Parent’s Guide

91-003678-006 US

INTRODUCTION

Thank you for purchasing the Kidizoom®PixiTM camera. This compact

and lightweight camera with a built-in rechargeable battery is designed

for taking great photos, seles, videos, playing games and listening to

music. With dual camera lenses and a wrist strap, you'll be ready to

take great photos anytime, anywhere! Use 50+ lters to stylize your

pictures with silly face lters, hairstyles, accessories and more. Add

more photo effects and frames, then save and transfer to a computer

with the included USB cable. Snap, stylize and save your creations!

Product Layout and Buttons

Front Camera Lens

Microphone

Camera Button

Master Power Switch

Memory Card Slot

Strap Hook

Speaker

Micro-USB Port

Headphone Jack

Lens Switching

Button

Sele Camera

Lens

Camera Button

Down Button

Right Button

Left Button

Home Button

On/Off Button

OK Button

Delete Button

Lens Switching

Button

Up Button

Master Power Switch /

When the switch is set to the Off

position , the battery will be

disconnected, the camera will not

function and the battery can not be

charged. When the switch is set

to the On position , the battery

will be connected, the camera

will function, and the battery can

be charged.

NOTE:

• You may need a small tool (such

as a paperclip) to move the

switch to the On or Off position.

• It is not necessary to move the

switch to the Off position in daily

use. Only move the switch to the

Off position when the camera

will not be in use for an extended

period of time.

On/Off Button

Press this button to turn the camera

On. Press this button again to turn

the camera Off.

Camera Button Press this button to switch to

Camera mode to take photographs.

Lens Switching

Button

Press this button to toggle between

the Front Camera lens and the

Sele Camera lens.

Home Button

Press this button to go to the Home

menu or to go back to the previous

menu.

OK Button

Press this button to conrm a

selection.

NOTE: The OK button can also

be used to take photos when in

Camera mode and to start/stop

recording videos in Video mode.

Delete Button

Press this button to delete the

selected le or cancel the effect in

Camera mode or Video mode.

Up / Down / Left /

Right Buttons

Press these buttons to make a

selection or do the specic function

according to the icons shown on

screen.

Memory Card Slot Insert a microSD card here for

memory expansion.

Micro-USB Port

Connect to a computer with the

included micro-USB cable to transfer

les and to charge the camera.

Headphone Jack

Plug in standard 3.5mm headphones

to listen to the unit's audio and any

MP3 les you load onto it.

INCLUDED IN THIS PACKAGE

• Kidizoom®PixiTM camera (with built-in rechargeable Li-ion polymer

battery*)

• Micro-USB Cable

• Wrist Strap

• Parent's Guide

WARNING: All packing materials such as tape, plastic sheets,

packaging locks, removable tags, cable ties and

packaging screws are not part of this toy, and

should be discarded for your child’s safety.

NOTE: Please keep this parent's guide as it contains

important information.

ATTENTION : Pour la sécuritéde votre enfant, débarrassez-vous

de tous les produits d’emballage tels que rubans

adhésifs, feuilles de plastique, attaches, étiquettes

et vis d’emballage. Ils ne font pas partie du jouet.

NOTE : Il est conseilléde conserver ce guide des parents

car il comporte des informations importantes.

*Battery is non-replaceable.

The battery in this product must not be disposed of with household

waste. This battery is recyclable. Please follow your local recycling

regulations. Battery is not replaceable.

Note: The metallic coating part on the Kidizoom®PixiTM camera is

insulating.

Unlock the packaging locks:

Turn the packaging lock

counterclockwise several times.

Pull out and discard the packaging lock.

PRODUCT

SPECIFICATION

Display 1.8'' color LCD

Photo Resolution 1600 x 1200 (2.0 MP) (default resolution)

640 x 480 (0.3 MP)

Video Resolution 320 x 240 (default resolution)

160 x 120

Focus Range 1.5 feet - ∞

Internal Memory

256MB built-in memory (shared with

program data, actual memory available for

user storage will be less)

External Memory

Card Format and

Capacity

A microSD or microSDHC card (not

included) with a capacity of 1GB to 32GB

is recommended

File Format Photos: Standard Baseline JPEG

Video: AVI (Motion JPEG)

Connectivity Micro-USB 2.0 cable (included) for

connection to a computer

Battery Rechargeable Li-ion polymer battery

(non-replaceable)

Optimal Operating

and Charging

Temperature

32°F to 104°F (0°C to 40°C)

MP3 Player

supported formats

MP3: MPEG Audio Layer III

WAV: PCM or ADPCM up to 44kHz

Important Note:

• Keep the rubber cover of the Micro-USB Port and Memory Card slot

tightly closed when they are not in use.

