance make sure no water gets inside the appli-

ance. Use a moderately damp cloth. Do not spray the inside or outside of

the appliance with water. Do not use a steam cleaner. If water gets inside

the appliance, it can cause damage.

Appliance description

The appliance is designed tor use in the home for extracting cooking fumes

and smells from the cooking area. The appliance is based on a completely

new functional concept whereby more cooking fumes can be removed with

significantly less air being extracted. The grease particles in the extracted air

are trapped very efficiently in the combi filters and metal grease filters.

The appliance can be used in extraction or recirculation mode.

Extraction mode

The cooking fumes and smells above the cooking area are removed by an

extractor fan. The extracted air is filtered through the combi filters and metal

grease filters and passed through a pipe with an integrated non-return valve

and then through an air duct to the outside.

Recirculation mode

The cooking fumes and smells above the cooking area after being filtered

through the combi filters and metal grease filters are passed through an ac-

tivated charcoal filter. The filtered air is then circulated back into the room

through the side openings.

When the appliance is in use, ensure that there is a sufficient supply

of fresh air to replace the air that is being extracted.

If activated charcoal filters are not supplied with the appliance, these

should be ordered and installed before using the appliance. Further-

more, the saturation indicator for the activated charcoal filters must

also be activated.

… Appliance description

Fitted with

䡲1extractionfan

䡲Illumination

䡲2 metal grease filters

䡲3combifilters

䡲1 activated charcoal filter

The extraction fan has 4 power levels.

䡲1 = Low, 2 = Medium, 3 = High and Intensive level.

䡲Power levels 1–3 can be used for longer periods of operation.

䡲The intensive level is for shorter bursts of intensive extraction of the cook-

ing fumes and smells, e.g. when searing meat. The intensive level runs for

a maximum of 5 minutes at a time.
