V-tech Stencil & Learn Studio Manual de usuario

User’s Manual

Printed in China

91-002759-005 US

Stencil & Learn StudioTM

INTRODUCTION

Thank you for purchasing the VTech®Stencil & Learn StudioTM!

The Stencil & Learn StudioTM by VTech®is an innovative magnetic

drawing studio that will enhance your child’s creativity as they learn!

The studio comes with 28 different cards that feature letters, numbers,

and shapes. As your child inserts each cards into the special slot, the

studio recognizes the card and verbally guides your child through tracing

and writing what’s on the card. Also included are Scribble Gears design

tools, three magnetic stamps, and a musical instrument sheet that will

help stimulate your child’s imagination and creativity as they doodle.

Introduction

ON/OFF

BUTTON

3 MAGNETIC

STAMPS

VOLUME CONTROL

BUTTON

5 ACTIVITY

BUTTONS

MUSIC

BUTTON

ATTACHED

PEN

ABC SLIDE

ERASER

INCLUDED IN THIS PACKAGE

• OneVTech®Stencil & Learn StudioTM

• Oneuser’smanual

• 26lettercards,1numberscard,1shapescard,1largeblankcard

and 1 instrument sheet

• 3magneticstampsand1scribblegearset

WARNING: All packing materials, such as tape, plastic sheets,

packaging locks and tags are not part of this toy, and

should be discarded for your child’s safety.

ATTENTION : Pour la sécurité de votre enfant, débarrassez-vous de

tous les produits d’emballage tels que rubans adhésifs,

feuilles de plastique, attaches et étiquettes. Ils ne font

pas partie du jouet.

NOTE: Please keep instruction manual as it contains important

information.

Unlock the packaging locks:

Rotate the packaging locks 90 degrees

counter-clockwise.

Pull out the packaging lock.

Getting Started

GETTING STARTED

BATTERY INSTALLATION

1. Make sure the unit is OFF.

2. Locate the battery cover on the

bottom of the unit.

3. Open the battery cover.

4. Install 3 new “AA” (AM-3/LR6)

batteries into the compartment

as illustrated. (The use of new,

alkaline batteries is recommended

formaximumperformance.)

5. Replace the battery cover.

BATTERY NOTICE

• Usenewalkalinebatteriesformaximumperformance.

• Useonlybatteriesofthesameorequivalenttypeasrecommended.

• Donotmixdifferenttypesofbatteries:alkaline,standard(carbon-

zinc)orrechargeable(Ni-Cd,Ni-MH),ornewandusedbatteries.

• Donotusedamagedbatteries.

• Insertbatterieswiththecorrectpolarity.

• Donotshort-circuitthebatteryterminals.

• Removeexhaustedbatteriesfromthetoy.

• Removebatteriesduringlongperiodsofnon-use.

• Donotdisposeofbatteriesinre.

• Donotchargenon-rechargeablebatteries.

• Remove rechargeable batteries from the toy before charging (if

removable).

• Rechargeable batteries are only to be charged under adult

supervision.

Battery notice

BEFORE USE

After unpacking, or after a long period of non-use, the magnetic surface

of the studio screen will need to be re-activated to improve the drawing

and writing functions. Use the STAMPS to cover the surface of the

screen, and then use the ABC SLIDE ERASER back and forth several

times until the surface is clear.

INSERTING A CARD OR SHEET

1. Chooseoneofthe26lettercards,thenumberscard,ortheshapes

card to practice your writing and drawing skills.

2. Choose the instrument sheet to use the pen to play 6 different

instruments.

3. Insert a letter card with the object showing on the right side. Make

sure the card is inserted correctly so it is recognized by the Studio.

PRODUCT FEATURES

1. ON/OFF BUTTON

Press the ON/OFF BUTTON to turn the unit

on. Press it again to turn the unit off.

2. VOLUME CONTROL BUTTON

To change the volume level, press the

VOLUME CONTROL BUTTON.

Product Features

3. MUSIC BUTTON

Press the MUSIC BUTTON to choose which

melody to play while you draw.

4. PEN

Use the PEN for tracing and drawing fun!

5. ACTIVITY BUTTONS

Press any ACTIVITY BUTTON to enter that

activity.

6. LETTER CARDS

 Insertanyofthe26LETTER CARDS to follow

along and practice writing your letters.

7. NUMBERS CARD

Insert the NUMBERS CARD to follow along

and practice writing numbers 0-9.

8. SHAPES CARD

Insert the SHAPES CARD to follow along and

practicedrawingacircle,asquare,atriangle,

a heart and a star.

Product Features

9. LARGE BLANK CARD

To play with the stencil, you can insert it on the

doodle and draw on top of it right away. While

drawing, the stencil may move a bit if you draw

on it with great force. If you want your stencil

to be absolutely stable on the drawing board,

put the LARGE BLANK CARD on top of the

drawing doodle before you insert the stencil.

10.MUSICAL INSTRUMENT SHEET

Insert the MUSICAL INSTRUMENT SHEET to

select and play the different instruments and

create your own band!

11.MAGNETIC STAMPS

The Studio comes with 3 fun MAGNETIC

STAMPS to add creative designs to your

artwork. Just press the stamps on the surface

of the studio screen and see their designs

appear.

12.SCRIBBLE GEARS

Use the SCRIBBLE GEARS to create fun

designs!

13.ABC SLIDE ERASER

Move the ABC SLIDE ERASER at the bottom

of the studio screen from left to right, and back

again, to erase your designs and start creating

again!

Product Features

2Printed cards

1Large blank card

Activities

14.AUTOMATIC SHUT-OFF

If there is no input into the Stencil & Learn Studio™ for several

minutes, the unit will automatically shut off to save power. After the

unit has automatically shut off, you will need to press the ON/OFF

BUTTON again to restart the unit. We recommend that you turn the

unit off when not playing with it. If the studio is not going to be used

for an extended period of time, we recommend removing the batteries.

ACTIVITIES

1. STOP & GO SOUNDS

Press the STOP & GO SOUNDS button to

enter this activity. Music will play when you start

drawing on the studio screen. When you stop

drawing, the music will stop. If you draw on a

different area, a different instrument will play

your song! You can press the MUSIC BUTTON

to change the song.

2. TRACING FUN

Press the TRACING FUN button to enter this

activity. Insert a card to trace the object shown

on the card. Letters, words and sound effects

play along when the pen is in motion. A different

instrument will play the song depending on

where you draw on the screen.

3. WRITE WITH ME ABC

Press the WRITE WITH ME ABC button to

enter this activity. Insert one of the letter cards

to learn and practice letters. When you draw,

you’ll hear letter names, vocabulary and more!

If no card is inserted, you’ll hear a music beat,

the alphabet and vocabulary words.

4. INSTRUMENT MIX UP

Press the INSTRUMENT MIX UP button

to enter this activity, and insert the Musical

Instrument sheet. One instrument will start to

play as you start drawing. As you move the

pen on different areas of the screen, a new

instrument will be added to the band! Press

the MUSIC BUTTON anytime to change the

song.

5. SCRIBBLE GEARS

Press the SCRIBBLE GEARS button to enter

this activity. Place the scribble gears on the

screen and move around with the pen to create

your masterpiece.

Activities