STORAGE CAPACITY FOR REFERENCE

Photos Videos

0.3 MP 2.0 MP

160 x 120

(120p)

(minutes)

320 x 240

(240p)

(minutes)

Internal Memory 1,060 210 15 6

microSD

Card

2GB 16,600 3,300 220 90

4GB 33,200 6,600 440 180

8GB 66,400 13,200 880 360

16GB 132,800 26,400 1,760 720

32GB 265,600 52,800 3,520 1,440

NOTE: The above amounts are approximations. The actual quantity and

length of photos/videos varies depending on the shooting environment.

The video length limit per le is ve minutes when using internal memory

and 10 minutes when using a memory card, or a le size no larger

than 2GB.

BATTERY CHARGING

Note: Adult operation required.

To charge the battery, connect the camera to a computer using the

included micro-USB cable.

• Make sure that the Master Power switch is in the On position before

charging.

• Pull up the rubber cover of the Micro-USB Port on the side of

the camera.

• Insert the micro-USB cable (small end) into the Micro-USB Port of

the camera.

• Insert the large end of the micro-USB cable into a USB port on your

computer. A USB port is usually marked with this symbol: .

• Once the connection is successful, you will see the battery charging

symbol appear on the camera's screen.

• When the battery is fully charged, a message will appear on the

camera's screen. The screen will then automatically turn Off. You

may now disconnect the camera from your computer.

Note: It will take approximately three hours to fully charge the battery.

The actual charging time depends on the power supply, the remaining

charge and the ambient temperature of the charging environment. The

optimal ambient temperature is 32°F to 104°F (0°C to 40°C).

BATTERY LIFE

The time the battery lasts between charges varies depending on

how the camera is used. Like other electronic devices, more frequent

usage means that the battery will drain faster. Some activities place

higher demands on the battery, such as taking photos and videos.

With continuous shooting, the battery will last approximately 2-3 hours.

With average usage, the battery should last approximately 8-12 hours.

When the battery level is low, we recommend that you recharge the

battery before further use. When the battery is depleted, the camera will

not turn on and must be recharged.

Power Saving

To preserve battery life, the Kidizoom®PixiTM camera will automatically

turn Off after a short period of time without user input. When recording

a video or listening to music with the Music Player, the camera will not

automatically turn Off until the recording or music has nished.

Battery Maintenance

• Charge the battery regularly for best performance, even when the

camera is not in daily use. We recommend that you fully charge the

camera at least once every six months. Move the Master Power

switch to the On position before charging the battery.

• Move the Master Power switch to the Off position when the camera

will not be in use for an extended period of time.

BATTERY NOTICE

Misuse of batteries can lead to them bursting, causing a re or chemical

burn. Please follow these precautions:

• Do not disassemble.

• Do not crush and do not expose the battery to any shock or force

such as hammering, dropping or stepping on it.

• Do not short circuit.

• Do not expose to high temperatures or place near a heat source. Do

not leave in direct sunlight for any length of time.

• Do not dispose of in a re.

• Do not handle damaged or leaking batteries.

• Keep the battery out of the reach of children.

• Keep the battery dry.

• If you nd the time between charges is considerably shortened with

no change in usage, the battery could be nearing the end of its life.

The battery life varies from battery to battery depending on storage,

usage and environment.

• Examine the USB cord periodically for conditions that may result in

the risk of re, electric shock, or injury to persons such as damage to

the cord, housing, or other parts. In the event of such conditions, the

cord should not be used until properly repaired or replaced.

MEMORY CARD INSTALLATION

The Kidizoom®PixiTM camera supports

microSD and microSDHC memory cards

(not included) to expand media storage.

Follow these instructions to use a

memory card:

• Make sure the camera is turned Off.

• Locate the Memory Card slot on the

side of the camera.

• Open the rubber cover.

• Insert your microSD or microSDHC

card as illustrated. The memory card

will now automatically be set as the default storage location for all

les.

• To remove the memory card from the slot, push the card once, and it

will eject.

NOTE: Data stored in the camera's internal memory will not

be accessible when a memory card is being used. To prevent

accidental data loss, be sure to back up all important data from

the camera's internal memory and from your memory card before

using it.

WRIST STRAP ATTACHMENT

Step 1:

Locate the thread loop on the end of the

wrist strap. Insert it into the groove behind

the strap hook and then push it through.

Step 2:

Feed the end of the strap up through the

loop and pull it all the way through.

Step 3:

Make sure the loop is securely tightened

around the bar.

GETTING STARTED

When using your Kidizoom®PixiTM

camera for the rst time, you will need

to switch the Master Power switch

(located at the bottom of the camera)

to the On position. You may need a

small tool (such as a paper clip) to

move the switch to the On position.

When the Master Power switch is in

the Off position, it will not be possible

to charge the battery or use the

camera.

