V-tech Kidi DJ MIX Instrucciones de montaje
Parent’s Guide
91-004004-001 UK
2
INTRODUCTION
Thank you for purchasing Kidi DJ Mix. Get in the DJ booth and
create your own custom music mixes! Customise the 15 included
songs or play along with your own music (external music player not
included). Jam, scratch and mix it up – you’re the star!
1
1
2
4
5
6
7
8
12
13
14
15
16
3
9
10
11
17
18
2
19
9
3
20
4
12
21 22 23
5
13
10
11
14
15
16
17
6
7
8
18
Vocal Track Button
Bluetooth®Connect Button
Audio-Out Jack
Mode Buttons
Style Button
Microphone
Selection Buttons
(Left, Right, OK)
Line-In Button
Power Button
Line-In Jack
Launch Pads
Custom Sound Effects Buttons
Pause Button
Bluetooth®Input Button
Turntable
20
21
22
23
19
Volume Control
Party Light On/Off Switch
Crossfader
Party Light Mode Button
Tempo Buttons
AC Adapter Jack
Preset SFX Buttons
Turntable Effect Buttons
3
INCLUDED IN THE PACKAGE
• Kidi DJ Mix
• Parent’s Guide
WARNING
All packing materials such as tape, plastic sheets, packaging locks,
removable tags, cable ties, cords and packaging screws are not part
of this toy, and should be discarded for your child’s safety.
NOTE
Please keep this parent’s guide as it contains important information.
Removing the Packaging Locks
Rotate the packaging locks 90 degrees
anticlockwise.
Pull out the packaging locks.
4
GETTING STARTED
NOTE
This product is in Try-me mode in the packaging. In DJ Party
mode , press and hold Custom Sound Effect Button
#5 for three seconds to exit Try-Me mode. If the unit powers
down during play, please install a new set of batteries.
Battery Removal and Installation
1. Make sure the unit is turned Off.
2. Find the battery cover located
on the back of the unit, use a
screwdriver to loosen the screw and
then open the battery cover.
3. Remove old batteries by pulling up
on one end of each battery.
4. Install 4 new AA (AM-3/LR6)
batteries following the diagram
inside the battery box. (For best
performance, alkaline batteries or
fully charged Ni-MH rechargeable
batteries are recommended).
5. Replace the battery cover and tighten the screw to secure.
WARNING:
Adult assembly required for battery installation.
Keep batteries out of reach of children.
5
BATTERY NOTICE
• Insert batteries with the correct polarity (+ and -).
• Do not mix old and new batteries.
• Do not mix alkaline, standard (carbon-zinc) or rechargeable batteries.
• Only batteries of the same or equivalent type as recommended
are to be used.
• Do not short-circuit the supply terminals.
• Remove batteries during long periods of non-use.
• Remove exhausted batteries from the toy.
• Disposeofbatteriessafely.Donotdisposeofbatteriesinre.
RECHARGEABLE BATTERIES:
• Remove rechargeable batteries from the toy before charging.
• Rechargeable batteries are only to be charged under adult supervision.
• Do not charge non-rechargeable batteries.
6
Disposal of batteries and product
The crossed-out wheelie bin symbols on products and
batteries, or on their respective packaging, indicates they
must not be disposed of in domestic waste as they contain
substances that can be damaging to the environment and
human health.
The chemical symbols Hg, Cd or Pb, where marked,
indicatethatthebatterycontainsmorethanthespecied
value of mercury (Hg), cadmium (Cd) or lead (Pb) set out
in the Batteries and Accumulators Regulation.
The solid bar indicates that the product was placed on the
market after 13th August, 2005.
Help protect the environment by disposing of your product
or batteries responsibly.
VTech®cares for the planet.
Care for the environment and give your toy a second life by
disposing of it at a small electricals collection point so all its
materials can be recycled.
In the UK:
Visit www.recyclenow.com to see a list of collection points near you.
In Australia & New Zealand:
Check with you local council for kerbside collections.
7
POWER ADAPTER CONNECTION
• Make sure your Kidi DJ Mix is turned off.
• Locate the AC Adapter Jack on the side of the unit.
• Connect an AC adapter (not included) to the AC Adapter Jack.
• Plug the adapter into a power outlet.
• Press the Power Button to turn the system On.
Note: When the toy is not going to be used for an extended period of
time, unplug the adapter.
Safety information when using power
supply for toys
VTech recommend a power supply (AC/DC adaptor) of the below
specication:
Power rating: 6V/800mA DC output with 3.5mm plug (positive centre).
• This toy shall only be used with a power supply for toys.
• The power supply is not a toy.
• This toy is not intended for use by children under 3 years old.
• Do not connect the toy to more than the recommended number of
power supplies.
• Never clean a plugged in toy with liquid.
• Please examine the power supply periodically for conditions that
mayresultintheriskofre,electricshock,orinjurytopersons
(such as damage to the supply cord, output cord, plug, blades,
housing, or other parts) and that, in the event of such conditions,
the power supply should be scrapped.
• Power supplies for toys are not intended to be used as toys,
and the use of these products by children shall be under the full
supervision of parents.
8
PRODUCT FEATURES
1. Power Button
Press the Power Button to power
On the unit. Press the button again to
power Off the unit.
2. Line-In Jack
Connect an external music player here
using a 3.5mm cable (cable and music
player not included).
3. Audio-Out Jack
Connect the mixer to external
speakers or headphones using the
Audio-Out Jack (cable not included).
4. AC Adapter
Connect the mixer to AC power
(adapter not included).
5. Automatic Shut-Off
To preserve battery life, Kidi DJ Mix will automatically turn off
after 10 minutes without input. The unit can be turned on again by
pressing the Power Button.
9
Modes
DJ Party
Create custom mixes with any of the
15built-intracks,adjustingallaspects
of each song, or play along with your
own music.
Audio Controls
•
Use the Launch Pads to choose
different instruments to play. Each
column triggers one instrument at a time.
• Press the Preset Sound Effects
Buttons to play built-in sound effects.
• Press the Style Button to change the
track’s style. The Launch Pads and
Preset Sound Effects Buttons will
adjustwhattheyplayaccordingly.