Note: We recommend fully charging the battery before rst use. A full

charge takes approximately three hours.

TO BEGIN USING KIDIZOOM®PIXITM CAMERA

Press the On/Off button to turn the camera On. When turning the

camera On for the rst time, you will need to select the language. Press

the Up and Down buttons / to select your desired language

and press the OK button to conrm.

Next, set the date and time. Press the Up and Down

buttons to select the correct month, day, year, hour

and minute. Press the Left and Right buttons / to

jump to the previous or next item. Finally, press the

OK button to conrm the setting.

If you wish to change the language, date and time

later, you can do so from the Settings menu.

NOTE: If the battery level becomes very low, the battery will need to

be recharged and the date and time and other settings may need to be

reset afterward.

QUICK OPERATION GUIDE

Home Menu

From the Home menu, you can access all the

activities on the Kidizoom® PixiTM camera. Press the

Home button to display the Home menu, then

press the Left or Right button to select an activity.

Press the OK button to conrm. You can also nd the

current time displayed in bottom right of the screen.

There are seven options in the Home menu:

• Camera

• Video

• View Photos and Videos

• Games

• Filter Studio

• Music Player

• Settings

Camera

In Camera mode, press the OK button or the Camera button to take a

photo. Press the Lens Switching button to toggle between the

Sele Camera lens and Front Camera lens. Press the Left and Right

buttons to select photo effects.

Video

In Video mode, press the OK button or the Camera button to start or

stop recording. Press the Lens Switching button to toggle between the

Sele Camera lens and Front Camera lens. Press the Left and Right

buttons to select different effects.

Tabla de contenidos

Otros manuales de Juguete de V-tech

V-tech

V-tech GearZooz Gear Up & Go Train Instrucciones de montaje

V-tech

V-tech Alphabet Alien Manual de usuario

V-tech

V-tech Go Go Smart Wheels Car Manual de usuario

V-tech

V-tech Wind & Go Turtle Manual de usuario

V-tech

V-tech V.Smile Motion Wireless Controller Manual de usuario

V-tech

V-tech Winnie the Pooh Musical Learning Center Manual de usuario

V-tech

V-tech Quiz Biz Word Play Manual de usuario

V-tech

V-tech V.Smile Motion: Kung Fu Panda Manual de usuario

V-tech

V-tech Whiz Kid CD - Spidey & Friends: Super National... Manual de usuario

V-tech

V-tech Go!Go! Smart Animals Manual de usuario

V-tech

V-tech V.Smile Motion: Wonder Pets-Save the Animals Manual de usuario

V-tech

V-tech Hug-A-Ball Manual de usuario

V-tech

V-tech Little SmartPhone Manual de usuario

V-tech

V-tech Bubble Time Turtle Manual de usuario

V-tech

V-tech Cutie Paws Puppy Stroller Instrucciones de montaje

V-tech

V-tech Light-Up Baby Touch Tablet Manual de usuario

V-tech

V-tech KidiPet Friends Manual de usuario

V-tech

V-tech Strum & Jam KidiBand - Pink Manual de usuario

V-tech

V-tech Lil' Critters Spin & Discover Ferris Wheel Manual de usuario

V-tech

V-tech Lullaby Bear Crib Projector Manual de usuario

V-tech

V-tech Light-up Learning Turtle Manual de usuario

V-tech

V-tech Learn & Grow Farm Manual de usuario

V-tech

V-tech Talking Whiz Kid Power Mouse Manual de usuario

V-tech

V-tech V.Smile Motion: Spidey & Friends Manual de usuario

Manuales populares de Juguete de otras marcas

marklin

marklin 37321 Manual de usuario

Canon

Canon PAPER CRAFT Manual de usuario

GREAT PLANES

GREAT PLANES Pitts M-12S Manual de usuario

NOCH

NOCH 14261 Manual de usuario

Hausler

Hausler 450 SE V2 Manual de usuario

Dynaflite

Dynaflite Daydream Manual de usuario

MiniacRC

MiniacRC MIGHTY MINI P40 WARHAWK Manual

Kenner

Kenner Batman 63651 Manual de usuario

LEGO

LEGO 8527 Manual de usuario

iKarus

iKarus ECO 8 Manual de usuario

Multiplex

Multiplex EasyStar II Manual de instrucciones

Walkera

Walkera 38 Manual de instrucciones

Hasbro

Hasbro TRANSFORMERS BUMBLEBEE Manual de usuario

MD MXION SWD Manual de usuario

Mattel

Mattel Disney Pixar Cars Cozy Cone Spiral Rampway Manual de usuario

marklin

marklin 39671 Manual de usuario

Meccano

Meccano 15103 Manual de usuario

LEGO

LEGO TECHNIC 8735 Manual de usuario
